Volkswagen Touareg I (2002-2010) Torque Spec Settings

By Vauxford - Own work, CC BY-SA 4.0,

Below you'll find the tightening torques for the Volkswagen Touareg I in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.

Most-used torque settings for Volkswagen Touareg I

Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil drain plug 50 37 Oil sump top part
  • V8
  • 4.2L Gasoline Engine
  • BHX
 unverified source
Oil pan Oil drain plug 50 37 Oul sump lower part
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Intake manifold Intake manifold 13 10
  • VR6
  • 3.2L Gasoline Engine
  • BRJ
 unverified source
Intake manifold Intake manifold 13 10
  • VR6
  • 3.2L Gasoline Engine
  • BMX
 unverified source
Intake manifold Intake manifold 13 10
  • VR6
  • 3.2L Gasoline Engine
  • BAA
 unverified source
Intake manifold Intake manifold 13 10
  • VR6
  • 3.2L Gasoline Engine
  • BMV
 unverified source
Intake manifold Intake manifold 13 10
  • V6
  • 3.2L Gasoline Engine
  • BKJ
 unverified source
Intake manifold Intake manifold 13 10
  • V6
  • 3.2L Gasoline Engine
  • AZZ
 unverified source
Intake manifold Intake manifold 10 7
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Intake manifold Intake manifold 10 7
  • V8
  • 4.2L Gasoline Engine
  • BHX
 unverified source

To make sure these are the correct tightening torque values, you can use the data below to verify this is the right model.

Are these torque settings right for you?

  • Production years: 2002 - 2010
  • Generation: 1
  • Type of van: car
  • Model variant: Base

All Torque Settings in Tables

engine torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil drain plug 50 37 Oil sump top part
  • V8
  • 4.2L Gasoline Engine
  • BHX
 unverified source
Oil pan Oil drain plug 50 37 Oul sump lower part
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Oil filter Oil filter cover 35 26
unverified source
Oil filter Oil filter housing 25 18 Oil filter cover
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Oil filter Oil filter housing 10 7 Oil filter drain plug
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Oil filter Oil filter housing 25 18 Oil filter cover
  • V10
  • 4.9L Diesel Engine
  • AYH
 unverified source
Oil filter Oil filter housing 20 15 On the engine block
  • V10
  • 4.9L Diesel Engine
  • AYH
 unverified source
Oil filter Oil filter housing 25 18 Cap
  • Straight-5
  • 2.5L Diesel Engine
  • BAC
 unverified source
Oil filter Oil filter housing 20 15 On the engine block
  • Straight-5
  • 2.5L Diesel Engine
  • BAC
 unverified source
Oil filter Oil filter housing 25 18 Oil filter cover
  • Straight-5
  • 2.5L Diesel Engine
  • BLK
 unverified source
Oil filter Oil filter housing 20 15 On the engine block
  • Straight-5
  • 2.5L Diesel Engine
  • BLK
 unverified source
Oil pump Oil pump 30 22
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Oil pump Oil pump 30 22
  • V8
  • 4.2L Gasoline Engine
  • BHX
 unverified source
Oil pump Oil pump chain wheel 34 25
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Oil pump Oil pump chain wheel 34 25
  • V8
  • 4.2L Gasoline Engine
  • BHX
 unverified source
Oil pump Oil pump drive chain tensioner 9 7 Minimum
unverified source
Oil pump Oil pump drive chain tensioner 10 7 Maximum
unverified source
Vacuum pump Vacuum pump 8 6 Minimum
  • Straight-5
  • 2.5L Diesel Engine
  • BLK
 unverified source
Vacuum pump Vacuum pump 20 15 Maximum
  • Straight-5
  • 2.5L Diesel Engine
  • BLK
 unverified source
Piston rods Rear axle shock absorber piston rod 60 44
  • Rear
 unverified source
Cylinder head Cylinder head screws 35 26 First stage
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Cylinder head Cylinder head screws 60 44 Second stage
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Cylinder head Cylinder head screws 30 22 First stage
  • V10
  • 4.9L Diesel Engine
  • AYH
 unverified source
Cylinder head Cylinder head screws 60 44 Second stage
  • V10
  • 4.9L Diesel Engine
  • AYH
 unverified source
Cylinder head Cylinder head screws 60 44 First stage
  • Straight-5
  • 2.5L Diesel Engine
  • BLK
 unverified source
Spark plugs Spark Plugs 30 22
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Spark plugs Spark Plugs 30 22
  • V8
  • 4.2L Gasoline Engine
  • BHX
 unverified source
Glow plugs Ceramic glow plug 12 9
unverified source
Glow plugs Metal glow plug 15 11
unverified source
Intake manifold Intake manifold 13 10
  • VR6
  • 3.2L Gasoline Engine
  • BRJ
 unverified source
Intake manifold Intake manifold 13 10
  • VR6
  • 3.2L Gasoline Engine
  • BMX
 unverified source
Intake manifold Intake manifold 13 10
  • VR6
  • 3.2L Gasoline Engine
  • BAA
 unverified source
Intake manifold Intake manifold 13 10
  • VR6
  • 3.2L Gasoline Engine
  • BMV
 unverified source
Intake manifold Intake manifold 13 10
  • V6
  • 3.2L Gasoline Engine
  • BKJ
 unverified source
Intake manifold Intake manifold 13 10
  • V6
  • 3.2L Gasoline Engine
  • AZZ
 unverified source
Intake manifold Intake manifold 10 7
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Intake manifold Intake manifold 10 7
  • V8
  • 4.2L Gasoline Engine
  • BHX
 unverified source
Engine block Coolant drain plug 40 30 At cylinder head
  • V10
  • 4.9L Diesel Engine
  • AYH
 unverified source
Engine block Coolant drain plug 40 30 On engine block
  • V10
  • 4.9L Diesel Engine
  • AYH
 unverified source
Alternator Alternator 22 16
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Alternator Alternator 22 16
  • V8
  • 4.2L Gasoline Engine
  • BHX
 unverified source
Starter Start System 40 30
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Starter Start System 40 30
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Starter Start System 65 48
  • V10
  • 4.9L Diesel Engine
  • AYH
 unverified source
Starter Start System 65 48
  • V10
  • 4.9L Diesel Engine
  • BLE
 unverified source
Starter Start System 65 48
  • V10
  • 4.9L Diesel Engine
  • BWF
 unverified source
Camshaft Camshaft bearing 5 4
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Camshaft Camshaft bearing 8 6
  • V10
  • 4.9L Diesel Engine
  • AYH
 unverified source
Camshaft Camshaft bearing 8 6
  • Straight-5
  • 2.5L Diesel Engine
  • BLK
 unverified source
Camshaft Camshaft timing chain slip rail 5 4 Left
  • V6
  • 3.0L Diesel Engine
  • CASB
 unverified source
Camshaft Camshaft timing chain slip rail 18 13 Bottom
  • V6
  • 3.0L Diesel Engine
  • CASB
 unverified source
Camshaft Camshaft timing chain slip rail 23 17 Top screws
  • V6
  • 3.0L Diesel Engine
  • CASB
 unverified source
Camshaft Camshaft timing chain slip rail 5 4 First stage
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Camshaft Camshaft timing chain slip rail 5 4 First stage
  • V6
  • 3.0L Diesel Engine
  • CASB
 unverified source
Camshaft Camshaft tensioner 40 30
unverified source
Crankshaft Crankshaft central screw 200 148
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Crankshaft Crankshaft pulley 22 16
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Crankshaft Crankshaft pulley 22 16
  • V8
  • 4.2L Gasoline Engine
  • BHX
 unverified source
Crankshaft Vibration damper 22 16
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Crankshaft Vibration damper 22 16
  • V8
  • 4.2L Gasoline Engine
  • BHX
 unverified source
Crankshaft Vibration damper 22 16
  • V8
  • 4.9L Diesel Engine
  • AYH
 unverified source
Water pump Coolant pump 14 10
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Water pump Coolant pump 8 6 Tighten cross-wise
  • V10
  • 4.9L Diesel Engine
  • AYH
 unverified source
Water pump Coolant pump 20 15 On the engine block
  • V10
  • 4.9L Diesel Engine
  • AYH
 unverified source
Water pump Coolant pump 14 10
  • V8
  • 4.2L Gasoline Engine
  • BHX
 unverified source
Water pump Coolant pump 20 15 Cap
  • Straight-5
  • 2.5L Diesel Engine
  • BLK
 unverified source
Water pump Coolant pump 84 62 Wheel central nuts
  • Straight-5
  • 2.5L Diesel Engine
  • BLK
 unverified source
Water pump Coolant pump 20 15 On engine block
  • Straight-5
  • 2.5L Diesel Engine
  • BLK
 unverified source
Water pump Coolant pump 84 62
  • Straight-5
  • 2.5L Diesel Engine
  • BLK
 unverified source
Fuel/Oil cooler Oil Cooler 25 18
  • V6
  • 3.2L Gasoline Engine
  • AZZ
 unverified source
Fuel/Oil cooler Oil Cooler 20 15
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Radiator Fan wheel 10 7
  • Straight-5
  • 2.5L Diesel Engine
  • BAC
 unverified source
Radiator Fan wheel 10 7
  • Straight-5
  • 2.5L Diesel Engine
  • BPE
 unverified source
Air conditioning Air-conditioning compressor 20 15
  • Straight-5
  • 2.5L Diesel Engine
  • BLK
 unverified source
Air conditioning Air-conditioning compressor 20 15
  • Straight-5
  • 2.5L Diesel Engine
  • BPD
 unverified source
Air conditioning Air-conditioning compressor 20 15
  • Straight-5
  • 2.5L Diesel Engine
  • BPE
 unverified source
Air conditioning Air-conditioning compressor 20 15
  • Straight-5
  • 2.5L Diesel Engine
  • BAC
 unverified source
Air conditioning Air-conditioning compressor 20 15
  • V10
  • 4.9L Diesel Engine
  • BLE
 unverified source
Air conditioning Air-conditioning compressor 20 15
  • V10
  • 4.9L Diesel Engine
  • AYH
 unverified source
Air conditioning Air-conditioning compressor 20 15
  • V10
  • 4.9L Diesel Engine
  • BWF
 unverified source
Air conditioning Air-conditioning compressor 23 17 M8
  • V6
  • 3.2L Gasoline Engine
  • AZZ
 unverified source
Air conditioning Air-conditioning compressor 45 33 M10
  • V6
  • 3.2L Gasoline Engine
  • AZZ
 unverified source
Valve cover Valve cover 15 11
  • Straight-5
  • 2.5L Diesel Engine
  • BAC
 unverified source
Valve cover Valve cover 15 11
  • Straight-5
  • 2.5L Diesel Engine
  • BLK
 unverified source
Valve cover Valve cover 15 11
  • Straight-5
  • 2.5L Diesel Engine
  • BPD
 unverified source
Valve cover Valve cover 15 11
  • Straight-5
  • 2.5L Diesel Engine
  • BPE
 unverified source
Rocker arm Rocker Bridge 10 7
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Rocker arm Rocker Bridge 10 7
  • V8
  • 4.2L Gasoline Engine
  • BHX
 unverified source

drivetrain torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Wheel hub assembly Wheel hub wheel bearing 200 148 M20
unverified source
Wheel hub assembly Wheel hub wheel bearing 500 369 M24
unverified source
Flywheel/Flex plate Flywheel/Flex plate 30 22
  • V8
  • 4.2L Gasoline Engine
  • AXQ
 unverified source
Flywheel/Flex plate Flywheel/Flex plate 50 37
  • V10
  • 4.9L Diesel Engine
  • AYH
 unverified source
Flywheel/Flex plate Flywheel 50 37
  • V10
  • 4.9L Diesel Engine
  • AYH
 unverified source
Drive/Axle shaft Front axle brake calliper 30 22
  • Straight-5
  • 2.5L Diesel Engine
  • BAC
  • Front
 unverified source
Drive/Axle shaft Front axle brake calliper 30 22
  • Straight-5
  • 2.5L Diesel Engine
  • BLK
  • Front
 unverified source
Drive/Axle shaft Front axle brake calliper 30 22
  • Straight-5
  • 2.5L Diesel Engine
  • BPD
  • Front
 unverified source
Drive/Axle shaft Front axle brake calliper 30 22
  • Straight-5
  • 2.5L Diesel Engine
  • BPE
  • Front
 unverified source
Drive/Axle shaft Rear axle brake calliper 30 22
  • Straight-5
  • 2.5L Diesel Engine
  • BAC
  • Rear
 unverified source
Drive/Axle shaft Rear axle brake calliper 30 22
  • Straight-5
  • 2.5L Diesel Engine
  • BLK
  • Rear
 unverified source
Drive/Axle shaft Rear axle brake calliper 30 22
  • Straight-5
  • 2.5L Diesel Engine
  • BPD
  • Rear
 unverified source
Drive/Axle shaft Rear axle brake calliper 30 22
  • Straight-5
  • 2.5L Diesel Engine
  • BPE
  • Rear
 unverified source

steering torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Power steering Servo-steering pump 35 26
  • Straight-5
  • 2.5L Diesel Engine
  • BAC
 unverified source
Power steering Servo-steering pump 35 26
  • Straight-5
  • 2.5L Diesel Engine
  • BLK
 unverified source
Power steering Servo-steering pump 35 26
  • Straight-5
  • 2.5L Diesel Engine
  • BPE
 unverified source

exhaust torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Exhaust manifold Exhaust manifold 25 18 M8
  • V6
  • 3.2L Gasoline Engine
  • AZZ
 unverified source
Exhaust manifold Exhaust manifold 40 30 M10
  • V6
  • 3.2L Gasoline Engine
  • AZZ
 unverified source
Exhaust manifold Exhaust pipe 25 18 M8
  • V6
  • 3.2L Gasoline Engine
  • AZZ
 unverified source
Exhaust manifold Exhaust pipe 40 30 M10
  • V6
  • 3.2L Gasoline Engine
  • AZZ
 unverified source
Turbo Turbo Charger 40 30 On the engine block
  • Straight-5
  • 2.5L Diesel Engine
  • BAC
 unverified source
Turbo Turbo Charger 40 30 Screws must be replaced
  • Straight-5
  • 2.5L Diesel Engine
  • BPE
 unverified source
Turbo Turbo Charger 40 30
  • Straight-5
  • 2.5L Diesel Engine
  • BKS
 unverified source
Catalytic converter Catalytic converter 8 6 Clamps
  • Straight-5
  • 2.5L Diesel Engine
  • BAC
 unverified source
Catalytic converter Catalytic converter 25 18 Nuts
  • Straight-5
  • 2.5L Diesel Engine
  • BAC
 unverified source
Catalytic converter Catalytic converter 27 20 At the turbocharger
  • V6
  • 3.0L Diesel Engine
  • BKS
 unverified source
Catalytic converter Catalytic converter 25 18 On particle filter
  • V6
  • 3.0L Diesel Engine
  • BKS
 unverified source
Catalytic converter Catalytic converter 25 18 At the turbocharger
  • V6
  • 3.0L Diesel Engine
  • CATA
 unverified source

brakes torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

suspension torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Wheels Wheel suspension on drive shaft 50 37 M10
  • Front
 unverified source
Wheels Wheel suspension on drive shaft 90 66 M12
  • Front
 unverified source
Wheels Wheel suspension on drive shaft 200 148 M20
  • Front
 unverified source
Wheels Wheel suspension on drive shaft 500 369 M24
  • Front
 unverified source
Wheels Wheel suspension on drive shaft 50 37 M10
  • Rear
 unverified source
Wheels Wheel suspension on drive shaft 90 66 M12
  • Rear
 unverified source
Wheels Wheel suspension on drive shaft 200 148 M20
  • Rear
 unverified source
Wheels Wheel suspension on drive shaft 500 369 M24
  • Rear
 unverified source
Control arm Upper Transverse Control Arm 50 37 At bearing pedestal
unverified source
Control arm Upper Transverse Control Arm 95 70 On stub axle
unverified source
Control arm Track Control Arm 180 133 At the front wheel axle support
unverified source
Control arm Track Control Arm 105 77 At the front wheel stub axle
unverified source
Control arm Lower Front transverse control arm 150 111 At the axle support
  • Front
 unverified source
Control arm Lower Rear transverse control arm 180 133 At the axle support
  • Rear
 unverified source
Control arm Lower Front transverse control arm 150 111 On stub axle
  • Front
 unverified source
Control arm Lower Rear transverse control arm 180 133 On stub axle
  • Rear
 unverified source
Control arm Upper front transverse control arm 180 133 At axle support
  • Front
 unverified source
Control arm Upper front transverse control arm 150 111 On stub axle
  • Front
 unverified source
Control arm Upper rear transverse control arm 180 133 At axle support
  • Rear
 unverified source
Control arm Upper rear transverse control arm 150 111 On stub axle
  • Rear
 unverified source

general torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Example of a Touareg I

By Lemon3, CC BY-SA 3.0


Did you find the answer to your specific question?
👍 0 👎 0

Related Vans:
