Volkswagen Scirocco 3 (2008-2017) Torque Spec Settings

By Thomas doerfer- Own work, CC BY 3.0

Below you'll find the tightening torques for the Volkswagen Scirocco 3 in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.

Most-used torque settings for Volkswagen Scirocco 3

Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil drain plug 30 22 Seal rings must be replaced
unverified source
Oil filter Oil filter 25 18 Replace the o ring
unverified source
Intake manifold Intake manifold 20 15
  • 1.4L Gasoline Engine
  • CAVD
 unverified source
Intake manifold Intake manifold 20 15
  • 1.4L Gasoline Engine
  • CAXA
 unverified source
Intake manifold Intake manifold 20 15
  • 1.4L Gasoline Engine
  • CMSB
 unverified source
Intake manifold Intake manifold 20 15
  • 1.4L Gasoline Engine
  • CNWA
 unverified source
Intake manifold Intake manifold 20 15
  • 1.4L Gasoline Engine
  • CTHD
 unverified source
Intake manifold Intake manifold 20 15
  • 1.4L Gasoline Engine
  • CTKA
 unverified source
Steering wheel Steering wheel 30 22 First stage
unverified source

To make sure these are the correct tightening torque values, you can use the data below to verify this is the right model.

Are these torque settings right for you?

  • Production years: 2008 - 2017
  • Generation: 3
  • Type of van: car
  • Model variant: Base

All Torque Settings in Tables

engine torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil drain plug 30 22 Seal rings must be replaced
unverified source
Oil pan Oil Sump top part 15 11 First stage
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Oil pan Oil Sump lower part 8 6 First stage
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Oil pan Oil sump at gearbox 40 30
  • 1.4L Gasoline Engine
  • CAXA
 unverified source
Oil pan Oil sump at gearbox 40 30
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Oil pan Oil sump on the engine block 13 10
  • 1.4L Gasoline Engine
  • CAXA
 unverified source
Oil pan Oil sump on the engine block 15 11
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Oil filter Oil filter 25 18 Replace the o ring
unverified source
Oil filter Oil filter cover 25 18
unverified source
Oil filter Oil filter housing on the engine block 15 11 First stage
unverified source
Oil pressure switch Oil pressure sensor 20 15
unverified source
Oil pump Oil pump 15 11 First stage
unverified source
Oil pump Oil pump drive chain tensioner 9 7
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Oil pump Oil pump chain wheel 20 15 First stage
unverified source
Vacuum pump Vacuum Pump 9 7 Minimum
unverified source
Vacuum pump Vacuum Pump 10 7 Maximum
unverified source
Cylinder head Cylinder head screws 40 30 Screws 1 - 10
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Cylinder head Cylinder head screws 8 6 Screws 11 - 14
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Cylinder head Cylinder head screws 30 22 First Stage
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Cylinder head Cylinder head screws 50 37 Second Stage
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Intake manifold Intake manifold 20 15
  • 1.4L Gasoline Engine
  • CAVD
 unverified source
Intake manifold Intake manifold 20 15
  • 1.4L Gasoline Engine
  • CAXA
 unverified source
Intake manifold Intake manifold 20 15
  • 1.4L Gasoline Engine
  • CMSB
 unverified source
Intake manifold Intake manifold 20 15
  • 1.4L Gasoline Engine
  • CNWA
 unverified source
Intake manifold Intake manifold 20 15
  • 1.4L Gasoline Engine
  • CTHD
 unverified source
Intake manifold Intake manifold 20 15
  • 1.4L Gasoline Engine
  • CTKA
 unverified source
Engine block Balance shaft gear wheel 10 7 Coolant pump
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Engine block Balance shaft gear wheel 9 7 On the engine block
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Engine block Balance shaft module 15 11 First stage
unverified source
Engine block Engine block closure screws 30 22
unverified source
Alternator Alternator 25 18
  • 1.4L Gasoline Engine
  • CAXA
 unverified source
Alternator Alternator 25 18
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Alternator Alternator 25 18
  • 2.0L Diesel Engine
  • CFHC
 unverified source
Alternator Alternator 25 18
  • 1.4L Gasoline Engine
  • CMSB
 unverified source
Alternator Generator Bracket 20 15 First stage
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Alternator Generator Bracket, M10 x 30 screws 40 30 First Stage
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Alternator Drive chain balance shaft tensioner 85 63
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Camshaft Camshaft Adjuster 9 7 Bearing casing
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Camshaft Camshaft Adjuster 9 7 Cap
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Camshaft Camshaft Adjuster 35 26 Central Screws
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Camshaft Camshaft Adjuster 40 30 First Stage
unverified source
Camshaft Camshaft bearing 10 7 Tighten gradually and alternately from inside to outside
unverified source
Camshaft Camshaft drive belt deflection pulley 20 15 Top
unverified source
Camshaft Camshaft drive belt deflection pulley 50 37 Center
unverified source
Camshaft Camshaft drive belt deflection pulley 20 15 Bottom
unverified source
Camshaft Camshaft timing chain slip rail 20 15
unverified source
Camshaft Camshaft timing chain tensioner 9 7 Minimum
unverified source
Camshaft Camshaft timing chain tensioner 10 7 Maximum
unverified source
Camshaft Camshaft timing chain tensioninig rail 20 15
unverified source
Camshaft Camshaft timing gear 50 37 First stage
  • 1.4L Gasoline Engine
  • CAVD
 unverified source
Camshaft Camshaft timing gear 100 74 Central screw
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Camshaft Camshaft timing gear 20 15 Wheel, First stage
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Camshaft Outlet camshaft wheel 8 6 M6 Central Screw
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Camshaft Outlet camshaft wheel 20 15 M8 Central Screw
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Camshaft Crankshaft ventilation 9 7
unverified source
Camshaft Crankshaft central screws 150 111 First stage
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Camshaft Crankshaft central screws 180 133 First stage
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Camshaft Crankshaft central screws 150 111 First stage
unverified source
Crankshaft Balance shaft timing chain guide rail 20 15 Balance shaft timing chain guide rail
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Crankshaft Balance shaft timing chain tension rail 20 15 Balance shaft timing chain tension rail
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Crankshaft Bottom part of the control unit housing 8 6 Bottom part of the control unit housing
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Crankshaft Crankshaft sensor 10 7
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Crankshaft Main bearing 50 37 First stage
  • 1.4L Gasoline Engine
  • CAVD
 unverified source
Crankshaft Main bearing 65 48 Center
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Crankshaft Main bearing 20 15 Lateral-fitting
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Crankshaft Main bearing 50 37 First stage
  • 1.4L Gasoline Engine
  • CAXA
 unverified source
Crankshaft Vibration damper 10 7 First stage
unverified source
Water pump Cooling system - coolant pump 8 6
  • 1.4L Gasoline Engine
  • CAVD
 unverified source
Water pump Cooling system - coolant pump 9 7 Gradually tighten screws crosswise
  • 1.4L Gasoline Engine
  • CAWB
 unverified source
Water pump Cooling system - coolant pump 9 7
  • 1.4L Gasoline Engine
  • CAXA
 unverified source
Water pump Cooling system - coolant pump 9 7
  • 1.4L Gasoline Engine
  • CMSB
 unverified source
Water pump Cooling system - coolant pump 8 6
  • 1.4L Gasoline Engine
  • CNWA
 unverified source
Water pump Cooling system - coolant pump 8 6
  • 1.4L Gasoline Engine
  • CTHD
 unverified source
Water pump Cooling system - coolant pump 8 6
  • 1.4L Gasoline Engine
  • CTKA
 unverified source
Water pump Cooling system - Coolant pump pulley 20 15
  • 1.4L Gasoline Engine
  • CAXA
 unverified source
Water pump Cooling system - Coolant pump pulley 20 15
  • 1.4L Gasoline Engine
  • CMSB
 unverified source
Fuel/Oil cooler Oil cooler 25 18
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Radiator Cooling system - coolant thermostat housing 9 7 Tighthen crosswise from the outside to inside
unverified source
Radiator Cooling system - coolant pump drive wheel 20 15 Screws must be replaced
unverified source
Radiator Cooling system - Fanwheel 5 4
unverified source
Radiator Cooling system - radiator mounting 5 4
unverified source
Air conditioning Air-conditioning compressor 45 33
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Air conditioning Air-conditioning compressor 45 33
  • 2.0L Diesel Engine
  • CFHC
 unverified source
Air conditioning Air-conditioning compressor bracket, M10 x 30 screws 20 15 First Stage
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Air conditioning Air-conditioning compressor bracket, M10 x 30 screws 40 30 First Stage
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Belt tensioner/Timing chains Top Auxiliary Drive belt tensioner 23 17
  • 1.4L Gasoline Engine
  • CAVD
 unverified source
Belt tensioner/Timing chains Bottom Auxiliary Drive belt tensioner 40 30 First stage
  • 1.4L Gasoline Engine
  • CAVD
 unverified source
Belt tensioner/Timing chains Compressor Belt 23 17
  • 1.4L Gasoline Engine
  • CAVD
 unverified source
Belt tensioner/Timing chains Auxiliary Drive belt tensioner 10 7
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Belt tensioner/Timing chains Auxiliary Drive belt tensioner 40 30
  • 1.4L Gasoline Engine
  • CAXA
 unverified source
Belt tensioner/Timing chains Auxiliary Drive belt tensioner 20 15 With automatic tensioner
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Belt tensioner/Timing chains Chain tensioner 9 7
unverified source
Belt tensioner/Timing chains Control drive chain tensioner 9 7
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Belt tensioner/Timing chains Control chain tensioning rail 20 15
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Belt tensioner/Timing chains Control unit for intake valve timing 5 4
unverified source
Valve cover Valve Cover 10 7 Tigthen gradually cross-wise
  • 2.0L Diesel Engine
  • CFHC
 unverified source
Valve cover Valve Cover 10 7 Tigthen gradually cross-wise
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Fuel system Fuel Distributing Pipe 22 16
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Fuel system Fuel Distributing Pipe 22 16
  • 2.0L Diesel Engine
  • CFHC
 unverified source
Fuel system Injection hoses 28 21
