Nissan Titan 1 (2003-2015) Torque Spec Settings

By IFCAR - Own work, Public Domain

Below you'll find the tightening torques for the Nissan Titan 1 in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.

Most-used torque settings for Nissan Titan 1

Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil pan drain plug 34 25
unverified source
Oil filter Oil filter 18 13
unverified source
Transmission fluid pan Drain plug 34 25
  • Automatic Transmission
 unverified source
Wheels Wheel nut 133 98
unverified source

Are these torque settings right for you?

  • Production years: 2003 - 2015
  • Generation: 1
  • Type of van: pickup
  • Model variant: Base

All Torque Settings in Tables

engine torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil pan drain plug 34 25
unverified source
Oil pan Upper oil pan bolts 9 7
unverified source
Oil pan Lower oil pan bolts 9 7
unverified source
Oil filter Oil filter 18 13
unverified source
Oil pressure switch Oil pressure sensor 15 11
unverified source
Cylinder head Cylinder head bolts 98 72 Step 1
unverified source
Cylinder head Cylinder head bolts 44 32 Step 3
unverified source
Spark plugs Spark plug 25 18
unverified source
Piston rods Connecting rod bolts 20 15 Step 1
unverified source
Intake manifold Intake manifold bolt 8 6
unverified source
Engine block Main bearing cap bolts 39 29 Bolts 1-10
unverified source
Engine block Main bearing cap bolts 29 21 Bolts 11-20
unverified source
Engine block Main bearing cap side bolts 49 36 Bolts 21-30
unverified source
Engine block Cylinder block drain plug 20 15
unverified source
Engine mounts Engine mounting bracket bolts 88 65
unverified source
Knock sensor Knock sensor bolts 21 15
unverified source
Alternator Generator upper bolt 65 48
unverified source
Alternator Generator lower bracket bolts 22 16
unverified source
Camshaft Camshaft sprockets bolts 152 112
unverified source
Camshaft Camshaft brackets bolts 2 1 Step 1, Bolts 9-12
unverified source
Camshaft Camshaft brackets bolts 2 1 Step 2, Bolts 1-8
unverified source
Camshaft Camshaft brackets bolts 6 4 Step 3, All bolts
unverified source
Camshaft Camshaft brackets bolts 10 7 Step 4, All bolts
unverified source
Water pump Water pump bolt 25 18
unverified source
Water pump Water pump pulley bolt 10 7
unverified source
Belt tensioner Drive belt auto tensioner bolts 22 16
unverified source
Belt tensioner Idler pulley bolt 35 26
unverified source
Belt tensioner Chain tensioner bolts 7 5
unverified source
Valve cover Rocker cover bolts 2 1 Step 1
unverified source
Valve cover Rocker cover bolts 8 6 Step 2
unverified source

drivetrain torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Wheel hub assembly Front wheel hub and bearing assembly bolts 210 155
unverified source
Transmission fluid pan Drain plug 34 25
  • Automatic Transmission
 unverified source
Transmission fluid pan Oil pan mounting bolt 8 6
  • Automatic Transmission
 unverified source
Transmission mount Transmission to Engine bolts 113 83
  • 4x2
  • Automatic Transmission
 unverified source
Transmission mount Transmission to Engine bolts 113 83
  • 4x4
  • Automatic Transmission
 unverified source
Axle shaft Front drive shaft nut 137 101
unverified source

steering torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Tie rod end Tie rod end nuts 85 63
unverified source
Steering wheel Steering wheel center nut 34 25
unverified source
Power steering pump Power steering pump bolt 44 32
unverified source
Power steering pump Power steering pump pulley nut 61 45
unverified source

exhaust torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Exhaust manifold Exhaust manifold nut 28 21
unverified source
Exhaust manifold Exhaust manifold gasket nut 28 21
unverified source

brakes torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Brake caliper Front disc brake caliper bracket bolts 210 155
unverified source
Brake caliper Front disc brake caliper bolts 44 32
unverified source
Brake caliper Rear disc brake caliper bolts 32 24
unverified source

suspension torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Wheels Wheel nut 133 98
unverified source
Shock absorbers/shocks Front shock absorber upper nut 54 40
unverified source
Shock absorbers/shocks Front shock absorber lower bolt 134 99
unverified source
Shock absorbers/shocks Rear shock absorber upper and lower nuts 150 111
unverified source
Stabilizer bar Front stabilizer bar mounting bracket bolts 128 94
unverified source
Control arm Front upper link nut 145 107
unverified source
Control arm Front lower link nut 133 98
unverified source
Ball joint Front upper ball joint nut 79 58
unverified source

general torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
