Mitsubishi Lancer 8 (2000-2007) Torque Spec Settings

Researched by Yien Yien Chan

By OSX - Own work, Public Domain

Below you'll find the tightening torques for the Mitsubishi Lancer 8 in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.

Most-used torque specs for Mitsubishi Lancer 8

Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Drain plug 20 15
verified source
Intake manifold Intake manifold 20 15 Minimum
verified source
Intake manifold Intake manifold 23 17 Maximum
verified source

To make sure these are the correct tightening torque values, you can use the data below to verify this is the right model.

Are these torque settings right for you?

  • Production years: 2000 - 2007
  • Generation: Eight
  • Type of van: car
  • Model variant: Base

All Torque Settings in Tables

engine torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil pan 12 9
verified source
Oil pan Drain plug 20 15
verified source
Oil filter Oil filter housing 24 18 M8
verified source
Oil filter Oil filter housing 40 30 M10
verified source
Oil filter Oil Strainer 10 7
verified source
Oil filter Oil screen 7 5
verified source
Oil pump Oil pump 22 16
verified source
Oil pump Oil pump stator 8 6
verified source
Oil pump Oil Pump Bracket 44 32
verified source
Oil pump Oil Pump Pulley 5 4
verified source
Vacuum pump Vacuum Hose 15 11 Minimum
verified source
Vacuum pump Vacuum Hose 18 13 Maximum
verified source
Piston rods Connecting Rod Cap 34 25
verified source
Intake manifold Intake manifold 20 15 Minimum
verified source
Intake manifold Intake manifold 23 17 Maximum
verified source
Throttle body Throttle body 10 7 Minimum
verified source
Throttle body Throttle body 13 10 Maximum
verified source
Engine mounts Engine mounts 22 16 M8
verified source
Engine mounts Engine mounts 41 30 M10
verified source
Engine mounts Engine mounts 75 55 M12
verified source
Sensor Coolant temperature sensor 30 22
verified source
Sensor Detection Switch 35 26
verified source
Sensor Oil Temperature Sensor 15 11
verified source
Sensor Acceleration/Deceleration Sensor brakcet 13 10
verified source
Alternator Alternator 10 7 Minimum
verified source
Alternator Alternator 20 15 Maximum
verified source
Starter Lock Up Solenoid 10 7
verified source
Starter Shift Solenoid 10 7
verified source
Camshaft Camshaft sprocket 88 65
verified source
Camshaft Camshaft Thrust Plate 13 10
verified source
Crankshaft Main Bearing Cap 74 55
verified source
Crankshaft Crankshaft Pulley 182 134
verified source
Water pump Water pump 24 18
verified source
Radiator Thermostat Housing 24 18
verified source
Radiator Fan Shroud 5 4
verified source
Radiator Fan Clutch 10 7 Minimum
verified source
Radiator Fan Clutch 12 9 Maximum
verified source
Belt tensioner/Timing chains Idler Pulley 49 36
verified source
Belt tensioner/Timing chains Idler Pulley Bracket 24 18
verified source
Valve cover Valve cover 4 3
verified source
Rocker arm Rocker arm 31 23
verified source

drivetrain torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Differential Differential 137 101 Ring gear (Minimum)
verified source
Differential Differential 167 123 Ring gear (Maximum)
verified source
Differential Differential 216 159 Companion flange
verified source
Differential Differential 55 41 Carrier bearing cap (Minimum)
verified source
Differential Differential 65 48 Carrier bearing cap (Maximum)
verified source
Differential Differential 19 14 Bearing lock plate
verified source
Differential Differential 36 27 Lock detection switch
  • Rear
verified source
Differential Center Differential Case 65 48 Ring gear (Minimum)
verified source
Wheel hub assembly Wheel Hub 1 1
verified source
Flywheel/Flex plate Drive Belt 21 15 M8
verified source
Flywheel/Flex plate Drive Belt 51 38 M10
verified source
Flywheel/Flex plate Flywheel 72 53 Minimum
verified source
Flywheel/Flex plate Flywheel 76 56 Maximum
verified source
Flywheel/Flex plate Flex Plate 72 53
verified source
Flywheel/Flex plate Flex Plate 76 56
verified source
Transmission mount Transmission Case 36 27
verified source
Transmission adapter Transmission Case Adapter 36 27 Chain cover
verified source
Transfer Transfer Case Cover 9 7 Oil pool cover
verified source
Transfer Transfer Case Cover 36 27 Rear cover
verified source
Transfer Transfer Case Cover 19 14 Side cover
verified source

steering torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Tie rod end Tie rod end 80 59 4- wheel drive (Minimum)
verified source
Tie rod end Tie rod end 110 81 4- wheel drive (Maximum)
verified source
Tie rod end Tie rod end 65 48 2- wheel drive (Minimum)
verified source
Tie rod end Tie rod end 75 55 2- wheel drive (Maximum)
verified source
Tie rod end Tie rod end 44 32
verified source
Pitman arm Pitman arm 1 1 Minimum
verified source
Pitman arm Pitman arm 3 2 Maximum
verified source
Idler arm Idler Arm Ball Joint Breakaway 2 1
verified source
Idler arm Idler Arm 2 1 Minimum
verified source
Idler arm Idler Arm 15 11 Maximum
verified source
Idler arm Idler Arm Support 54 40 Minimum
verified source
Idler arm Idler Arm Support 64 47 Maximum
verified source
Steering rack Steering gear, jam nut 147 108 Minimum
verified source
Steering rack Steering gear, jam nut 176 130 Maximum
verified source
Steering rack Lower Joint Assembly Connecting Bolt 29 21 Minimum
verified source
Steering rack Lower Joint Assembly Connecting Bolt 34 25 Maximum
verified source
Steering rack Steering Gear Mounting 54 40 Minimum
verified source
Steering rack Steering Gear Mounting 64 47 Maximum
verified source
Steering wheel Wheel Nut 98 72 Minimum
verified source
Steering wheel Wheel Nut 118 87 Maximum
verified source
Power steering Power steering hose 24 18
verified source

exhaust torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
EGR EGR 22 16
verified source

brakes torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Brake booster Brake booster 14 10
verified source
Brake pedal Brake pedal 14 10 Bracket To Frame Nut
verified source
Brake pedal Brake pedal 22 16 Bracket To Frame Bolt
verified source
Brake pedal Brake pedal 29 21 Pedal Support Bushing Nu
verified source
Brake pedal Brake pedal 12 9 Shift Lock Cable Nut
verified source
Master cylinder Master cylinder 15 11
verified source
ABS Brake mounting 12 9
verified source

suspension torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Shock absorbers/shocks Shock Absorber Mounting 215 159 Minimum
verified source
Shock absorbers/shocks Shock Absorber Mounting 245 181 Maximum
verified source
Stabilizer bar Stabilizer bar 2 1 Minimum
verified source
Stabilizer bar Stabilizer bar 3 2 Maximum
verified source
Ball joint Ball joint 1 1 Minimum
verified source
Ball joint Ball joint 4 3 Maximum
verified source

general torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Example of a Lancer 8

By OSX - Own work, Public Domain
