Chevrolet Camaro 6 (2016-2024) Torque Spec Settings
By Kevauto - Own work, CC BY-SA 4.0
Below you'll find the tightening torques for the Chevrolet Camaro 6 in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.
Most-used torque specs for Chevrolet Camaro 6
| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Oil pan | Oil pan drain plug | 25 | 18 |
|
|
|
| Belt tensioner/Timing chains | Drive belt tensioner bolt | 58 | 43 |
|
|
|
| Differential | Drain plug | 45 | 33 |
|
|
|
| Wheels | Wheel nuts | 190 | 140 |
|
|
To make sure these are the correct tightening torque values, you can use the data below to verify this is the right model.
Are these torque settings right for you?
- Production years: 2016 - 2024
- Generation: 6
- Type of van: car
- Model variant: Base
- Also known as:
All Torque Settings in Tables
engine torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Oil pan | Oil pan drain plug | 25 | 18 |
|
|
|
| Oil pan | Oil pan bolt | 10 | 7 | Long |
|
|
| Oil pan | Oil pan bolt - Perimeter | 25 | 18 |
|
|
|
| Oil pan | Lower oil pan bolt | 10 | 7 |
|
|
|
| Oil pan | Oil pan baffle bolt | 10 | 7 |
|
|
|
| Oil pressure switch | Engine oil pressure sensor | 35 | 26 |
|
|
|
| Oil dipstick | Engine oil level indicator switch bolt | 10 | 7 |
|
|
|
| Oil feeder | Piston oil nozzle bolt | 10 | 7 |
|
|
|
| Oil pump | Oil pump suction pipe bolt | 10 | 7 |
|
|
|
| Oil pump | Oil pump flow control valve bolt | 10 | 7 |
|
|
|
| Vacuum pump | Vacuum pump bolt | 10 | 7 |
|
|
|
| Piston rods | Connecting rod bolt | 25 | 18 | First pass |
|
|
| Cylinder head | Cylinder head core hole plug | 50 | 37 |
|
|
|
| Cylinder head | Cylinder head oil gallery plug | 40 | 30 |
|
|
|
| Cylinder head | Cylinder head bolt | 30 | 22 | First pass |
|
|
| Spark plugs | Spark plug | 20 | 15 |
|
|
|
| Intake manifold | Intake manifold bolt | 12 | 9 |
|
|
|
| Intake manifold | Intake manifold cover bolt | 9 | 7 |
|
|
|
| Throttle body | Throttle body bolt | 10 | 7 |
|
|
|
| Engine block | Engine block oil gallery plug - Large, left side and rear engine block | 65 | 48 |
|
|
|
| Engine block | Engine block oil gallery plug - Large, left side lower crankcase | 65 | 48 |
|
|
|
| Engine block | Engine block oil gallery plug - Small, rear engine block | 40 | 30 |
|
|
|
| Engine block | PCV valve bolt | 10 | 7 |
|
|
|
| Engine mounts | Engine mount fastener | 58 | 43 | First pass |
|
|
| Engine mounts | Engine front cover bolt | 10 | 7 | M6 bolt |
|
|
| Engine mounts | Engine front cover bolt | 25 | 18 | M8 bolt |
|
|
| Engine mounts | Engine front cover bolt | 58 | 43 | M10 bolt |
|
|
| Engine mounts | Engine front cover bolt | 15 | 11 | M10 bolt, New fastener, First pass |
|
|
| Sensor | Camshaft position sensor bolt | 10 | 7 |
|
|
|
| Sensor | Crankshaft position sensor bolt | 10 | 7 |
|
|
|
| Sensor | Knock sensor bolt | 25 | 18 |
|
|
|
| Sensor | Manifold Absolute Pressure (MAP) sensor bolt | 5 | 4 |
|
|
|
| Sensor | Heated oxygen sensor (HO2S) | 42 | 31 |
