Jeep Cherokee 3 (2002-2007) Torque Spec Settings
By IFCAR - Own work, Public Domain
Below you'll find the tightening torques for the Jeep Cherokee 3 in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.
Most-used torque settings for Jeep Cherokee 3
| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Oil pan | Oil pan drain plug | 27 | 20 |
|
|
|
| Oil pan | Oil pan drain plug | 34 | 25 |
|
|
|
| Oil filter | Oil filter | 20 | 15 |
|
|
|
| Spark plugs | Spark plugs | 18 | 13 |
|
|
|
| Glow plugs | Glow plug | 13 | 10 |
|
|
|
| Transmission fluid pan | Drain plug | 30 | 22 |
|
|
To make sure these are the correct tightening torque values, you can use the data below to verify this is the right model.
Are these torque settings right for you?
- Production years: 2002 - 2007
- Generation: 3
- Type of van: car
- Model variant: Base
- Also known as:
All Torque Settings in Tables
engine torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Oil pan | Oil pan bolts | 12 | 9 |
|
|
|
| Oil pan | Oil pan bolts | 12 | 9 |
|
|
|
| Oil pan | Oil pan bolts | 16 | 12 |
|
|
|
| Oil pan | Oil pan drain plug | 27 | 20 |
|
|
|
| Oil pan | Oil pan drain plug | 34 | 25 |
|
|
|
| Oil filter | Oil filter | 20 | 15 |
|
|
|
| Oil filter | Oil separator bolts | 11 | 8 |
|
|
|
| Oil dipstick | Oil dipstick tube to Engine block bolt | 15 | 11 |
|
|
|
| Oil dipstick | Oil level indicator to Cylinder head cover | 11 | 8 |
|
|
|
| Oil dipstick | Oil level indicator tube to Pan | 11 | 8 |
|
|
|
| Oil feeder | Oil jet bolts | 11 | 8 |
|
|
|
| Oil feeder | Oil fill tube bolts | 12 | 9 |
|
|
|
| Oil pump | Oil pump to Block bolts | 28 | 21 |
|
|
|
| Oil pump | Oil pump bolts | 11 | 8 |
|
|
|
| Oil pump | Oil pump bolts | 28 | 21 |
|
|
|
| Oil pump | Oil pump cover plate bolts | 12 | 9 |
|
|
|
| Oil pump | Oil pump cover bolts | 12 | 9 |
|
|
|
| Oil pump | Oil pump pickup tube bolt | 28 | 21 |
|
|
|
| Oil pump | Oil pump pickup tube | 32 | 24 |
|
|
|
| Oil pump | Oil pickup tube bolt and nut | 28 | 21 |
|
|
|
| Oil pump | Oil pump relief valve cap | 41 | 30 |
|
|
|
| Vacuum pump | Vacuum pump bolts | 11 | 8 |
|
|
|
| Vacuum pump | Vacuum pump pipe to Block | 57 | 42 |
|
|
|
| Vacuum pump | Vacuum line fitting bolt | 57 | 42 |
|
|
|
| Piston rods | Connecting rod cap bolts | 27 | 20 | Stage 1 |
|
|
| Piston rods | Connecting rod cap bolts | 10 | 7 | Stage 1 |
|
|
| Piston rods | Connecting rod cap bolts | 30 | 22 | Stage 2 |
|
|
| Piston rods | Connecting rod cap bolts | 88 | 65 | Stage 4 |
|
|
| Piston rods | Connecting rod cap bolts | 27 | 20 | Stage 1 |
|
|
| Cylinder head | Cylinder head bolts | 34 | 25 | Stage 1 |
|
|
| Cylinder head | Cylinder head bolts | 68 | 50 | Stage 2 |
|
|
| Cylinder head | Cylinder head bolts | 68 | 50 | Stage 3 |
|
|
| Cylinder head | Cylinder head bolts | 30 | 22 | Stage 1 |
|
|
| Cylinder head | Cylinder head bolts | 27 | 20 | Step 1, Bolts 1-8 |
|
|
| Cylinder head | Cylinder head bolts | 14 | 10 | Step 2, Bolts 9 through 12 |
|
|
| Cylinder head | Cylinder head bolts | 26 | 19 | Step 4, Bolts 9-12 |
|
|
| Cylinder head | Cylinder head cover bolts | 12 | 9 |
|
|
|
| Cylinder head | Cylinder head cover bolts | 25 | 18 |
|
|
|
| Cylinder head | Cylinder head cover bolts and studs | 12 | 9 |
|
|
|
| Spark plugs | Spark plugs | 18 | 13 |
