Volkswagen Transporter T5 (2003-2015) Torque Spec Settings

Below you'll find the tightening torques for the Volkswagen Transporter T5 in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.

Most-used torque settings for Volkswagen Transporter T5

Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil drain plug 30 22
  • Petrol Engines
 unverified source
Oil pan Oil drain plug 30 22
  • Diesel Engines
 unverified source
Oil filter Oil filter cap 25 18
unverified source
Spark plugs Spark plugs 25 18
unverified source
Differential Drain plug 40 30 Up to model year 2009
unverified source
Differential Drain plug 38 28 From model year 2010
unverified source
Disc brake Front brake caliper mounting bracket bolts 180 133 Stage 1
unverified source
Disc brake Rear caliper mounting bracket bolts 165 122 Standard caliper
unverified source
Disc brake Rear caliper mounting bracket bolts 180 133 FN44 caliper
unverified source
Wheels Wheel bolts 180 133
unverified source
Wheels Wheel bolts 180 133
unverified source

Are these torque settings right for you?

  • Production years: 2003 - 2015
  • Generation: 5
  • Model variant: T5
  • Also known as: Volkswagen Caravelle Volkswagen Multivan Volkswagen Doubleback (Camper) Volkswagen Transportor (Arpitania) Volkswagen California

All Torque Settings in Tables

engine torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil drain plug 30 22
  • Petrol Engines
 unverified source
Oil pan Oil drain plug 30 22
  • Diesel Engines
 unverified source
Oil pan Oil pan bolts 7 5
  • Automatic Gearbox 09K
 unverified source
Oil pan Sump bolt 15 11
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Oil pan Sump bolt 15 11
  • 4-Cylinder Diesel Engine
 unverified source
Oil pan Baffle plate bolt 15 11
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Oil pan Baffle plate bolt 15 11
  • 4-Cylinder Diesel Engine
 unverified source
Oil filter Oil filter cap 25 18
unverified source
Oil filter Oil filter bracket bolt 20 15
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Oil filter Oil filter bracket bolt 15 11
  • 4-Cylinder Diesel Engine
 unverified source
Oil pressure switch Oil pressure switch 25 18
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Oil pressure switch Oil pressure switch 20 15
  • 4-Cylinder Diesel Engine
 unverified source
Oil dipstick Oil level pipe 3 2
unverified source
Oil dipstick Dipstick guide tube bolt 10 7
  • 4-Cylinder Diesel Engine
 unverified source
Oil feeder Oil spray jet securing bolt with pressure relief valve 27 20
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Oil feeder Oil spray jet bolt 25 18
  • 4-Cylinder Diesel Engine
 unverified source
Oil feeder Suction line bolt 15 11
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Oil feeder Suction line bolt 15 11
  • 4-Cylinder Diesel Engine
 unverified source
Oil feeder Oil supply line union nuts 22 16
  • 4-Cylinder Diesel Engine
 unverified source
Oil feeder Oil supply line clamp bolt 10 7
  • 4-Cylinder Diesel Engine
 unverified source
Oil feeder Oil supply line bracket nut 25 18
  • 4-Cylinder Diesel Engine
 unverified source
Oil feeder Oil return line union nut 22 16
  • 4-Cylinder Diesel Engine
 unverified source
Oil pump Oil pump bolt 15 11
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Oil pump Oil pump sprocket bolt 20 15
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Oil pump Oil pump chain sprocket bolt 25 18
  • 4-Cylinder Diesel Engine
 unverified source
Piston rods Conrod bearing cap nuts 30 22
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Piston rods Conrod bolt 30 22
  • 4-Cylinder Diesel Engine
 unverified source
Cylinder head Cylinder head bolts 40 30 Stage 1
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Cylinder head Cylinder head bolts 35 26 Stage 1
  • 4-Cylinder Diesel Engine
 unverified source
Cylinder head Cylinder head bolts 60 44 Stage 2
  • 4-Cylinder Diesel Engine
 unverified source
Cylinder head Cylinder head cover bolt 10 7
  • 4-Cylinder Diesel Engine
 unverified source
Spark plugs Spark plugs 25 18
unverified source
Glow plugs Glow plugs 18 13
unverified source
Intake manifold Upper intake manifold bolts 25 18
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Intake manifold Lower intake manifold nuts 25 18
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Intake manifold Intake manifold bolt 25 18
  • 4-Cylinder Diesel Engine
 unverified source
Intake manifold Intake manifold support bolt 20 15
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Throttle body Throttle valve module bolt 10 7
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Engine block Cylinder block bracket bolt 15 11
  • 4-Cylinder Diesel Engine
 unverified source
Engine block Cylinder head plug 15 11
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Engine mounts Engine mounting bolts 45 33
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Engine mounts Engine mounting to Engine carrier bolts 50 37
  • 4-Cylinder Diesel Engine
 unverified source
Sensor Oxygen sensor fastener 37 27
unverified source
Sensor Knock sensor bolt 20 15
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Sensor Oil level/Oil temperature sender 10 7
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Sensor Oil level/Oil temperature sender 10 7
  • 4-Cylinder Diesel Engine
 unverified source
Sensor Exhaust gas temperature sender 45 33
  • 4-Cylinder Diesel Engine
 unverified source
Sensor Exhaust gas pressure sensor bolt 9 7
  • 4-Cylinder Diesel Engine
 unverified source
Sensor Intake manifold pressure sender bolts 3 2
  • 4-Cylinder Diesel Engine
 unverified source
Sensor Speed sensor bolt 8 6
unverified source
Sensor Brake pressure sender 35 26
unverified source
Alternator Alternator hexagon head flange bolts 20 15 M8 bolts
  • 2.0L Petrol Engine
 unverified source
Alternator Alternator hexagon head flange bolts 20 15 M8 bolts
  • 3.2L V6 Engine
 unverified source
Alternator Alternator hexagon head flange bolts 20 15 M8 bolts
  • 1.9L TDI Engine
 unverified source
Alternator Alternator hexagon head flange bolts 20 15
  • 2.0L TDI Engine
 unverified source
Alternator Alternator bolts 20 15 M8 bolts
  • 2.5L TDI Engine
 unverified source
Starter Starter bolts 40 30 M10 bolts
unverified source
Starter Starter bolts 75 55 M12 bolts
unverified source
Starter Battery positive wire to Starter nut 20 15 M8 nut
unverified source
Battery Battery positive terminal clamp bolt 6 4
unverified source
Battery Battery negative terminal clamp bolt 6 4
unverified source
Battery Battery tray bolt 23 17
unverified source
Battery Ignition coil bolts 8 6
unverified source
Camshaft Camshaft pulley bolt 100 74
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Camshaft Camshaft sprocket bolt 100 74
  • 4-Cylinder Diesel Engine
 unverified source
Camshaft Bearing cap nuts 20 15
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Camshaft Bearing cap bolts 8 6
  • 4-Cylinder Diesel Engine
 unverified source
Crankshaft Crankshaft pulley bolt 90 66
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Crankshaft Crankshaft pulley bolt 120 89
  • 4-Cylinder Diesel Engine
 unverified source
Crankshaft Bearing cap bolts 65 48
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Crankshaft Bearing cap bolts 65 48
  • 4-Cylinder Diesel Engine
 unverified source
Water pump Coolant pump bolt 15 11
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Water pump Coolant pump bolt 15 11
  • 4-Cylinder Diesel Engine
 unverified source
Heater core Heater unit bolts 8 6
unverified source
Heater core Heater unit securing nuts 5 4
unverified source
Fuel/Oil cooler Oil cooler bolt 6 4
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Fuel/Oil cooler Engine oil cooler plug 25 18
  • 4-Cylinder Diesel Engine
 unverified source
Fuel/Oil cooler Fuel cooler bolts 20 15
  • Diesel Engines
 unverified source
Intercooler Charge air cooler bolts 8 6
  • 4-Cylinder Diesel Engine
 unverified source
Coolant expansion tank Coolant expansion tank bolt 5 4
  • 4-Cylinder Diesel Engine
 unverified source
Radiator Radiator bolt 3 2
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Radiator Radiator bolt 10 7
  • 4-Cylinder Diesel Engine
 unverified source
Radiator Radiator fan bolts 5 4
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Radiator Radiator fan nut 10 7
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Radiator Radiator fan support bolts 6 4
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Radiator Radiator fan support bolts 5 4
  • 4-Cylinder Diesel Engine
 unverified source
Radiator Coolant pipe bolt 40 30
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Radiator Coolant pipe bolt 40 30
  • 4-Cylinder Diesel Engine
 unverified source
Radiator Thermostat housing fasteners 13 10
unverified source
Air conditioning Air conditioner compressor bolts 45 33
unverified source
Air conditioning Air conditioner compressor to Ancillary bracket bolts 25 18
unverified source
Air conditioning Refrigerant lines to Air conditioner compressor bolts 20 15
unverified source
Air conditioning Refrigerant lines bolts 10 7
unverified source
Air conditioning Heating and air conditioning unit nuts 5 4
unverified source
Belt tensioner/Timing chains Belt pulley and vibration damper bolt 10 7
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Belt tensioner/Timing chains Belt pulley and vibration damper bolt 10 7
  • 4-Cylinder Diesel Engine
 unverified source
Belt tensioner/Timing chains Tensioning pulley nut 20 15
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Belt tensioner/Timing chains Tensioning pulley nut 20 15
  • 4-Cylinder Diesel Engine
 unverified source
Belt tensioner/Timing chains Idler roller nut 20 15
  • 4-Cylinder Diesel Engine
 unverified source
Belt tensioner/Timing chains Poly V-belt tensioning element bolt 25 18
  • 4-Cylinder Diesel Engine
 unverified source
Valve cover Valve body to Gearbox bolts 8 6
  • Automatic Gearbox 09K
 unverified source
Rocker arm Rocker arm shaft bolt 20 15
  • 4-Cylinder Diesel Engine
 unverified source

