Renault Clio 1 (1990-11998) Torque Spec Settings

Charlie from United Kingdom, CC BY 2.0, via Wikimedia Commons

Below you'll find the tightening torques for the Renault Clio 1 in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.

Most-used torque specs for Renault Clio 1

Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil filter Oil filter 90 66
unverified source
Oil sump Drain plug 28 21 square oil drain plug socket No.8
verified source
Spark plugs Spark plugs 25 18 spark plug socket #16
verified source
Wheels Wheel lug nuts 110 81 Steel wheels - cross order - impact socket #19
verified source
Wheels Wheel lug nuts 90 66 Alloy wheels - cross order - impact socket #19
verified source

To make sure these are the correct tightening torque values, you can use the data below to verify this is the right model.

Are these torque settings right for you?

  • Production years: 1990 - 11998
  • Generation: 1
  • Type of van: car
  • Model variant: Base

All Torque Settings in Tables

engine torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil filter Oil filter 90 66
unverified source
Oil sump Drain plug 28 21 square oil drain plug socket No.8
verified source
Spark plugs Spark plugs 25 18 spark plug socket #16
verified source

drivetrain torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

steering torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Tie rod end Tie rod end to steering knuckle 35 26 drive socket #17
verified source
Pitman arm Tie rod end locknut 50 37 combination spanner #19 + #20
verified source

exhaust torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

brakes torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Brake caliper Front brake caliper brackets 100 74 drive socket #18
verified source
Brake caliper Front brake disc bolts 14 10 torx T30 or T40
verified source

suspension torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Wheels Wheel lug nuts 110 81 Steel wheels - cross order - impact socket #19
verified source
Wheels Wheel lug nuts 90 66 Alloy wheels - cross order - impact socket #19
verified source
Struts Front struts to steering knuckle fasteners 170 125 drive socket + spanner #18
verified source
Stabilizer bar Stabilizer links fastener 35 26 Torx T45 + drive socket #13
verified source
Ball joint Ball joints to control arm 75 55 drive socket #18
verified source

general torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Example of a Clio 1

Phase 3 Clio - Kieran White from Manchester, England, CC BY 2.0, via Wikimedia Commons