|
|
|
| Glow plugs | Glow plug | 13 | 10 |
|
|
|
| Intake manifold | Intake manifold lower bolts | 28 | 21 |
|
|
|
| Intake manifold | Intake manifold bolts | 25 | 18 |
|
|
|
| Intake manifold | Intake manifold bolts | 12 | 9 | Stage 1 |
|
|
| Intake manifold | Intake inlet tube bolts | 10 | 7 |
|
|
|
| Engine mounts | Front engine cover bolts | 6 | 4 |
|
|
|
| Engine mounts | Engine mount bracket right bolts | 61 | 45 |
|
|
|
| Engine mounts | Engine mount bracket to Cylinder head bolts | 45 | 33 |
|
|
|
| Engine mounts | Engine mount bracket to Block bolts | 61 | 45 |
|
|
|
| Engine mounts | Engine lift hook bolts | 45 | 33 |
|
|
|
| Engine mounts | Structural support to Engine bolts | 45 | 33 |
|
|
|
| Sensor | Camshaft position sensor bolt | 11 | 8 |
|
|
|
| Sensor | Crankshaft position sensor bolts | 11 | 8 |
|
|
|
| Sensor | Boost pressure sensor bolts | 5 | 4 |
|
|
|
| Sensor | Intake air temperature sensor bolts | 5 | 4 |
|
|
|
| Alternator | Generator mounting bolts | 28 | 21 | M8 bolts |
|
|
| Alternator | Generator mounting bolts | 54 | 40 | M10 bolts |
|
|
| Camshaft | Camshaft sprocket bolt | 115 | 85 |
|
|
|
| Camshaft | Camshaft sprocket bolt | 108 | 80 |
|
|
|
| Camshaft | Camshaft sprocket bolts | 122 | 90 | Non-oiled |
|
|
| Camshaft | Camshaft bearing cap bolts | 11 | 8 |
|
|
|
| Camshaft | Camshaft timing access bolt | 25 | 18 |
|
|
|
| Camshaft | Camshaft access plugs | 80 | 59 |
|
|
|
| Crankshaft | Crankshaft main bearing cap bolts | 28 | 21 | M8 bolts |
|
|
| Crankshaft | Crankshaft main bearing cap bolts | 75 | 55 | M11 bolts |
|
|
| Crankshaft | Rear main bearing support bolts | 28 | 21 |
|
|
|
| Crankshaft | Bedplate retraining bolts | 54 | 40 | Stage 1, Bolts 1A-1J |
|
|
| Crankshaft | Bedplate retraining bolts | 7 | 5 | Stage 2, Bolts 1-8 |
|
|
| Crankshaft | Bedplate retraining bolts | 27 | 20 | Stage 4, Bolts A-E |
|
|
| Crankshaft | Crankshaft gear bolts | 11 | 8 |
|
|
|
| Crankshaft | Crankshaft hub bolt | 275 | 203 |
|
|
|
| Crankshaft | Crankshaft damper | 136 | 100 |
|
|
|
| Crankshaft | Crankshaft damper bolt | 175 | 129 |
|
|
|
| Crankshaft | Crankshaft pulley bolts | 32 | 24 |
|
|
|
| Crankshaft | Crankshaft support bolts | 44 | 32 |
|
|
|
| Crankshaft | Vibration damper to Crankshaft hub bolts | 28 | 21 |
|
|
|
| Crankshaft | Balance shaft carrier to Block bolts | 54 | 40 |
|
|
|
| Crankshaft | Balance shaft bolts | 32 | 24 |
|
|
|
| Crankshaft | Balance shaft gear cover fastener | 12 | 9 | Double ended |
|
|
| Crankshaft | Balance shaft sprocket bolt | 28 | 21 |
|
|
|
| Crankshaft | Balance shaft chain tensioner bolts | 12 | 9 |
|
|
|
| Crankshaft | Balance shaft carrier cover bolts | 12 | 9 |
|
|
|
| Crankshaft | Counterbalance shaft retaining bolt | 28 | 21 |
|
|
|
| Crankshaft | Reluctor wheel bolts | 15 | 11 |
|
|
|
| Common rail | Fuel rail retaining bolts | 25 | 18 |
|
|
|
| Water pump | Water pump housing nuts | 24 | 18 |
|
|
|
| Water pump | Water pump bolts | 58 | 43 |
|
|
|
| Fuel/Oil cooler | Oil cooler to Engine block bolt | 47 | 35 |
|
|
|
| Fuel/Oil cooler | Oil cooler mounting stud | 50 | 37 |
|
|
|
| Radiator | Thermostat housing bolts | 25 | 18 |
|
|
|
| Radiator | Thermostat housing bolts | 12 | 9 |
|
|
|
| Belt tensioner/Timing chains | Timing belt covers bolts | 12 | 9 | Front covers to Rear covers |