drivetrain torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Differential Rear final drive to Cross member bolts 90 66
unverified source
Differential Hydraulic fluid filler plug 40 30 Up to model year 2010
unverified source
Differential Hydraulic fluid filler plug 15 11 From model year 2010
unverified source
Differential Oil filler plug 8 6 Up to model year 2010
unverified source
Differential Oil filler plug 15 11 From model year 2010
unverified source
Differential Drain plug 40 30 Up to model year 2009
unverified source
Differential Drain plug 38 28 From model year 2010
unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 Initial torque
  • 4-Cylinder Engine
  • 5-Speed Manual Gearbox
 unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 Final torque
  • 4-Cylinder Engine
  • 5-Speed Manual Gearbox
 unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 Initial torque
  • 4-Cylinder Engine
  • 4WD
  • 6-Speed Manual Gearbox
 unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 Initial torque
  • 5-Cylinder Engine
  • 4WD
  • 6-Speed Manual Gearbox
 unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 Final torque
  • 4-Cylinder Engine
  • 4WD
  • 6-Speed Manual Gearbox
 unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 Final torque
  • 5-Cylinder Engine
  • 4WD
  • 6-Speed Manual Gearbox
 unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 With triple roller joint AAR3700i + AAR4100i, Initial torque
  • 5-Cylinder Engine
  • 4WD
  • 6-Speed Manual Gearbox
 unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 With triple roller joint AAR3700i + AAR4100i, Initial torque
  • 6-Cylinder Engine
  • 4WD
  • 6-Speed Manual Gearbox
 unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 With triple roller joint AAR3700i + AAR4100i, Initial torque
  • 5-Cylinder Engine
  • 4WD
  • Automatic Gearbox
 unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 With triple roller joint AAR3700i + AAR4100i, Initial torque
  • 6-Cylinder Engine
  • 4WD
  • Automatic Gearbox
 unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 With triple roller joint AAR3700i + AAR4100i, Final torque
  • 5-Cylinder Engine
  • 4WD
  • 6-Speed Manual Gearbox
 unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 With triple roller joint AAR3700i + AAR4100i, Final torque
  • 6-Cylinder Engine
  • 4WD
  • 6-Speed Manual Gearbox
 unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 With triple roller joint AAR3700i + AAR4100i, Final torque
  • 5-Cylinder Engine
  • 4WD
  • Automatic Gearbox
 unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 With triple roller joint AAR3700i + AAR4100i, Final torque
  • 6-Cylinder Engine
  • 4WD
  • Automatic Gearbox
 unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 With triple roller joint AAR3700i/SX, Initial torque
  • Dual Clutch Gearbox
 unverified source
CVs Outer constant velocity joint twelve-point nut 200 148 With triple roller joint AAR3700i/SX, Final torque
  • Dual Clutch Gearbox
 unverified source
CVs Inner constant velocity joint support ring bolts 20 15
  • 4-Cylinder Engine
  • 5-Speed Manual Gearbox
 unverified source
CVs Inner constant velocity joint support ring bolts 20 15
  • 4-Cylinder Engine
  • 4WD
  • 6-Speed Manual Gearbox
 unverified source
CVs Inner constant velocity joint support ring bolts 20 15
  • 5-Cylinder Engine
  • 4WD
  • 6-Speed Manual Gearbox
 unverified source
Wheel hub assembly Front wheel bearing housing bolts 180 133 FN3 caliper
unverified source
Wheel hub assembly Front wheel bearing housing bolts 180 133 2FNR44 caliper
unverified source
Wheel hub assembly Rear brake carrier to Wheel bearing housing bolts 165 122
unverified source
Wheel hub assembly Rear brake carrier to Wheel bearing housing bolts 180 133 FN44 caliper
unverified source
Flywheel/Flex plate Flywheel bolt 60 44
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Flywheel/Flex plate Flywheel bolt 60 44
  • 4-Cylinder Diesel Engine
 unverified source
Transmission fluid pan Fluid filler/level plug 15 11
  • Automatic Transmission
 unverified source
Transmission fluid pan Fluid filler/level plug 30 22 Hex plug
  • Manual Transmission
 unverified source
Transmission fluid pan Fluid filler/level plug 45 33 Bi-hex plug
  • Manual Transmission
 unverified source
Transmission fluid pan Fluid drain plug 40 30
  • Automatic Transmission
 unverified source
Transmission fluid pan Fluid drain plug 30 22 Hex plug
  • Manual Transmission
 unverified source
Transmission fluid pan Fluid drain plug 45 33 Bi-hex plug
  • Manual Transmission
 unverified source
Torque converter Torque converter to Drive plate 57 42
  • Automatic Gearbox 09K
 unverified source
Transfer Gearbox mounting bolts 50 37
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Transfer Gearbox mounting bolts 50 37
  • 4-Cylinder Diesel Engine
 unverified source
Transfer Selector mechanism bolt 20 15
  • Automatic Gearbox 09K
 unverified source
Transfer Selector shaft gear lever nut 10 7
  • Automatic Gearbox 09K
 unverified source
Transfer Selector lever cable bolt 13 10
  • Automatic Gearbox 09K
 unverified source
Transfer Selector lever cable support bracket bolt 23 17
  • Automatic Gearbox 09K
 unverified source
Drive/Axle shaft Front drive shaft nut 200 148
unverified source
Drive/Axle shaft Propshaft flange to Rear final drive 210 155
unverified source

