Ford Maverick (2022-on) Torque Spec Settings

By MercurySable99 - Own work, CC BY-SA 4.0,

Below you'll find the tightening torques for the Ford Maverick in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.

Most-used torque settings for Ford Maverick

Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Spark plugs Spark plugs 12 9
  • 2.0L EcoBoost Engine
 unverified source
Tie rod end Front tie rod end nut 48 35
  • 2.0L EcoBoost Engine
 unverified source
Wheels Wheel nuts 204 150
  • 2.0L EcoBoost Engine
 unverified source

Are these torque settings right for you?

  • Production years: 2022 - present
  • Type of van: pickup
  • Model variant: Base

All Torque Settings in Tables

engine torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil pan drain bolt 27 20
  • 2.0L EcoBoost Engine
 unverified source
Oil pan Oil pan bolts 25 18
  • 2.0L EcoBoost Engine
 unverified source
Oil filter Engine oil filter 8 6 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Oil pressure switch Oil pressure sensor 12 9
  • 2.0L EcoBoost Engine
 unverified source
Cylinder head Cylinder head bolts 7 5 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Cylinder head Cylinder head bolts 15 11 Stage 2
  • 2.0L EcoBoost Engine
 unverified source
Cylinder head Cylinder head bolts 55 41 Stage 3
  • 2.0L EcoBoost Engine
 unverified source
Cylinder head Upper cylinder head studs 18 13
  • 2.0L EcoBoost Engine
 unverified source
Spark plugs Spark plugs 12 9
  • 2.0L EcoBoost Engine
 unverified source
Piston rods Connecting rod caps 20 15 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Piston rods Connecting rod caps 40 30 Stage 2
  • 2.0L EcoBoost Engine
 unverified source
Intake manifold Intake manifold bolts 25 18
  • 2.0L EcoBoost Engine
 unverified source
Engine block Main bearing beam bolts 5 4 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Engine block Main bearing beam bolts 25 18 Stage 2
  • 2.0L EcoBoost Engine
 unverified source
Engine mounts Engine mount bolts 175 129
  • 2.0L EcoBoost Engine
 unverified source
Engine mounts Engine mount studs 12 9
  • 2.0L EcoBoost Engine
 unverified source
Engine mounts Engine mount nuts 110 81
  • 2.0L EcoBoost Engine
 unverified source
Engine mounts Engine front cover fasteners 48 35 Bolts 1-3
  • 2.0L EcoBoost Engine
 unverified source
Engine mounts Engine front cover fasteners 11 8 Bolts 4 - 22
  • 2.0L EcoBoost Engine
 unverified source
Knock sensor Knock sensor 25 18
  • 2.0L EcoBoost Engine
 unverified source
Camshaft Camshaft caps bolts 7 5 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Camshaft Camshaft caps bolts 16 12 Stage 2
  • 2.0L EcoBoost Engine
 unverified source
Water pump Coolant pump bolts 10 7
  • 2.0L EcoBoost Engine
 unverified source
Water pump Coolant pump pulley bolts 25 18
  • 2.0L EcoBoost Engine
 unverified source
Belt tensioner Accessory drive belt tensioner bolts 25 18
  • 2.0L EcoBoost Engine
 unverified source
Belt tensioner Timing chain tensioner bolts 11 8
  • 2.0L EcoBoost Engine
 unverified source
Valve cover Valve cover fasteners 11 8
  • 2.0L EcoBoost Engine
 unverified source

drivetrain torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Wheel hub assembly Front wheel hub nut 103 76 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Wheel hub assembly Rear wheel hub nut 133 98
  • 2.0L EcoBoost Engine
 unverified source
Wheel hub assembly Rear wheel bearing and wheel hub 110 81
  • 2.0L EcoBoost Engine
 unverified source
Transmission fluid pan Transmission fluid drain plug 14 10
  • 2.0L EcoBoost Engine
  • 8F35 Automatic Transmission
 unverified source
Transmission fluid pan Oil pan to Transmission bolt 48 35
  • 2.0L EcoBoost Engine
 unverified source
Transmission mount Transmission to Engine bolts 48 35
  • 2.0L EcoBoost Engine
  • 8F35 Automatic Transmission
 unverified source
Transmission mount Top transmission to Engine bolts 48 35
  • 2.0L EcoBoost Engine
  • 8F35 Automatic Transmission
 unverified source
Transmission mount Lower transmission to Engine bolts 48 35
  • 2.0L EcoBoost Engine
  • 8F35 Automatic Transmission
 unverified source