|
|
| Belt tensioner/Timing chains | Timing belt covers bolts | 12 | 9 | Rear cover |
|
|
| Belt tensioner/Timing chains | Timing chain cover bolts | 58 | 43 |
|
|
|
| Belt tensioner/Timing chains | Timing chain guide bolts | 28 | 21 |
|
|
|
| Belt tensioner/Timing chains | Timing chain tensioner arm | 28 | 21 |
|
|
|
| Belt tensioner/Timing chains | Timing chain primary tensioner bolts | 28 | 21 |
|
|
|
| Belt tensioner/Timing chains | Timing belt tensioner assembly bolts | 61 | 45 |
|
|
|
| Belt tensioner/Timing chains | Timing belt tensioner bolt | 29 | 21 |
|
|
|
| Belt tensioner/Timing chains | Timing belt idler pulley bolt | 47 | 35 |
|
|
|
| Belt tensioner/Timing chains | Timing drive idler sprocket bolt | 34 | 25 |
|
|
|
| Belt tensioner/Timing chains | Inner timing belt cover bolts | 11 | 8 | 8mm |
|
|
| Belt tensioner/Timing chains | Inner timing belt cover bolts | 45 | 33 | 10mm |
|
|
| Belt tensioner/Timing chains | Outer timing belt cover bolts | 6 | 4 | 3mm |
|
|
| Belt tensioner/Timing chains | Outer timing belt cover bolts | 11 | 8 | 8mm |
|
|
| Belt tensioner/Timing chains | Accessory drive bracket bolts | 45 | 33 |
|
|
|
| Belt tensioner/Timing chains | Accessory drive belt idler pulley bolts | 53 | 39 |
|
|
|
| Fuel system | Fuel pump nuts | 28 | 21 |
|
|
|
| Fuel system | Fuel line fittings at Pump | 28 | 21 |
|
|
|
| Fuel system | Fuel injection pump gear nut | 88 | 65 |
|
|
|
| Fuel system | Fuel injection pump retaining nuts | 24 | 18 |
|
|
drivetrain torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Clutch pressure plate | Pressure plate bolts | 31 | 23 |
|
|
|
| Clutch pressure plate | Pressure plate bolts | 54 | 40 |
|
|
|
| Clutch pressure plate | Pressure plate bolts | 50 | 37 |
|
|
|
| Clutch assembly | Clutch cylinder bolts | 23 | 17 |
|
|
|
| Flywheel/Flex plate | Flywheel bolts | 81 | 60 |
|
|
|
| Flywheel/Flex plate | Flywheel bolts | 45 | 33 |
|
|
|
| Flywheel/Flex plate | Flywheel bolts | 81 | 60 |
|
|
|
| Flywheel/Flex plate | Flex plate to Crankshaft | 95 | 70 |
|
|
|
| Flywheel/Flex plate | Flexplate bolts | 95 | 70 |
|
|
|
| Flywheel/Flex plate | Converter to Driveplate bolt | 88 | 65 |
|
|
|
| Flywheel/Flex plate | Torque converter to Drive plate bolt | 31 | 23 |
|
|
|
| Flywheel/Flex plate | Torque converter to Drive plate bolt | 31 | 23 |
|
|
|
| Transmission fluid pan | Transmission to Engine bolts | 83 | 61 |
|
|
|
| Transmission fluid pan | Oil pan to Case bolt | 20 | 15 |
|
|
|
| Transmission fluid pan | Oil pan bolt | 12 | 9 |
|
|
|
| Transmission fluid pan | Oil pan bolt | 12 | 9 |
|
|
|
| Transmission fluid pan | Cooler line fitting | 48 | 35 |
|
|
|
| Transmission fluid pan | Oil cooler filter | 14 | 10 |
|
|
|
| Transmission fluid pan | Oil cooler filter | 14 | 10 |
|
|
|
| Transmission fluid pan | Drain/Fill plug | 34 | 25 |
|
|
|
| Transmission fluid pan | Drain plug | 30 | 22 |
|
|
|
| Transmission fluid pan | Fill plug | 30 | 22 |
|
|
|
| Transmission mount/case | Structural support to Transmission bolts | 45 | 33 |
|
|
|
| Transmission mount/case | Engine to Transmission bellhousing bolts | 41 | 30 |
|
|
|
| Transmission mount/case | Rear mount to Transmission bolts | 46 | 34 |
|
|
|
| Transmission mount/case | Transmission mounting bolts | 38 | 28 |
|
|
|
| Transmission mount/case | Oil pump to Case bolt | 30 | 22 |
|
|
|
| Transmission mount/case | Oil pump to Transmission case bolt | 28 | 21 |
|
|
|
| Transmission mount/case | Oil pump to Transmission case bolt | 28 | 21 |
|
|
|
| Transmission mount/case | Valve body to Case bolt | 12 | 9 |
|
|
|
| Transmission fluid pan | Valve body to Transmission case bolt | 12 | 9 |
|
|
|
| Transmission mount/case | Valve body to Transmission case bolt | 12 | 9 |
|
|
|
| Transmission mount/case | Rear support to Transmission bolt | 47 | 35 |
|
|
|
| Transmission mount/case | Clevis bracket to Transmission bolt | 68 | 50 |
|
|
|
| Transmission adapter | Adapter/Extension housing bolt | 54 | 40 |
|
|
|
| Transmission adapter | Extension/Adapter housing to Transmission case bolt | 54 | 40 |
|
|
|
| Transmission adapter | Extension/Adapter housing to Transmission case bolt | 54 | 40 |
|
|
|
| Torque converter | Torque converter housing to Engine bolt | 68 | 50 |
|
|
|
| Transfer | Manual valve lever to Manual valve bolt | 5 | 4 |
|
|
|
| Transfer | Manual shift lever retaining cross bolt | 16 | 12 |
|
|
|
| Transfer | Manual shift lever retaining cross bolt | 16 | 12 |
|
|
|
| Transfer | TRS/Manual shaft retaining screw | 5 | 4 |
|
|
|
| Transfer | Manual selector shaft retaining screw | 28 | 21 |
|
|
|
| Transfer | Manual selector shaft retaining screw | 28 | 21 |
|
|
|
| Transfer | Valve body to Transfer plate bolt | 5 | 4 |
|
|
|
| Transfer | Transfer plate to Valve body screw | 6 | 4 |
|
|
|
| Transfer | Transfer plate to Valve body screw | 6 | 4 |
|
|
|
| Transfer | Detent spring to Valve body screw | 5 | 4 |
|
|
|
| Transfer | Detent spring to Valve body screw | 5 | 4 |
|
|
|
| Transfer | Shift shaft lock bolt | 27 | 20 |
|
|
|
| Transfer | Shift tower bolts | 14 | 10 |
|
|
|
| Transfer | Shift tower bolts | 14 | 10 |
|
|
steering torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to |
|---|
exhaust torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Exhaust manifold | Exhaust manifold to Cylinder head bolts | 23 | 17 |
|
|
|
| Exhaust manifold | Exhaust manifold nuts | 36 | 27 |
|
|
|
| Exhaust manifold | Exhaust manifold bolts | 25 | 18 |
|
|
|
| Exhaust manifold | Exhaust manifold heat shield bolts | 12 | 9 |
|
|
|
| Exhaust manifold | Exhaust manifold heat shield bolts | 28 | 21 |
|
|
|
| Exhaust manifold | Exhaust manifold heat shield | 25 | 18 |
|
|
|
| Exhaust manifold | Exhaust manifold heat shield nuts | 8 | 6 | Stage 1 |
|
|
| Turbo | Turbocharger downpipe nuts | 32 | 24 |
|
|
|
| Turbo | Turbocharger bracket bolts | 47 | 35 |
|
|
|
| Turbo | Turbocharger to Exhaust manifold nuts | 32 | 24 |
|
|
|
| Turbo | Turbocharger oil suppy line fitting | 25 | 18 |
|
|
|
| Turbo | Turbocharger oil return line bolts | 11 | 8 |
|
|
|
| EGR | EGR valve bolts | 25 | 18 |
|
|
|
| EGR | EGR air control valve to Cylinder head cover | 11 | 8 |
|
|
|
| EGR | Coolant pipe to EGR valve bolts | 25 | 18 |
|
|
brakes torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to |
|---|
suspension torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to |
|---|
general torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to |
|---|
By OSX - Own work, Public Domain
Did you find the answer to your specific question?
👍 0 👎 0