steering torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Tie rod end Tie rod end to Steering knuckle fastening nut 60 44
unverified source
Tie rod end Tie rod end locknut 60 44
unverified source
Steering column Steering column bolt 20 15
unverified source
Steering column Steering column nut 20 15
unverified source
Power steering Vane pump bolts 40 30
  • 5-Cylinder Diesel Engine
 unverified source
Power steering Vane pump banjo bolt 35 26
  • 4-Cylinder Petrol Engine
 unverified source
Power steering Vane pump banjo bolt 35 26
  • 6-Cylinder Petrol Engine
 unverified source
Power steering Vane pump banjo bolt 35 26
  • 4-Cylinder Diesel Engine
 unverified source
Power steering Vane pump pulley bolts 25 18
  • 4-Cylinder Petrol Engine
 unverified source
Power steering Vane pump pulley bolts 25 18
  • 6-Cylinder Petrol Engine
 unverified source
Power steering Vane pump pulley bolts 25 18
  • 4-Cylinder Diesel Engine
 unverified source
Power steering Vane pump bracket bolts 25 18
  • 4-Cylinder Petrol Engine
 unverified source
Power steering Vane pump bracket bolts 25 18
  • 6-Cylinder Petrol Engine
 unverified source
Power steering Vane pump bracket bolts 25 18
  • 4-Cylinder Diesel Engine
 unverified source

exhaust torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Exhaust manifold Exhaust manifold connecting pipe bolt 25 18
  • 4-Cylinder Diesel Engine
 unverified source
Exhaust manifold Exhaust manifold heat shield nut 25 18
  • 4-Cylinder Diesel Engine
 unverified source
EGR Exhaust gas recirculation cooler bolt 9 7
  • 4-Cylinder Diesel Engine
 unverified source
EGR Exhaust gas recirculation valve bolt 9 7
  • 4-Cylinder Diesel Engine
 unverified source
EGR Exhaust gas recirculation connecting pipe 40 30
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Muffler Front silencer mounting bolts 60 44
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Muffler Front silencer mounting bolts 25 18 With retaining ring
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Muffler Front silencers mounting bolts 60 44 With retaining ring
  • 4-Cylinder Diesel Engine
 unverified source
Muffler Rear silencers mounting bolts 23 17 With retaining ring
  • 4-Cylinder Diesel Engine
 unverified source
Diesel particulate filter Particulate filter bolt 60 44
  • 4-Cylinder Diesel Engine
 unverified source
Diesel particulate filter Particulate filter to Cylinder block support bolt 60 44
  • 4-Cylinder Diesel Engine
 unverified source
Catalytic converter Front exhaust pipe with catalytic converter nut 25 18
  • 4-Cylinder Injection Engine (2.0L Engine)
 unverified source
Catalytic converter Front exhaust pipe with catalytic converter clip 7 5
  • 4-Cylinder Diesel Engine
 unverified source

brakes torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Disc brake Front brake caliper mounting bracket bolts 180 133 Stage 1
unverified source
Disc brake Rear caliper mounting bracket bolts 165 122 Standard caliper
unverified source
Disc brake Rear caliper mounting bracket bolts 180 133 FN44 caliper
unverified source
Disc brake Front brake guide pin 30 22 FN3 caliper
unverified source
Disc brake Front brake guide pin 60 44 2FNR44 caliper
unverified source
Disc brake Rear brake caliper guide pins/bolts 35 26 Standard caliper
unverified source
Disc brake Rear brake caliper guide pins/bolts 30 22 FN44 caliper
unverified source
Disc brake Front brake disc fastener 17 13
unverified source
Disc brake Front brake disc bolt 15 11 FN3 caliper
unverified source
Disc brake Front brake disc bolt 20 15 2FNR44 caliper
unverified source
Disc brake Rear brake disc bolt 15 11
unverified source
Disc brake Front brake caliper bleed screw 10 7
unverified source
Disc brake Rear brake caliper bleed screw 10 7
unverified source
Brake line Brake line to Front left brake caliper 14 10
unverified source
Brake line Brake line to Front right brake caliper 14 10
unverified source
Brake line Brake line to Rear left brake caliper 14 10
unverified source
Brake line Brake line to Rear right brake caliper 14 10
unverified source
Brake line Brake master cylinder/primary piston circuit to Hydraulic unit brake line 14 10
unverified source
Brake line Brake master cylinder/secondary piston circuit to Hydraulic unit brake line 14 10
unverified source
Brake pedal Brake pedal mounting bracket nut 25 18
unverified source
Brake pedal Brake pedal switch nuts 25 18
unverified source
Master cylinder Tandem brake master cylinder nuts 25 18
unverified source
ABS ABS control unit bolts 4 3
unverified source
ABS ABS speed sensor bolt 8 6
unverified source

suspension torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Wheels Wheel bolts 180 133
unverified source
Struts Front shock strut piston rod nut 80 59
unverified source
Struts Front shock absorber strut mount upper fastener 80 59
unverified source
Struts Front shock strut to Steering knuckle lower fasteners 75 55
unverified source
Shock absorbers/shocks Top shock absorber fastener 80 59
unverified source
Shock absorbers/shocks Rear shock absorber lower fastener 120 89
unverified source
Stabilizer bar Front stabilizer link to Stabilizer bar fastener 60 44
unverified source
Stabilizer bar Anti-roll bar clip bolts 110 81
unverified source
Stabilizer bar Coupling rod nuts 60 44
unverified source
Sway bar links/Stabilizer links Front stabilizer link to Shock strut fastener 60 44
unverified source
Control arm Control arm to Subframe front fastener 110 81
unverified source
Control arm Arm to Body subframe rear fastener 110 81
unverified source
Control arm Suspension link nut 120 89
unverified source
Control arm Suspension link eccentric bolt 100 74
unverified source
Ball joint Front ball joint to Steering knuckle fastener 90 66
unverified source
Ball joint Front ball joint to Control arm fasteners 60 44
unverified source
Ball joint Track rod ball joint nuts 60 44
unverified source

general torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

Did you find the answer to your specific question?
👍 12 👎 17

Related Vans:
