Toyota HiLux 8 (2015-on) Torque Spec Settings

By EurovisionNim - Own work, CC BY-SA 4.0

Below you'll find the tightening torques for the Toyota HiLux 8 in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.

Most-used torque settings for Toyota HiLux 8

Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil pan drain plug 40 30
  • 1GD-FTV
 unverified source
Differential Rear differential drain plug 49 36
unverified source

Are these torque settings right for you?

  • Production years: 2015 - present
  • Generation: 8
  • Type of van: pickup
  • Model variant: Base
  • Also known as: TruckMasters OX

All Torque Settings in Tables

engine torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil pan drain plug 40 30
  • 1GD-FTV
 unverified source
Oil filter Oil filter sub-assembly 12 9
  • 1GD-FTV
 unverified source
Oil pressure switch Oil pressure switch assembly 15 11
  • 1GD-FTV
 unverified source
Cylinder head Cylinder head set bolts and spacers 150 111 Bolt A
  • 1GD-FTV
 unverified source
Cylinder head Cylinder head set bolts and spacers 85 63 Bolt B
  • 1GD-FTV
 unverified source
Piston rods Connecting rod bolts 40 30
  • 1GD-FTV
 unverified source
Intake manifold Intake manifold bolts and nuts 23 17
  • 1GD-FTV
 unverified source
Engine block Crankshaft bearing cap set bolts 95 70
  • 1GD-FTV
 unverified source
Engine mounts Engine assembly to Body 42 31
  • 1GD-FTV
 unverified source
Camshaft Camshaft bearing cap bolts 10 7 Bolt A
  • 1GD-FTV
 unverified source
Camshaft Camshaft bearing cap bolts 21 15 Bolt B
  • 1GD-FTV
 unverified source
Camshaft No.1 camshaft to No.2 camshaft bolts 81 60
  • 1GD-FTV
 unverified source
Water pump Water pump assembly bolts 25 18
  • 1GD-FTV
 unverified source

drivetrain torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Differential Front differential oil drain plug 65 48
unverified source
Differential Rear differential drain plug 49 36
unverified source
Differential Front differential carrier assembly bolts 108 80
unverified source
Differential Rear differential carrier assembly 25 18
unverified source
Transmission fluid pan Drain plug sub-assembly 37 27
  • RC60F/RC61F Manual Transmission
 unverified source
Axle shaft Front axle shaft nut 235 173
  • 4WD
 unverified source
Axle shaft Rear axle shaft with backing plate 43 32
unverified source

steering torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Tie rod end Tie rod end sub-assembly to Front axle hub assembly 49 36
  • 2WD
 unverified source
Tie rod end Tie rod end sub-assembly to Front axle hub assembly 91 67
  • 4WD
  • Pre-Runner
 unverified source
Steering knuckle Front axle hub sub-assembly to Steering knuckle 80 59
  • 4WD
  • Pre-Runner
 unverified source
Steering column Steering column assembly bolt and nuts 36 27
unverified source
Steering shaft No.2 steering intermediate shaft sub-assembly bolt 35 26
unverified source
Steering wheel Steering wheel set nut 50 37
unverified source
Power steering pump Vane pump bolts 21 15
  • 1GD-FTV
 unverified source

exhaust torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Exhaust manifold Exhaust manifold to Cylinder head nuts 40 30
  • 1GD-FTV
 unverified source

brakes torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Brake caliper Front disc brake cylinder mounting bolts 160 118
  • 2WD
 unverified source
Brake caliper Front disc brake assembly bolts 197 145
  • 4WD
  • Pre-Runner
 unverified source

suspension torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Wheels Axle hub nuts 152 112 Steel wheel
  • 2WD
 unverified source
Wheels Axle hub nuts 121 89 Aluminium wheel
  • 2WD
 unverified source
Wheels Axle hub nuts 105 77
  • 4WD
  • Pre-Runner
 unverified source
Shock absorbers/shocks Front shock absorber 110 81
  • 4WD
  • Pre-Runner
  • Coil Spring
 unverified source
Shock absorbers/shocks Rear shock absorber bolts 105 77
  • 4WD
  • Pre-Runner
 unverified source
Stabilizer bar Front stabilizer brackets bolts 48 35
  • 4WD
  • Pre-Runner
 unverified source
Sway bar links/Stabilizer links Front stabilizer link assembly nuts 70 52
  • 4WD
  • Pre-Runner
 unverified source
Control arm Front upper suspension arm assembly to Steering knuckle 110 81
  • 4WD
  • Pre-Runner
 unverified source
Control arm Front upper suspension arm assembly bolt 115 85
  • 4WD
  • Pre-Runner
 unverified source
Control arm Front lower No.1 suspension arm sub-assembly nuts 185 136
  • 4WD
  • Pre-Runner
 unverified source
Ball joint Front lower ball joint attachment bolts 160 118
  • 4WD
  • Pre-Runner
 unverified source
Ball joint Front lower ball joint attachment nut 140 103
  • 4WD
  • Pre-Runner
 unverified source

general torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
