Volkswagen Golf V (Mk5) (2004-2008) Torque Spec Settings

OSX, Public domain, via Wikimedia Commons

Below you'll find the tightening torques for the Volkswagen Golf V (Mk5) in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.

Most-used torque specs for Volkswagen Golf V (Mk5)

Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil drain plug 30 22
  • Petrol Engines
unverified source
Oil pan Oil drain plug 30 22
  • Diesel Engines
unverified source
Spark plugs Spark plugs 25 18
unverified source
Wheels Wheel bolts 120 89
unverified source
Wheels Wheel bolts 120 89
unverified source

To make sure these are the correct tightening torque values, you can use the data below to verify this is the right model.

Are these torque settings right for you?

  • Production years: 2004 - 2008
  • Generation: 5
  • Type of van: car
  • Also known as: Volkswagen Rabbit Volkswagen GTI Volkswagen Jetta SportWagen Volkswagen Vento Variant

All Torque Settings in Tables

engine torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil drain plug 30 22
  • Petrol Engines
unverified source
Oil pan Oil drain plug 30 22
  • Diesel Engines
unverified source
Oil pan Oil filler plug 15 11
unverified source
Oil filter Oil filter housing 25 18
  • 2.0L FSI Engine
unverified source
Oil filter Oil filter housing 25 18
  • 2.0L TFSI Engine
unverified source
Oil filter Oil filter housing 25 18
  • 2.5L Petrol Engine
unverified source
Oil filter Filter threaded cap 25 18
  • 1.6L FSI Engine
unverified source
Oil filter Oil filter cover 25 18
  • 1.4L TSI Engine
unverified source
Oil pressure switch Oil pressure switch 25 18
unverified source
Piston rods Conrod bolt 20 15 M7x0.75
unverified source
Piston rods Conrod bolt 30 22 M8x1
unverified source
Cylinder head Cylinder head bolts 30 22
unverified source
Spark plugs Spark plugs 25 18
unverified source
Glow plugs Glow plugs 18 13
unverified source
Engine mounts Engine mount to Engine bracket bolts 60 44
unverified source
Engine mounts Engine mount to Body bolts 40 30
unverified source
Engine mounts Engine mount side brace bolts 20 15
unverified source
Alternator Alternator retaining bolts 25 18
unverified source
Alternator Alternator ancillary bracket hexagon head flange bolts 40 30
  • 1.4L Petrol Engine
unverified source
Alternator Alternator ancillary bracket hexagon head flange bolts 52 38
  • 1.6L Petrol Engine
unverified source
Alternator Alternator ancillary bracket hexagon head flange bolts 52 38
  • 2.0L FSI Engine
unverified source
Alternator Alternator ancillary bracket hexagon head flange bolts 45 33
  • 2.0L TFSI Engine
unverified source
Alternator Alternator ancillary bracket multi-point socket head bolts 25 18
  • 2.5L Petrol Engine
unverified source
Alternator Alternator ancillary bracket hexagon head flange bolts 40 30
  • 1.9L Diesel Engine
unverified source
Alternator Alternator ancillary bracket hexagon head flange bolts 40 30
  • 2.0L Diesel Engine
unverified source
Alternator Alternator ancillary bracket hexagon head flange bolts 40 30
  • 2.0L SDI Engine
unverified source
Alternator Alternator hexagon head flange bolts 23 17
  • 1.4L FSI Engine
unverified source
Alternator Alternator hexagon head flange bolts 23 17
  • 1.4L TSI Engine
unverified source
Alternator Alternator hexagon head flange bolts 23 17
  • 1.6L FSI Engine
unverified source
Alternator Alternator hexagon head flange bolts 25 18
  • 2.5L Petrol Engine
unverified source
Alternator Alternator hexagon head flange bolts 20 15
  • 1.9L Diesel Engine
unverified source
Alternator Alternator hexagon head flange bolts 20 15
  • 2.0L Diesel Engine
unverified source
Alternator Alternator hexagon head flange bolts 20 15
  • 2.0L SDI Engine
unverified source
Starter Starter bolts 75 55
unverified source
Starter Starter bolts 40 30 M10
  • DSG
unverified source
Starter Starter bolts 75 55 M12
  • DSG
unverified source
Starter Starter bolts 75 55
  • Manual Gearbox
unverified source
Starter Battery positive wire connection to Starter nut 15 11
unverified source
Starter Battery positive wire connection to Starter nut 20 15
  • DSG
unverified source
Starter Battery positive wire connection to Starter nut 15 11
  • Manual Gearbox
unverified source
Starter Battery positive cable securing nut 15 11
  • 1.4L FSI Engine
unverified source
Battery Battery clamping plate bolt 35 26
unverified source
Battery Battery clamp to Battery positive terminal 9 7
unverified source
Battery Battery clamp to Battery negative terminal 9 7
unverified source
Battery Ignition coil bolts 7 5
unverified source
Camshaft Camshaft housing bolt 10 7
unverified source
Camshaft Camshaft housing cover bolt 10 7
unverified source
Crankshaft Crankshaft pulley fastener 10 7
unverified source
Water pump Water pump fasteners 15 11
unverified source
Radiator Air conditioning radiator fasteners 13 10
unverified source
Belt tensioner/Timing chains Timing belt idler pulley fastener 25 18
unverified source
Belt tensioner/Timing chains Timing belt tensioner pulley fastener 27 20
unverified source
Belt tensioner/Timing chains Lower timing cover fasteners 10 7
unverified source
Belt tensioner/Timing chains Timing belt cover fasteners 10 7
unverified source
Fuel system Fuel filter upper part to Fuel filter lower part 5 4
unverified source

drivetrain torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Wheel hub assembly Drive shaft to Front wheel hub bolt 200 148
unverified source
Wheel hub assembly Front wheel hub bearing fastener 70 52
unverified source
Wheel hub assembly Rear hub 180 133
unverified source
Clutch pressure plate Pressure plate bolt 13 10 Bolt M6, Sachs clutch
  • 6-Speed Manual Gearbox 02S
unverified source
Clutch pressure plate Pressure plate bolt 13 10 Bolt M6, LuK clutch
  • 6-Speed Manual Gearbox 02S
unverified source
Clutch pressure plate Pressure plate bolt 13 10 One-piece flywheel
  • 6-Speed Manual Gearbox 02S
unverified source
Clutch pressure plate Pressure plate bolt 20 15 Bolt M7, Sachs clutch
  • 6-Speed Manual Gearbox 02S
unverified source
Clutch pressure plate Pressure plate bolt 20 15 Bolt M7, LuK clutch
  • 6-Speed Manual Gearbox 02S
unverified source
Clutch pressure plate Pressure plate bolt 20 15 One-piece flywheel
  • 6-Speed Manual Gearbox 02S
unverified source
Clutch pressure plate SAC pressure plate bolt 13 10 Bolt M6, LuK clutch
  • 6-Speed Manual Gearbox 02Q
unverified source
Clutch pressure plate SAC pressure plate bolt 20 15 Bolt M7, LuK clutch
  • 6-Speed Manual Gearbox 02Q
unverified source
Clutch pressure plate Clutch plate thrust plate bolt 13 10 Bolt M6, Sachs clutch
  • 6-Speed Manual Gearbox 02Q
unverified source
Clutch pressure plate Clutch plate thrust plate bolt 20 15 Bolt M7, Sachs clutch
  • 6-Speed Manual Gearbox 02Q
unverified source
Clutch assembly Clutch pedal to Mounting bracket self-locking nuts 25 18
  • 6-Speed Manual Gearbox 02S
unverified source
Clutch assembly Clutch pedal to Mounting bracket self-locking nuts 25 18
  • 6-Speed Manual Gearbox 02Q
unverified source
Clutch assembly Master cylinder hexagon nut 25 18 LHD vehicles
  • 6-Speed Manual Gearbox 02S
unverified source
Clutch assembly Master cylinder hexagon nut 25 18 RHD vehicles
  • 6-Speed Manual Gearbox 02S
unverified source
Clutch assembly Master cylinder hexagon nut 25 18 LHD
  • 6-Speed Manual Gearbox 02Q
unverified source
Clutch assembly Master cylinder hexagon nut 25 18 RHD
  • 6-Speed Manual Gearbox 02Q
unverified source
Clutch assembly Slave cylinder hexagon bolt 20 15 LHD vehicles
  • 6-Speed Manual Gearbox 02S
unverified source
Clutch assembly Slave cylinder flange bolt 20 15 RHD vehicles
  • 6-Speed Manual Gearbox 02S
unverified source
Clutch assembly Slave cylinder with clutch release bearing bolts 12 9 Without locking fluid
  • 6-Speed Manual Gearbox 02Q
unverified source
Clutch assembly Slave cylinder with clutch release bearing bolts 15 11 With locking fluid
  • 6-Speed Manual Gearbox 02Q
unverified source
Flywheel/Flex plate Flywheel cover plate to Intermediate plate 10 7
  • 6-Speed Manual Gearbox 02Q
unverified source
Transmission fluid pan Gearbox oil drain plug 30 22
  • 6-Speed Manual Gearbox 02S
unverified source
Transmission fluid pan Gearbox oil drain plug 30 22 Hexagon socket head
  • 6-Speed Manual Gearbox 02Q
unverified source
Transmission fluid pan Gearbox oil drain plug 45 33 Multi-point socket head
  • 6-Speed Manual Gearbox 02Q
unverified source
Transmission fluid pan Gearbox oil filler plug 30 22
  • 6-Speed Manual Gearbox 02S
unverified source
Transmission fluid pan Gearbox oil filler plug 30 22 Hexagon socket head
  • 6-Speed Manual Gearbox 02Q
unverified source
Transmission fluid pan Gearbox oil filler plug 45 33 Multi-point socket head
  • 6-Speed Manual Gearbox 02Q
unverified source
Transmission fluid pan ATF cooler bolt 36 27
  • 6-Speed Automatic Gearbox 09G
unverified source
Transmission mount/case Transmission mount to Body bolts 40 30
unverified source
Transmission mount/case Transmission mount to Transmission bracket bolts 60 44
unverified source
Transmission mount/case Transmission case bolts 40 30 Shorter M10 bolt
unverified source
Transmission mount/case Transmission case bolts 40 30 Longer M10 bolts
unverified source
Torque converter Drive plate to Torque converter 60 44
  • 1.6L Petrol Engine
  • 6-Speed Automatic Gearbox 09G
unverified source
Torque converter Drive plate to Torque converter 60 44
  • 2.0L FSI Engine
  • 6-Speed Automatic Gearbox 09G
unverified source
Torque converter Drive plate to Torque converter 60 44
  • 2.5L Petrol Engine
  • 6-Speed Automatic Gearbox 09G
unverified source
Transfer Selector lever housing hexagon nuts 8 6 Nut M6
  • 6-Speed Manual Gearbox 02S
unverified source
Transfer Selector lever housing hexagon nuts 25 18 Nut M8
  • 6-Speed Manual Gearbox 02S
unverified source
Transfer Selector housing hexagon nuts 8 6 Nut M6
  • 6-Speed Manual Gearbox 02Q
unverified source
Transfer Selector housing hexagon nuts 25 18 Nut M8
  • 6-Speed Manual Gearbox 02Q
unverified source
Transfer Selector housing nuts 9 7
  • 7-Speed Dual Clutch Gearbox 0AM
unverified source
Transfer Selector housing nuts 9 7
  • 6-Speed Automatic Gearbox 09G
unverified source
Transfer Gearbox bracket to Gearbox bolts 40 30
  • 6-Speed Manual Gearbox 02S
unverified source
Transfer Gearbox bracket to Gearbox bolts 60 44
  • 6-Speed Manual Gearbox 02Q
unverified source
Transfer Bracket to Gearbox bolt 40 30
  • 7-Speed Dual Clutch Gearbox 0AM
unverified source
Transfer Gearbox mounting to Body bolts 60 44
  • 6-Speed Manual Gearbox 02S
unverified source
Transfer Gearbox mounting to Body bolts 60 44
  • 6-Speed Manual Gearbox 02Q
unverified source
Transfer Gearbox support to Gearbox bracket and gearbox bolts 20 15
  • 6-Speed Manual Gearbox 02S
unverified source
Transfer Gearbox housing cover bolts 18 13
  • 6-Speed Manual Gearbox 02S
unverified source
Transfer Gearbox to Engine 40 30 M10
  • 1.4L TSI Engine
unverified source
Transfer Gearbox to Engine 80 59 M12
  • 1.4L TSI Engine
unverified source
Transfer Gearbox to Engine 40 30 M10
  • 1.9L TDI Engine
unverified source
Transfer Gearbox to Engine 80 59 M12
  • 1.9L TDI Engine
unverified source

steering torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Tie rod end Tie rod end to Steering knuckle 20 15
unverified source
Tie rod end Tie rod end locknut 50 37
unverified source
Steering knuckle Shock strut to Steering knuckle lower fasteners 70 52
unverified source
Steering knuckle Control arm to Rear knuckle fasteners 90 66
unverified source
Steering column Crash bar to Steering column mounting bracket 20 15 Attachment with 1 bolt
  • 6-Speed Manual Gearbox 02S
unverified source
Steering column Crash bar to Steering column mounting bracket 10 7 Attachment with 2 bolts
  • 6-Speed Manual Gearbox 02S
unverified source
Steering column Crash bar to Steering column mounting bracket 10 7
  • 6-Speed Manual Gearbox 02Q
unverified source

exhaust torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

brakes torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Disc brake Front brake caliper guide pins 30 22
unverified source
Disc brake Rear brake caliper guide pin bolts 35 26
unverified source
Disc brake Rear brake caliper bracket 90 66
unverified source
Disc brake Front brake disc fasteners 4 3
unverified source
Disc brake Rear brake disc fasteners 4 3
unverified source
Disc brake Front brake caliper bleed screw 10 7
unverified source
Disc brake Rear brake caliper bleed screw 10 7
unverified source
Brake line Front brake pipe to Brake caliper fastener 30 22
unverified source
ABS ABS sensor to Steering knuckle 7 5
unverified source

suspension torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Wheels Wheel bolts 120 89
unverified source
Struts Front strut upper mounting bolts 15 11
unverified source
Struts Front strut bottom clamp bolt/nut 70 52
unverified source
Struts Front shock strut piston rod nut 60 44
unverified source
Struts Rear shock strut piston rod upper fastener 25 18
unverified source
Shock absorbers/shocks Front shock absorber strut mount upper fastener 15 11
unverified source
Shock absorbers/shocks Rear shock absorber upper mounting bolt 50 37
unverified source
Shock absorbers/shocks Rear shock absorber lower mounting bolt 180 133
unverified source
Stabilizer bar Front stabilizer link to Stabilizer bar fastener 65 48
unverified source
Stabilizer bar Rear stabilizer link to Stabilizer bar fastener 45 33
unverified source
Sway bar links/Stabilizer links Front stabilizer link to Shock strut fastener 60 44
unverified source
Control arm Front control arm to Subframe front fastener 70 52
unverified source
Control arm Front control arm to Body subframe rear fastener 50 37
unverified source
Control arm Front control arm to Car body rear fastener 70 52
unverified source
Control arm Rear control arm to Rear subframe fastener 95 70
unverified source
Control arm Rear arm to Beam fastener 95 70
unverified source
Ball joint Front ball joint fastener 60 44
unverified source

general torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Example of a Golf V (Mk5)

OSX, Public domain, via Wikimedia Commons


Did you find the answer to your specific question?
👍 8 👎 12