steering torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Tie rod end Front tie rod end nut 48 35
  • 2.0L EcoBoost Engine
 unverified source
Tie rod end Tie rod end jam nut 90 66
  • 2.0L EcoBoost Engine
 unverified source
Steering knuckle Rear wheel knuckle bolts 133 98 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Steering rack Steering gear retainers 70 52 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Steering column Steering column shaft bolt 63 46
  • 2.0L EcoBoost Engine
 unverified source
Steering shaft Steering column intermediate shaft 48 35 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Steering shaft Steering shaft coupler retainer 55 41
  • 2.0L EcoBoost Engine
 unverified source
Steering wheel Steering wheel retainer 48 35
  • 2.0L EcoBoost Engine
 unverified source

exhaust torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

brakes torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Brake caliper Front brake caliper guide pin bolts 28 21
  • 2.0L EcoBoost Engine
 unverified source
Brake caliper Rear brake caliper guide pin bolts 28 21
  • 2.0L EcoBoost Engine
 unverified source
Brake caliper Front brake caliper anchor plate bolts 110 81
  • 2.0L EcoBoost Engine
 unverified source
Brake caliper Rear brake caliper anchor plate bolts 63 46
  • 2.0L EcoBoost Engine
 unverified source

suspension torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Wheels Wheel nuts 204 150
  • 2.0L EcoBoost Engine
 unverified source
Struts Front strut and spring assembly upper bolts 30 22
  • 2.0L EcoBoost Engine
 unverified source
Struts Front strut and spring assembly to Wheel knuckle bolts and nuts 140 103 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Struts Front strut rod nut 55 41
  • 2.0L EcoBoost Engine
 unverified source
Shock absorbers/shocks Rear shock absorber upper bolts 110 81
  • 2.0L EcoBoost Engine
 unverified source
Shock absorbers/shocks Rear lower shock absorber bolt and nut 110 81
  • 2.0L EcoBoost Engine
 unverified source
Stabilizer bar Front stabilizer bar bracket bolts 63 46
  • 2.0L EcoBoost Engine
 unverified source
Stabilizer bar Rear stabilizer bar bracket bolts 63 46
  • 2.0L EcoBoost Engine
 unverified source
Sway bar links/Stabilizer links Front stabilizer bar link upper nut 110 81
  • 2.0L EcoBoost Engine
 unverified source
Sway bar links/Stabilizer links Rear stabilizer link upper nut 115 85
  • 2.0L EcoBoost Engine
 unverified source
Sway bar links/Stabilizer links Front stabilizer bar link lower nut 115 85
  • 2.0L EcoBoost Engine
 unverified source
Sway bar links/Stabilizer links Rear stabilizer link lower nut 115 85
  • 2.0L EcoBoost Engine
 unverified source
Control arm Rear upper arm to Wheel knuckle bolt 90 66 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Control arm Rear upper arm to Frame bolt 90 66 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Control arm Front lower arm bolts and nut 140 103 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Control arm Rear suspension front lower arm to Wheel knuckle bolt 90 66 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Control arm Rear lower arm to Wheel knuckle bolt and nut 110 81 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Control arm Rear suspension front lower arm to Frame bolt 90 66 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Control arm Front rearward lower arm bolt and nut 133 98 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Control arm Rear rearward lower arm adjustment cam to Crossmember bolt and nut 18 13 Stage 1
  • 2.0L EcoBoost Engine
 unverified source
Control arm Rear rearward lower arm adjustment cam to Crossmember bolt and nut 150 111 Stage 2
  • 2.0L EcoBoost Engine
 unverified source
Ball joint Front ball joint pinch bolt and nut 110 81
  • 2.0L EcoBoost Engine
 unverified source

general torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