|
|
|
| Alternator | Generator mounting bolt | 22 | 16 |
|
|
|
| Starter | Starter motor mounting bolt | 58 | 43 |
|
|
|
| Starter | Starter solenoid cable bolt (Engine block ground) | 40 | 30 |
|
|
|
| Battery | Ignition coil bolt | 10 | 7 |
|
|
|
| Camshaft | Camshaft bearing cap bolt | 10 | 7 |
|
|
|
| Camshaft | Camshaft cover bolt | 10 | 7 |
|
|
|
| Camshaft | Camshaft cover heat shield bolt | 10 | 7 |
|
|
|
| Camshaft | Camshaft cover opening plug | 35 | 26 |
|
|
|
| Camshaft | Camshaft position actuator bolt | 30 | 22 |
|
|
|
| Camshaft | Camshaft position actuator solenoid valve bolt | 10 | 7 |
|
|
|
| Crankshaft | Lower crankcase bolt - Crankshaft bearing | 20 | 15 | First pass |
|
|
| Crankshaft | Lower crankcase bolt - Perimeter | 25 | 18 |
|
|
|
| Crankshaft | Crankshaft balancer bolt | 150 | 111 | First pass |
|
|
| Crankshaft | Balancer shaft driven sprocket bolt | 40 | 30 | First pass |
|
|
| Crankshaft | Balancer shaft housing bolt | 58 | 43 | First pass |
|
|
| Crankshaft | Balancer shaft housing bolt | 58 | 43 | Second pass |
|
|
| Crankshaft | Balancer chain guide bolt | 10 | 7 |
|
|
|
| Crankshaft | Balancer chain tensioner bolt | 10 | 7 |
|
|
|
| Water pump | Water pump fastener | 25 | 18 |
|
|
|
| Water pump | Water pump housing bolt | 10 | 7 |
|
|
|
| Heater core | Coolant heater | 50 | 37 |
|
|
|
| Heater core | Coolant heater cord fastener | 10 | 7 |
|
|
|
| Heater core | Engine coolant heater fastener | 50 | 37 |
|
|
|
| Fuel/Oil cooler | Auxiliary engine oil cooler | 10 | 7 |
|
|
|
| Fuel/Oil cooler | Engine oil cooler adapter | 50 | 37 |
|
|
|
| Fuel/Oil cooler | Engine oil cooler adapter fastener to Engine block | 58 | 43 |
|
|
|
| Fuel/Oil cooler | Engine oil cooler bolt | 10 | 7 |
|
|
|
| Fuel/Oil cooler | Engine oil cooler pipe fastener | 10 | 7 |
|
|
|
| Intercooler | Charge air cooler radiator fasteners | 10 | 7 |
|
|
|
| Coolant expansion tank | Radiator surge tank fastener | 6 | 4 |
|
|
|
| Radiator | Radiator inlet pipe fastener | 10 | 7 |
|
|
|
| Radiator | Radiator upper bracket fastener | 9 | 7 |
|
|
|
| Radiator | Fan control module fastener | 8 | 6 |
|
|
|
| Radiator | Engine coolant thermostat housing fastener | 10 | 7 |
|
|
|
| Radiator | Engine coolant thermostat heater shield | 5 | 4 |
|
|
|
| Radiator | Water outlet fastener | 12 | 9 |
|
|
|
| Belt tensioner/Timing chains | Drive belt tensioner bolt | 58 | 43 |
|
|
|
| Belt tensioner/Timing chains | Timing chain cover bolt - Engine front cover | 5 | 4 |
|
|
|
| Belt tensioner/Timing chains | Timing chain guide bolt | 25 | 18 |
|
|
|
| Belt tensioner/Timing chains | Timing chain tensioner pivot arm bolt | 25 | 18 |
|
|
|
| Belt tensioner/Timing chains | Timing chain tensioner shoe bolt | 25 | 18 |
|
|
|
| PCM | Engine control module bracket fastener | 7 | 5 |
|
|
|
| Fuel system | Fuel feed intermediate pipe nut to Fuel rail | 15 | 11 | First pass |
|
|
| Fuel system | Fuel feed intermediate pipe nut to Fuel pump | 15 | 11 | Second pass |
|
|
| Fuel system | Fuel feed intermediate pipe nut to Fuel rail | 30 | 22 | Third pass |
|
|
| Fuel system | Fuel feed intermediate pipe nut to Fuel pump | 30 | 22 | Final pass |
|
|
| Fuel system | Fuel feed pipe | 30 | 22 |
|
|
|
| Fuel system | Fuel feed pipe clip stud | 10 | 7 |
|
|
|
| Fuel system | Fuel injection fuel rail bolt | 25 | 18 |
|
|
|
| Fuel system | Fuel injection fuel rail fuel pressure sensor | 33 | 24 |
|
|
|
| Fuel system | Fuel pump fasteners | 15 | 11 |
|
|
|
| Fuel system | Fuel pump shield bolt | 10 | 7 |
|
|
|
| Fuel system | Fuel pump cover fasteners | 10 | 7 |
|
|
|
| Fuel system | Fuel pump flow control module fastener | 7 | 5 |
|
|
|
| Fuel system | Fuel tank fill pipe bracket bolt | 9 | 7 |
|
|
|
| Fuel system | Fuel tank strap bolt | 20 | 15 |
|
|
drivetrain torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Flywheel/Flex plate | Automatic transmission flexplate bolt | 30 | 22 | First pass |
|
|
| Flywheel/Flex plate | Flywheel bolt | 30 | 22 | First pass |
|
|
| Transmission fluid pan | Transmission fluid cooler pipe clip bolt (Transmission connection interface) | 22 | 16 |
|
|
|
| Transmission fluid pan | Transmission fluid cooler pipe nut (Pipe retaining points along vehicle) | 9 | 7 |
|
|
|
| Transmission fluid pan | Transmission fluid cooler pipe stud (Pipe retaining point) | 22 | 16 |
|
|
steering torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to |
|---|
exhaust torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Exhaust manifold | Exhaust manifold brace | 25 | 18 |
|
|
|
| Exhaust manifold | Exhaust manifold fasteners | 20 | 15 | First pass |
|
|
| Exhaust manifold | Exhaust manifold fasteners | 20 | 15 | Second pass |
|
|
| Exhaust manifold | Exhaust manifold fasteners | 20 | 15 | Final pass |
|
|
| Exhaust manifold | Exhaust manifold heat shield fasteners | 14 | 10 |
|
|
|
| Turbo | Turbocharger exhaust pipe stud | 25 | 18 |
|
|
|
| Turbo | Turbocharger nut | 30 | 22 |
|
|
|
| Turbo | Turbocharger oil feed pipe bolt | 35 | 26 |
|
|
|
| Turbo | Turbocharger oil feed and return pipe bolt | 10 | 7 |
|
|
|
| Turbo | Turbocharger coolant feed pipe banjo bolt | 35 | 26 |
|
|
|
| Turbo | Turbocharger coolant feed pipe fasteners | 10 | 7 |
|
|
|
| Turbo | Turbocharger coolant return pipe banjo bolt | 35 | 26 |
|
|
|
| Turbo | Turbocharger coolant return pipe fasteners | 10 | 7 |
|
|
|
| Catalytic converter | Catalytic converter brace | 22 | 16 |
|
|
|
| Catalytic converter | Catalytic converter nut to Exhaust manifold | 50 | 37 |
|
|
|
| Catalytic converter | Catalytic converter to Turbocharger fasteners | 50 | 37 |
|
|
brakes torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Brake pedal | Accelerator pedal bolt | 9 | 7 |
|
|
suspension torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to |
|---|
general torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to |
|---|
By Kevauto - Own work, CC BY-SA 4.0