unverified source
Fuel system Injection Nozzle (Injector) 8 6 First Stage
  • 2.0L Diesel Engine
  • CFGB
 unverified source
Fuel system Injection Nozzle (Injector) 10 7 Retaining Clamp
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Fuel system Injection Nozzle (Injector) 5 4 Crews
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Fuel system Pressure tube connection 30 22 Components must be replaced
unverified source
Fuel system Fuel lines 18 13
unverified source
Fuel system Fuel pump, Preliminary feed pump 110 81 Sealing rings must be replaced
unverified source
Wheel hub assembly Wheel hub wheel bearing 70 52
  • Front
 unverified source
Clutch pressure plate Clutch pressure plate, M6 13 10 Gradually tighten screws crosswise
unverified source
Clutch pressure plate Clutch pressure plate, M7 20 15 Gradually tighten screws crosswise
unverified source
Clutch assembly Clutch slave cylinder 15 11
unverified source
Clutch assembly Clutch slave cylinder 20 15
unverified source
Clutch assembly Clutch slave cylinder bleeder valve 5 4
unverified source
Clutch assembly Release bearing guide sleeve 20 15
unverified source
Flywheel/Flex plate Flywheel 60 44
unverified source
Drive/Axle shaft Front axle drive shaft, M8 40 30 Screws must be replaced
  • Front
 unverified source
Drive/Axle shaft Front axle drive shaft, M10 70 52 Screws must be replaced
  • Front
 unverified source
Drive/Axle shaft Rear axle carrier 90 66 On chassis
  • Rear
 unverified source
Tie rod end Track rod end on stub axle 20 15 First stage
unverified source
Tie rod end Track rod end on track rod 50 37
unverified source
Tie rod end Track rod end on steering gear 100 74
unverified source
Steering rack Steering gear 50 37 Screws must be replaced
unverified source
Steering column Steering column 30 22 Screws must be replaced
unverified source
Steering column Lower steering column joint 30 22 Screws must be replaced
unverified source
Steering wheel Steering wheel 30 22 First stage
unverified source
Exhaust manifold Exhaust manifold 25 18
  • 1.4L Gasoline Engine
  • CAVD
 unverified source
Exhaust manifold Exhaust manifold 30 22 Bottom Nuts
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Exhaust manifold Exhaust manifold 25 18 Top Nuts
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Exhaust manifold Exhaust manifold 16 12
  • 1.4L Gasoline Engine
  • CAXA
 unverified source
Exhaust manifold Exhaust manifold 20 15
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Exhaust manifold Exhaust manifold 25 18
  • 2.0L Diesel Engine
  • CFHC
 unverified source
Exhaust manifold Exhaust manifold 16 12
  • 1.4L Gasoline Engine
  • CMSB
 unverified source
Exhaust manifold Exhaust manifold 25 18
  • 1.4L Gasoline Engine
  • CNWA
 unverified source
Exhaust manifold Exhaust manifold 25 18
  • 1.4L Gasoline Engine
  • CTHS
 unverified source
Exhaust manifold Exhaust manifold 25 18
  • 1.4L Gasoline Engine
  • CTKA
 unverified source
Exhaust manifold Exhaust manifold heat shields 20 15
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Exhaust manifold Exhaust manifold heat shields 25 18
  • 2.0L Diesel Engine
  • CFHC
 unverified source
Turbo Turbocharger coolant feed line 8 6 Sealings rings must be replaced
unverified source
Turbo Turbocharger coolant return line 8 6 Sealings rings must be replaced
unverified source
Turbo Turbocharger oil feed line 30 22 At the turbocharger
  • 1.4L Gasoline Engine
  • CAVD
 unverified source
Turbo Turbocharger oil feed line 20 15 On the engine block
  • 1.4L Gasoline Engine
  • CAVD
 unverified source
Turbo Turbocharger oil feed line 10 7 Support Screws
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Turbo Turbocharger oil feed line 22 16 Union nuts
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Turbo Turbocharger oil feed line 22 16 Union Nuts at turbocharger
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Turbo Turbocharger oil feed line 30 22 Banjo bolts on the engine block
  • 2.0L Diesel Engine
  • CFHC
 unverified source
Turbo Turbocharger oil return line 15 11 At the turbocharger
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Turbo Turbocharger oil return line 60 44 Banjo bolts on the engine block
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Turbo Turbocharger oil return line 20 15 Support on the turbocharger
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Turbo Turbocharger oil return line 17 13 At the turbocharger
  • 2.0L Diesel Engine
  • CFHC
 unverified source
Turbo Turbocharger oil return line 20 15 Support at the turbocharger
  • 2.0L Diesel Engine
  • CFHC
 unverified source
Turbo Turbocharger oil return line 40 30 Banjo bolts on the engine block
  • 2.0L Diesel Engine
  • CFHC
 unverified source
EGR Carburetion - Exhaust gas return cooler 20 15 Second Stage
unverified source
EGR Carburetion - Exhaust gas return cooler 7 5 Clamps
unverified source
EGR Carburetion - Exhaust gas return valve 9 7
unverified source
EGR Exhaust recirculation pipe 24 18 Nuts
  • 2.0L Diesel Engine
  • CFHC
 unverified source
EGR Exhaust recirculation pipe 9 7 Screws
  • 2.0L Diesel Engine
  • CFHC
 unverified source
EGR Exhaust recirculation pipe 20 15 Screws
  • 2.0L Diesel Engine
  • CBDB
 unverified source
Catalytic converter Catalytic converter 40 30 Nuts must be replaced
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Catalytic converter Catalytic converter bracket 23 17
unverified source
Disc brake Front axle brake bleed valve 10 7 Minimum
  • Front
 unverified source
Disc brake Front axle brake bleed valve 12 9 Maximum
  • Front
 unverified source
Disc brake Rear axle brake bleeder valve 10 7
  • Rear
 unverified source
Disc brake Brake calliper 30 22
  • Front
 unverified source
Disc brake Brake calliper 35 26 Screws must be replaced
  • Rear
 unverified source
Disc brake Brake disc 4 3
  • Front
 unverified source
Disc brake Brake disc 4 3
  • Rear
 unverified source
Brake line Brake hose 35 26 At the brake caliper
unverified source
Brake line Brake line 14 10
unverified source
Wheels Cental screws - Bi-hexagon 70 52 With ribbing
  • Front
 unverified source
Wheels Cental screws - Bi-hexagon 200 148 Without ribbing
  • Front
 unverified source
Struts Suspension rod on chassis 15 11 Screws must be replaced
unverified source
Spring Suspension rod on stub axle 70 52 Screws and nuts must be replaced
unverified source
Shock absorbers/shocks Shock-absorber piston rod 65 48
unverified source
Shock absorbers/shocks Rear axle shock absorber 50 37 On chassis
  • Rear
 unverified source
Shock absorbers/shocks Rear axle shock absorber 180 133 On stub axle
  • Rear
 unverified source
Shock absorbers/shocks Rear axle shock absorber piston rod 25 18
  • Rear
 unverified source
Shock absorbers/shocks Connecting rod bearing, M8 30 22
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Shock absorbers/shocks Connecting rod bearing, M9 45 33
  • 2.0L Gasoline Engine
  • CAWB
 unverified source
Shock absorbers/shocks Connecting rod bearing, M7 20 15
  • 2.0L Gasoline Engine
  • CAXA
 unverified source
Shock absorbers/shocks Connecting rod bearing, M8 30 22
  • 2.0L Gasoline Engine
  • CAXA
 unverified source
Shock absorbers/shocks Connecting rod bearing 30 22 First Stage
unverified source
Stabilizer bar Stabiliser mounting at the stabiliser 65 48 Nuts must be replaced
  • Front
 unverified source
Stabilizer bar Stabiliser mounting at the suspension strut 65 48 Nuts must be replaced
  • Front
 unverified source
Stabilizer bar Stabiliser mounting at the subframe 65 48 First stage
  • Front
 unverified source
Stabilizer bar Rear axle stabilizer support at the stabilizer 45 33
  • Rear
 unverified source
Stabilizer bar Rear Axle stabilizer support at the stub axle 40 30
  • Rear
 unverified source
Control arm Aluminium forged tranverse arm 100 74
  • Front
 unverified source
Control arm Cast-iron wishbone 60 44
  • Front
 unverified source
Control arm Support Joint at the transverse control arm from sheet metal 100 74
  • Front
 unverified source
Control arm Lower front transverse control arm 70 52
  • Front
 unverified source
Control arm Lower rear transverse control arm 50 37 At the subframe
  • Front
 unverified source
Control arm Lower rear transverse control arm 70 52 On chassis
  • Front
 unverified source
Control arm Rear axle longitudinal control arm 90 66 At the bearing pedestal
  • Rear
 unverified source
Control arm Rear axle longitudinal control arm 50 37 Bearing pedestal on chassis
  • Rear
 unverified source
Control arm Rear axle stabilizer mounting 90 66 On stub axle
  • Rear
 unverified source
Control arm Lower track control arm 95 70 At the axle support
  • Rear
 unverified source
Control arm Lower track control arm 90 66 On the stub axle
  • Rear
 unverified source
Control arm Upper track control arm 95 70 At the axle support
  • Rear
 unverified source
Control arm Upper track control arm 130 96 On the stub axle
  • Rear
 unverified source

drivetrain torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

steering torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

exhaust torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

brakes torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

suspension torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

general torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Example of a Scirocco 3

By Kārlis Dambrāns from Latvia - Volkswagen Scirocco 2008 67, CC BY 2.0


Did you find the answer to your specific question?
👍 0 👎 1

Related Vans:
