Ford Super Duty 3 (2011-2016) Torque Spec Settings

Below you'll find the tightening torques for the Ford Super Duty 3 in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.

Most-used torque specs for Ford Super Duty 3

Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil pan drain plug 23 17
  • 6.2L Engine
 unverified source
Oil pan Oil pan drain plug 26 19
  • 6.7L Engine
 unverified source
Oil pan Oil pan drain plug 14 10
  • 6.8L Engine
 unverified source
Oil filter Oil filter 16 12
  • 6.2L Engine
 unverified source
Oil filter Oil filter 16 12
  • 6.8L Engine
 unverified source
Spark plugs Spark plugs 12 9
  • 6.8L Engine
 unverified source
Glow plugs Glow plug 11 8
  • 6.7L Engine
 unverified source
Disc brake Front brake caliper bolts 76 56
  • F-250
 unverified source
Disc brake Front brake caliper bolts 76 56
  • F-350
 unverified source
Disc brake Front brake caliper bolts 63 46
  • F-450
 unverified source
Disc brake Front brake caliper bolts 63 46
  • F-550
 unverified source
Disc brake Rear brake caliper bolts 35 26
  • F-250
  • SRW
 unverified source
Disc brake Rear brake caliper bolts 35 26
  • F-350
  • SRW
 unverified source
Disc brake Rear brake caliper bolts 76 56
  • F-350
  • DRW
 unverified source
Disc brake Rear brake caliper bolts 62 46
  • F-450
 unverified source
Disc brake Rear brake caliper bolts 62 46
  • F-550
 unverified source
Wheels Wheel nuts 224 165
  • SRW
  • DRW
 unverified source

Are these torque settings right for you?

  • Production years: 2011 - 2016
  • Generation: 3
  • Type of van: pickup
  • Also known as: F-250 F-350 F-450 F-550

All Torque Settings in Tables

engine torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil pan drain plug 23 17
  • 6.2L Engine
 unverified source
Oil pan Oil pan drain plug 26 19
  • 6.7L Engine
 unverified source
Oil pan Oil pan drain plug 14 10
  • 6.8L Engine
 unverified source
Oil pan Oil pan bolts 2 1 Stage 1
  • 6.2L Engine
 unverified source
Oil pan Oil pan bolts 10 7 Stage 2
  • 6.2L Engine
 unverified source
Oil pan Lower oil pan bolts 10 7
  • 6.7L Engine
 unverified source
Oil pan Upper oil pan bolts 2 1 Stage 1
  • 6.7L Engine
 unverified source
Oil pan Upper oil pan bolts 24 18 Stage 2
  • 6.7L Engine
 unverified source
Oil pan Oil pan bolts 2 1 Stage 1
  • 6.8L Engine
 unverified source
Oil pan Oil pan bolts 20 15 Stage 2
  • 6.8L Engine
 unverified source
Oil filter Oil filter 16 12
  • 6.2L Engine
 unverified source
Oil filter Oil filter 16 12
  • 6.8L Engine
 unverified source
Oil filter Engine oil filter 5 4 Turbocharger
unverified source
Oil filter Oil filter adapter bolts 25 18
  • 6.2L Engine
 unverified source
Oil filter Oil filter adapter bolts 10 7
  • 6.7L Engine
 unverified source
Oil filter Oil filter adapter bolts 25 18
  • 6.8L Engine
 unverified source
Oil filter Oil filter adapter nut 48 35
  • 6.8L Engine
 unverified source
Oil filter Oil filter adapter stud bolt 10 7
  • 6.7L Engine
 unverified source
Oil filter Oil filter adapter stud 12 9
  • 6.8L Engine
 unverified source
Oil filter Crankcase vent oil separator bolts 10 7
  • 6.7L Engine
 unverified source
Oil filter Crankcase vent oil separator stud bolts 10 7
  • 6.7L Engine
 unverified source
Oil pressure switch EOP switch 14 10 Stage 1
  • 6.2L Engine
 unverified source
Oil pressure switch Engine Oil Pressure (EOP) switch 20 15
  • 6.7L Engine
 unverified source
Oil pressure switch Engine Oil Pressure (EOP) switch 18 13
  • 6.8L Engine
 unverified source
Oil dipstick Oil level indicator tube bolt 10 7
  • 6.2L Engine
 unverified source
Oil dipstick Oil level indicator tube bolt 10 7
  • 6.7L Engine
 unverified source
Oil dipstick Front oil level indicator tube bolt 25 18
  • 6.8L Engine
 unverified source
Oil dipstick Rear oil level indicator tube bolt 10 7
  • 6.8L Engine
 unverified source
Oil feeder Oil fill pipe bolt 10 7
  • 6.7L Engine
 unverified source
Oil pump Oil pump bolts 2 1 Stage 1
  • 6.2L Engine
 unverified source
Oil pump Oil pump bolts 10 7 Stage 2, Upper bolts
  • 6.2L Engine
 unverified source
Oil pump Oil pump bolts 20 15 Stage 3, Lower stud bolts
  • 6.2L Engine
 unverified source
Oil pump Oil pump bolts 10 7
  • 6.8L Engine
 unverified source
Oil pump Oil pump screen and pickup tube bolts 10 7
  • 6.2L Engine
 unverified source
Oil pump Oil pump screen and pickup tube bolts 10 7
  • 6.7L Engine
 unverified source
Oil pump Oil pump screen and pickup tube nut 24 18
  • 6.2L Engine
 unverified source
Oil pump Oil pump screen and pickup tube spacer 25 18
  • 6.8L Engine
 unverified source
Oil pump Oil pump screen and pickup tube to Oil pump bolts 10 7
  • 6.8L Engine
 unverified source
Oil pump Oil pump screen and pickup tube to Spacer bolt 25 18
  • 6.8L Engine
 unverified source
Vacuum pump Vacuum pump bolts 10 7
  • 6.7L Engine
 unverified source
Piston rods Connecting rod bolts 20 15 Stage 1
  • 6.2L Engine
 unverified source
Piston rods Connecting rod bolts 43 32 Stage 2
  • 6.2L Engine
 unverified source
Piston rods Connecting rod cap bolts 45 33 Stage 1
  • 6.7L Engine
 unverified source
Piston rods Connecting rod bolts 43 32 Stage 1
  • 6.8L Engine
 unverified source
Cylinder head LH cylinder head bolts 25 18 Stage 1, M12 fasteners
  • 6.2L Engine
 unverified source
Cylinder head LH cylinder head bolts 60 44 Stage 2, M12 fasteners
  • 6.2L Engine
 unverified source
Cylinder head LH cylinder head bolts 20 15 Stage 5, M8 fastener
  • 6.2L Engine
 unverified source
Cylinder head RH cylinder head bolts 25 18 Stage 1, M12 fasteners
  • 6.2L Engine
 unverified source
Cylinder head RH cylinder head bolts 60 44 Stage 2, M12 fasteners
  • 6.2L Engine
 unverified source
Cylinder head Cylinder head bolts 20 15 Stage 1, Bolts 1 through 18
  • 6.7L Engine
 unverified source
Cylinder head Cylinder head bolts 49 36 Stage 2, Bolts 1 through 18
  • 6.7L Engine
 unverified source
Cylinder head Cylinder head bolts 49 36 Stage 3, Bolts 1 through 18
  • 6.7L Engine
 unverified source
Cylinder head Cylinder head bolts 49 36 Stage 4, Bolts 1 through 18
  • 6.7L Engine
 unverified source
Cylinder head Cylinder head bolts 30 22 Stage 8, Bolts 19 through 22
  • 6.7L Engine
 unverified source
Cylinder head Cylinder head bolts 40 30 Stage 1
  • 6.8L Engine
 unverified source
Spark plugs Spark plug 12 9
  • 6.2L Engine
 unverified source
Spark plugs Spark plugs 12 9
  • 6.8L Engine
 unverified source
Glow plugs Glow plug 11 8
  • 6.7L Engine
 unverified source
Glow control unit Glow plug module bolts 5 4
  • 6.7L Engine
 unverified source
Intake manifold Intake manifold bolts 10 7 Stage 1
  • 6.2L Engine
 unverified source
Intake manifold Lower intake manifold bolts 24 18
  • 6.7L Engine
 unverified source
Intake manifold Upper intake manifold bolts 10 7
  • 6.7L Engine
 unverified source
Intake manifold Intake manifold bolts 2 1 Stage 1
  • 6.8L Engine
 unverified source
Intake manifold Intake manifold bolts 10 7 Stage 2
  • 6.8L Engine
 unverified source
Intake manifold Intake Manifold Runner Control (IMRC) 10 7
  • 6.8L Engine
 unverified source
Throttle body Air Cleaner (ACL) outlet pipe to Throttle Body (TB) adapter bolts 10 7
  • Gasoline Engines
 unverified source
Throttle body TB bolts 12 9
  • 6.2L Engine
 unverified source
Throttle body TB bolts 10 7
  • 6.7L Engine
 unverified source
Throttle body TB bolts 9 7 Stage 1
  • 6.8L Engine
 unverified source
Throttle body TB adapter to TB bolts 10 7
  • 6.2L Engine
 unverified source
Throttle body TB adapter to TB clamp 5 4
  • 6.2L Engine
 unverified source
Throttle body TB spacer lower bolts 9 7 Stage 1
  • 6.8L Engine
 unverified source
Throttle body Upper TB spacer bolts 9 7 Stage 1
  • 6.8L Engine
 unverified source
Engine block Block heater 41 30
  • Diesel Engine
 unverified source
Engine block Block heater retaining screw 4 3
  • Gasoline Engines
 unverified source
Engine block Cylinder block drain plug 60 44
  • Diesel Engine
 unverified source
Engine block Cylinder block drain plug 24 18
  • 6.8L Engine
 unverified source
Engine mounts LH engine mount nuts 172 127
unverified source
Engine mounts LH engine mount nuts 115 85
unverified source
Engine mounts Engine front cover fasteners 10 7 Stage 1
  • 6.2L Engine
 unverified source
Engine mounts Engine front cover fasteners 20 15 Stage 2
  • 6.2L Engine
 unverified source
Engine mounts Engine front cover bolts 24 18
  • 6.7L Engine
 unverified source
Engine mounts Engine front cover fasteners 25 18 Stage 1, Fasteners 1 through 5
  • 6.8L Engine
 unverified source
Engine mounts Engine front cover fasteners 48 35 Stage 2, Fasteners 6 and 7
  • 6.8L Engine
 unverified source
Engine mounts Engine front cover fasteners 25 18 Stage 3, Fasteners 8 through 15
  • 6.8L Engine
 unverified source
Engine mounts Engine rear cover bolts 10 7 Stage 1
  • 6.7L Engine
 unverified source
Engine mounts Engine rear cover bolts 48 35 Stage 2
  • 6.7L Engine
 unverified source
Sensor Front wheel speed sensor bolt 25 18
  • RWD
 unverified source
Sensor Front wheel speed sensor bolt 18 13
  • 4WD
 unverified source
Sensor Rear wheel speed sensor bolt 20 15 Four channel
unverified source
Sensor Rear wheel speed sensor bolt 20 15 Three channel
unverified source
Sensor Output Shaft Speed (OSS) sensor bolt 9 7
  • TorqShift Automatic Transmission
 unverified source
Sensor Output Shaft Speed (OSS) sensor bolt 11 8
  • TorqShift 6 Automatic Transmission
 unverified source
Sensor Turbine Shaft Speed (TSS) and intermediate shaft speed sensor bolt 9 7
  • TorqShift Automatic Transmission
 unverified source
Sensor Turbine Shaft Speed (TSS) sensor bolt 11 8
  • TorqShift 6 Automatic Transmission
 unverified source
Sensor Camshaft Position (CMP) sensor bolt 10 7
  • Diesel Engine
 unverified source
Sensor Camshaft Position (CMP) sensor 10 7
  • Gasoline Engines
 unverified source
Sensor Crankshaft Position (CKP) sensor bolt 10 7
  • Diesel Engine
 unverified source
Sensor Crankshaft Position (CKP) sensor 10 7
  • Gasoline Engines
 unverified source
Sensor Diesel Particulate Filter (DPF) pressure sensor bolt 20 15
  • Diesel Engine
 unverified source
Sensor Engine Oil Temperature (EOT) sensor 20 15
  • Diesel Engine
 unverified source
Sensor Engine Coolant Temperature (ECT) sensor 27 20
  • Diesel Engine
 unverified source
Sensor Engine Coolant Temperature (ECT) 2 sensor 18 13
  • Diesel Engine
 unverified source
Sensor Exhaust Pressure (EP) sensor 20 15
  • Diesel Engine
 unverified source
Sensor Exhaust Gas Temperature (EGT) sensor 30 22
  • Diesel Engine
 unverified source
Sensor Fuel Rail Pressure (FRP) sensor 70 52
  • Diesel Engine
 unverified source
Sensor Fuel temperature sensor 21 15
  • Diesel Engine
 unverified source
Sensor Manifold Absolute Pressure (MAP) sensor 5 4
  • Diesel Engine
 unverified source
Sensor Mass Air Flow (MAF) sensor bolt 2 1
  • Diesel Engine
 unverified source
Sensor Mass Air Flow (MAF) sensor bolts 2 1
  • Gasoline Engines
 unverified source
Sensor Nitrogen Oxides (NOx) sensor 50 37
  • Diesel Engine
 unverified source
Sensor Nitrogen Oxides (NOx) sensor module bolts 25 18
  • Diesel Engine
 unverified source
Sensor Cylinder Head Temperature (CHT) sensor 11 8
  • 6.2L Engine
 unverified source
Sensor Cylinder Head Temperature (CHT) sensor 10 7
  • 6.8L Engine
 unverified source
Sensor Heated Oxygen Sensor (HO2S) 46 34
  • Gasoline Engines
 unverified source
Sensor Knock Sensor (KS) 20 15
  • Gasoline Engines
 unverified source
Sensor TP sensor bolts 3 2
  • 6.8L Engine
 unverified source
Alternator Generator bolts 47 35
  • 6.2L Engine
 unverified source
Alternator Generator mounting bolts 48 35
  • 6.7L Engine
 unverified source
Alternator Generator bolts 25 18
  • 6.8L Engine
 unverified source
Alternator Generator support bracket bolts 20 15 Stage 1
  • 6.2L Engine
 unverified source
Alternator Generator top bracket mounting bolts 10 7
  • 6.8L Engine
 unverified source
Alternator Generator B+ terminal nut 17 13
unverified source
Starter Starter solenoid positive cable terminal nut 12 9
  • Diesel Engine
 unverified source
Starter Starter motor ground cable nut 25 18
  • Gasoline Engines
 unverified source
Starter Starter solenoid wire terminal nut 5 4
  • Diesel Engine
 unverified source
Starter Starter solenoid B-terminal nut 12 9
  • Gasoline Engines
 unverified source
Starter Starter solenoid S-terminal nut 5 4
  • Gasoline Engines
 unverified source
Starter Starter motor upper bolts 25 18
  • Diesel Engine
 unverified source
Starter Starter motor lower bolt 25 18
  • Diesel Engine
 unverified source
Starter Starter motor mounting bolt 25 18
  • Gasoline Engines
 unverified source
Starter Starter motor mounting stud bolt 25 18
  • Gasoline Engines
 unverified source
Starter Starter wiring harness support bracket nut 10 7
  • 6.2L Engine
 unverified source
Starter Starter harness retainer bracket nut 12 9
  • 6.7L Engine
 unverified source
Starter Starter harness ground bolt 25 18
  • 6.7L Engine
 unverified source
Battery Battery ground cable to Starter eyelet nut 25 18
  • Gasoline Engines
 unverified source
Battery Battery ground cable to Engine block bolt 25 18
unverified source
Battery Battery ground cable to Frame bracket bolt 30 22
unverified source
Battery Battery ground cable to Frame bolt 30 22
unverified source
Battery Battery hold down clamp nuts 4 3
unverified source
Battery Battery tray bolts 25 18 Primary
unverified source
Battery Battery tray bolts 18 13 Secondary
unverified source
Battery Battery cable bracket bolts 12 9
  • Diesel Engine
 unverified source
Battery Front engine cover battery ground cable bracket nut 40 30
  • Gasoline Engines
 unverified source
Battery Positive battery cable to Engine bracket nut 12 9
  • Diesel Engine
 unverified source
Battery Positive battery cable to Engine harness retainer nuts 12 9
  • Diesel Engine
 unverified source
Battery Pressure line bracket to Battery cable shield bolt 5 4
unverified source
Battery Secondary battery ground cable to Engine terminal bolt 25 18
  • Diesel Engine
 unverified source
Battery Secondary battery harness retainer bolt 12 9
  • Diesel Engine
 unverified source
Battery Secondary battery harness retainer nut 12 9
  • Diesel Engine
 unverified source
Battery Ignition coil-on-plug bolts 10 7
  • 6.2L Engine
 unverified source
Battery Ignition coil-on-plug bolts 6 4
  • 6.8L Engine
 unverified source
Camshaft Camshaft bearing caps bolts 6 4 Stage 1
  • 6.2L Engine
 unverified source
Camshaft Camshaft bearing cap bolts 8 6 Stage 1
  • 6.8L Engine
 unverified source
Camshaft Camshaft phaser and sprocket bolts 9 7 Stage 1
  • 6.2L Engine
 unverified source
Camshaft Camshaft sprocket bolt 40 30 Stage 1
  • 6.8L Engine
 unverified source
Camshaft Camshaft gear bolt 20 15 Stage 1
  • 6.7L Engine
 unverified source
Camshaft Camshaft thrust plate bolts 25 18
  • 6.7L Engine
 unverified source
Camshaft Variable Camshaft Timing (VCT) solenoid bolts 10 7 Stage 1
  • 6.2L Engine
 unverified source
Crankshaft Camshaft bearing caps bolts 175 129 Stage 1
  • 6.2L Engine
 unverified source
Crankshaft Crankshaft pulley bolts 30 22 Stage 1
  • 6.7L Engine
 unverified source
Crankshaft Crankshaft pulley bolt 90 66 Stage 1
  • 6.8L Engine
 unverified source
Crankshaft Crankshaft pulley bolt 50 37 Stage 1
  • 6.8L Engine
 unverified source
Crankshaft Vertical outer main bearing cap fasteners 35 26 Stage 1
  • 6.2L Engine
 unverified source
Crankshaft Vertical outer main bearing cap fasteners 50 37 Stage 2
  • 6.2L Engine
 unverified source
Crankshaft Vertical inner main bearing cap fasteners 35 26 Stage 1
  • 6.2L Engine
 unverified source
Crankshaft Vertical inner main bearing cap fasteners 65 48 Stage 2
  • 6.2L Engine
 unverified source
Crankshaft Crankshaft main bearing cap bolts 20 15 Stage 2, Bolts 1 through 10
  • 6.7L Engine
 unverified source
Crankshaft Crankshaft main bearing cap bolts 80 59 Stage 3, Bolts 1 through 10
  • 6.7L Engine
 unverified source
Crankshaft Crankshaft main bearing cap bolts 160 118 Stage 4, Bolts 11 through 20
  • 6.7L Engine
 unverified source
Crankshaft Crankshaft main bearing cap bolts 40 30 Stage 6, Bolts 21 through 30
  • 6.7L Engine
 unverified source
Crankshaft Main bearing caps fasteners 40 30 Stage 1, Fasteners 1 through 12
  • 6.8L Engine
 unverified source
Crankshaft Main bearing caps fasteners 30 22 Stage 1, Fasteners 13 through 24
  • 6.8L Engine
 unverified source
Crankshaft Main bearing side bolts 20 15 Stage 1
  • 6.2L Engine
 unverified source
Crankshaft Main bearing side bolts 35 26 Stage 2
  • 6.2L Engine
 unverified source
Crankshaft Balance shaft bearing caps bolts 10 7
  • 6.8L Engine
 unverified source
Crankshaft Crankshaft rear seal retainer plate bolts 10 7 Stage 1
  • 6.2L Engine
 unverified source
Crankshaft Crankshaft rear seal retainer plate bolts 10 7
  • 6.8L Engine
 unverified source
Common rail Fuel rail bolts 10 7 Stage 3
  • 6.2L Engine
 unverified source
Common rail Fuel rail bolts 24 18
  • 6.7L Engine
 unverified source
Common rail Fuel rail bolts 10 7
  • 6.8L Engine
 unverified source
Common rail Fuel rail supply tube bracket bolts 10 7
  • 6.7L Engine
 unverified source
Common rail Fuel rail supply tube bracket stud bolt 10 7
  • 6.7L Engine
 unverified source
Water pump Coolant pump bolts 10 7 Small bolts
  • Diesel Engine
 unverified source
Water pump Coolant pump bolts 24 18 Large bolts
  • Diesel Engine
 unverified source
Water pump Coolant pump bolts 20 15 Stage 2
  • 6.2L Engine
 unverified source
Water pump Coolant pump bolts 25 18
  • 6.8L Engine
 unverified source
Water pump Coolant pump pulley bolts 25 18
  • Gasoline Engines
 unverified source
Heater core Heater core and evaporator core housing bolts (interior or exterior) 7 5
unverified source
Heater core Heater core and evaporator core housing nuts (exterior) 7 5
unverified source
Heater core Heater core and evaporator core housing nut (interior) 6 4
unverified source
Heater core Heater core inlet tube bolts 10 7
  • 6.7L Engine
 unverified source
Heater core Heater coolant inlet fitting bolt 10 7
  • 6.2L Engine
 unverified source
Heater core Heater coolant return fitting bolt 10 7
  • 6.2L Engine
 unverified source
Heater core Heater supply tube bolts 10 7
  • 6.7L Engine
 unverified source
Fuel/Oil cooler Engine oil cooler 58 43
  • 6.2L Engine
 unverified source
Fuel/Oil cooler Oil cooler nut 24 18
  • 6.7L Engine
 unverified source
Fuel/Oil cooler Oil cooler bolts 10 7
  • 6.7L Engine
 unverified source
Fuel/Oil cooler Oil cooler 58 43
  • 6.8L Engine
 unverified source
Fuel/Oil cooler Fuel cooler bolt 9 7
unverified source
Fuel/Oil cooler Fuel cooler nuts 20 15
unverified source
Intercooler Charge Air Cooler (CAC) mounting bolts 12 9
unverified source
Intercooler CAC tube clamps 9 7
unverified source
Coolant expansion tank Coolant crossover manifold assembly bolts 10 7
  • 6.7L Engine
 unverified source
Coolant expansion tank Coolant crossover manifold assembly bolts 10 7
  • 6.8L Engine
 unverified source
Radiator Coolant inlet connector fitting 40 30
  • 6.7L Engine
 unverified source
Radiator Coolant outlet connection bolts 10 7
  • Diesel Engine
 unverified source
Radiator Coolant tube stud bolt 10 7
  • 6.8L Engine
 unverified source
Radiator Radiator bolts 11 8
  • 6.7L Engine
 unverified source
Radiator Secondary radiator bolts 11 8
  • Diesel Engine
 unverified source
Radiator Radiator bracket bolts 35 26
  • Diesel Engine
 unverified source
Radiator Radiator bracket bolts 35 26
  • Gasoline Engines
 unverified source
Radiator Radiator support bolts 40 30
  • Gasoline Engines
 unverified source
Radiator Radiator bolster bolts 40 30
  • Diesel Engine
 unverified source
Radiator Thermostat bolts 10 7
  • Gasoline Engines
 unverified source
Radiator Thermostat housing bolts 10 7
  • 6.7L Engine
 unverified source
Radiator Thermostat cover bolts 6 4
  • 6.7L Engine
 unverified source
Radiator Cooling fan drive assembly bolts 24 18
  • 6.7L Engine
 unverified source
Radiator Cooling fan blade to Fan clutch bolts 7 5
  • Gasoline Engines
 unverified source
Radiator Cooling fan to Cooling fan clutch nuts 7 5
  • Diesel Engine
 unverified source
Radiator Cooling fan clutch hub to Coolant pump 133 98
  • Gasoline Engines
 unverified source
Radiator Cooling fan clutch wiring harness bracket bolt 7 5
  • 6.2L Engine
 unverified source
Radiator Cooling fan clutch 133 98
  • 6.7L Engine
 unverified source
Radiator Cooling fan clutch electrical connector bracket bolt 25 18
  • 6.7L Engine
 unverified source
Radiator Cooling fan shroud bolts 7 5
  • Diesel Engine
 unverified source
Radiator Cooling fan shroud bolts 7 5
  • Gasoline Engines
 unverified source
Radiator Cooling fan stator nuts 17 13
  • 6.7L Engine
 unverified source
Radiator Cooling fan stator stand offs 22 16
  • 6.7L Engine
 unverified source
Air conditioning A/C clutch disc and hub bolt 14 10
unverified source
Air conditioning A/C compressor bolts 25 18
unverified source
Air conditioning A/C compressor fitting nuts (suction and discharge) 15 11
unverified source
Air conditioning A/C pressure relief valve 10 7
unverified source
Air conditioning A/C tube fitting nuts 15 11
  • Diesel Engine
 unverified source
Air conditioning A/C fitting to Condenser nuts 15 11
  • Gasoline Engines
 unverified source
Air conditioning A/C condenser bolts 11 8
  • 6.7L Engine
 unverified source
Air conditioning A/C condenser bolts 8 6
  • Gasoline Engines
 unverified source
Air conditioning Condenser fitting nuts (inlet and outlet) 15 11
unverified source
Air conditioning Condenser inlet jumper line fitting nut 15 11
unverified source
Air conditioning Evaporator to Compressor suction line fitting nut 15 11
unverified source
Air conditioning Thermostatic Expansion Valve (TXV) bolts 8 6
unverified source
Air conditioning TXV fitting nut 15 11
unverified source
Belt tensioner/Timing chains Accessory drive belt idler pulley bolt 25 18
  • 6.2L Engine
 unverified source
Belt tensioner/Timing chains Accessory drive belt idler pulley bolt 25 18
  • 6.8L Engine
 unverified source
Belt tensioner/Timing chains Accessory drive belt idler pulley bolt 48 35
  • 6.7L Engine
 unverified source
Belt tensioner/Timing chains Accessory drive belt idler pulley and bracket assembly stud bolts 25 18 Without A/C
  • 6.2L Engine
 unverified source
Belt tensioner/Timing chains Accessory drive belt idler pulley and bracket assembly stud bolts 25 18 Without A/C
  • 6.7L Engine
 unverified source
Belt tensioner/Timing chains Accessory drive belt tensioner bolts 25 18
  • 6.2L Engine
 unverified source
Belt tensioner/Timing chains Accessory drive belt tensioner bolts 25 18
  • 6.8L Engine
 unverified source
Belt tensioner/Timing chains Accessory drive belt tensioner bolt 48 35
  • 6.7L Engine
 unverified source
Belt tensioner/Timing chains Timing chain tensioner bolts 10 7 Stage 1
  • 6.2L Engine
 unverified source
Belt tensioner/Timing chains Timing chain hydraulic tensioner bolts 25 18
  • 6.8L Engine
 unverified source
Belt tensioner/Timing chains Timing chain guide bolt 10 7 Stage 1
  • 6.2L Engine
 unverified source
Belt tensioner/Timing chains Timing chain guide bolt 10 7
  • 6.8L Engine
 unverified source
Valve cover Valve cover fasteners 10 7
  • 6.2L Engine
 unverified source
Valve cover Valve cover stud bolts and bolts 12 9
  • 6.7L Engine
 unverified source
Valve cover Valve cover fasteners 10 7
  • 6.8L Engine
 unverified source
Valve cover Valve housing bolts 145 107
unverified source
PCM PCM nuts 7 5
  • Diesel Engine
 unverified source
PCM PCM nuts 7 5
  • Gasoline Engines
 unverified source
PCM PCM wiring harness bracket bolts 10 7
  • 6.7L Engine
 unverified source
Rocker arm Intake rocker arm shaft assembly bolts 10 7 Stage 1
  • 6.2L Engine
 unverified source
Rocker arm Intake rocker arm shaft assembly bolts 20 15 Stage 2
  • 6.2L Engine
 unverified source
Rocker arm Exhaust rocker arm shaft assembly bolts 10 7 Stage 1
  • 6.2L Engine
 unverified source
Rocker arm Exhaust rocker arm shaft assembly bolts 20 15 Stage 2
  • 6.2L Engine
 unverified source
Rocker arm Rocker arm assemblies 4 3 Stage 2
  • 6.7L Engine
 unverified source
Rocker arm Rocker arm assemblies 8 6 Stage 3
  • 6.7L Engine
 unverified source
Rocker arm Rocker arm assemblies 13 10 Stage 4
  • 6.7L Engine
 unverified source
Rocker arm Rocker arm assemblies 13 10 Stage 5
  • 6.7L Engine
 unverified source
Fuel system Fuel tube bracket nut 12 9
  • TorqShift Automatic Transmission
 unverified source
Fuel system Fuel tube bracket bolts 10 7
  • Diesel Engine
 unverified source
Fuel system Fuel volume control valve bolts 3 2 Stage 1
  • Diesel Engine
 unverified source
Fuel system Fuel volume control valve bolts 7 5 Stage 2
  • Diesel Engine
 unverified source
Fuel system Fuel pressure control valve 60 44 Stage 1
  • Diesel Engine
 unverified source
Fuel system Fuel pressure control valve 85 63 Stage 3
  • Diesel Engine
 unverified source
Fuel system Fuel pressure switch 21 15
  • Diesel Engine
 unverified source
Fuel system Fuel filter and bracket bolts and stud bolt 10 7
unverified source
Fuel system Secondary fuel filter 5 4
unverified source
Fuel system Fuel supply tube bolts 10 7
unverified source
Fuel system Fuel injector hold down clamps 30 22 Stage 1
  • 6.7L Engine
 unverified source
Fuel system Fuel injector supply tubes 20 15
  • 6.7L Engine
 unverified source
Fuel system Fuel injection pump supply tube bolt and stud bolt 10 7
  • 6.7L Engine
 unverified source
Fuel system Fuel Pump Driver Module (FPDM) bolts 9 7
  • 6.2L Engine
 unverified source
Fuel system Fuel pump control module nuts 10 7
  • 6.8L Engine
 unverified source
Fuel system Fuel tank filler pipe hose clamp 4 3
unverified source
Fuel system Fuel tank selector valve bolts 18 13
unverified source
Fuel system Fuel tank shield bolts 90 66 Aft of axle tank
unverified source
Fuel system Fuel tank shield bolts 20 15 Midship tank
unverified source
Fuel system Fuel tank strap nuts 72 53 Aft of axle tank
unverified source
Fuel system Fuel tank support strap bolts 40 30 Midship tank
unverified source
Fuel system High pressure fuel injection pump drive gear nut 80 59
  • 6.7L Engine
 unverified source
Fuel system High pressure fuel injection pump mounting bolts 48 35
  • 6.7L Engine
 unverified source
Fuel system High pressure fuel injection pump spacers 24 18
  • 6.7L Engine
 unverified source
Fuel system High pressure fuel injection pump supply tube retainer nut 11 8
  • 6.7L Engine
 unverified source

drivetrain torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Differential Front differential bearing cap bolts 108 80
unverified source
Differential Rear differential bearing cap bolts 108 80
  • Dana 80 Rear Axle
 unverified source
Differential Rear differential bearing cap bolt 190 140
  • Dana S110 Rear Axle
 unverified source
Differential Rear differential bearing cap bolt 190 140
  • Dana S130 Rear Axle
 unverified source
Differential Rear differential bearing cap bolt 119 88
  • Ford 10.50 Inch Rear Axle
 unverified source
Differential Front differential housing bolts 61 45
unverified source
Differential Rear differential case bolts 129 95
  • Dana 80 Rear Axle
 unverified source
Differential Rear differential carrier housing bolts 203 150
  • Dana S110 Rear Axle
 unverified source
Differential Rear differential carrier housing bolts 203 150
  • Dana S130 Rear Axle
 unverified source
Differential Rear differential case half bolts 163 120
  • Ford 10.50 Inch Rear Axle
 unverified source
Differential Rear differential housing cover bolts 45 33
  • Dana 80 Rear Axle
 unverified source
Differential Rear differential housing cover 32 24 Cast aluminium
  • Ford 10.50 Inch Rear Axle
 unverified source
Differential Rear differential housing cover bolts 45 33 Steel
  • Ford 10.50 Inch Rear Axle
 unverified source
Differential Front differential ring gear bolts 215 159
unverified source
Differential Rear ring gear bolts 298 220
  • Dana 80 Rear Axle
 unverified source
Differential Rear ring gear bolts 203 150
  • Dana S110 Rear Axle
 unverified source
Differential Rear ring gear bolts 203 150
  • Dana S130 Rear Axle
 unverified source
Differential Rear differential ring gear bolts 227 167
  • Ford 10.50 Inch Rear Axle
 unverified source
Differential Front fill plug 27 20
unverified source
Differential Rear fill plug 68 50
  • Dana S110 Rear Axle
 unverified source
Differential Rear fill plug 68 50
  • Dana S130 Rear Axle
 unverified source
Differential Rear filler plug 30 22
  • Ford 10.50 Inch Rear Axle
 unverified source
Differential Rear pinion shaft locknut 637 470
  • Dana 80 Rear Axle
 unverified source
Differential Rear pinion hex nut 1128 832
  • Dana S110 Rear Axle
 unverified source
Differential Rear pinion hex nut 1128 832
  • Dana S130 Rear Axle
 unverified source
Differential Rear differential pinion shaft lock bolt 31 23
  • Ford 10.50 Inch Rear Axle
 unverified source
Wheel hub assembly Front wheel bearing and wheel hub nuts 180 133
  • 4WD
 unverified source
Wheel hub assembly Front wheel bearing and wheel hub nuts 180 133
  • F-450
  • RWD
 unverified source
Wheel hub assembly Front wheel bearing and wheel hub nuts 180 133
  • F-550
  • RWD
 unverified source
Wheel hub assembly Rear hub bolts 155 114
  • 4WD
  • Full Floating Axle - Dana
 unverified source
Wheel hub assembly Hub nut 95 70 Stage 1
  • Full Floating Axle - Dana
 unverified source
Wheel hub assembly Hub nut 24 18 Stage 3
  • Full Floating Axle - Dana
 unverified source
Wheel hub assembly Hub nut 95 70 Stage 1
  • Full Floating Axle - Ford
 unverified source
Wheel hub assembly Hub nut 20 15 Stage 3
  • Full Floating Axle - Ford
 unverified source
Wheel hub assembly Rear brake disc to Wheel hub bolts 121 89
unverified source
Clutch pressure plate Clutch pressure plate bolts 45 33
unverified source
Clutch assembly Clutch housing to Transmission main case rear bolts 62 46
  • Tremec 5-Speed Manual Transmission
 unverified source
Clutch assembly Clutch housing to Transmission main case nuts 62 46
  • Tremec 5-Speed Manual Transmission
 unverified source
Flywheel/Flex plate Flywheel bolts 20 15 Stage 1, Fasteners 1 through 4
  • 6.2L Engine
 unverified source
Flywheel/Flex plate Flywheel bolts 35 26 Stage 2, Fasteners 1 through 4
  • 6.2L Engine
 unverified source
Flywheel/Flex plate Flywheel bolts 20 15 Stage 4, Fasteners 5 through 8
  • 6.2L Engine
 unverified source
Flywheel/Flex plate Flywheel bolts 35 26 Stage 5, Fasteners 5 through 8
  • 6.2L Engine
 unverified source
Flywheel/Flex plate Flexplate bolts 20 15 Stage 1, Fasteners 1 through 4
  • 6.2L Engine
 unverified source
Flywheel/Flex plate Flexplate bolts 35 26 Stage 2, Fasteners 1 through 4
  • 6.2L Engine
 unverified source
Flywheel/Flex plate Flexplate bolts 20 15 Stage 4, Fasteners 5 through 8
  • 6.2L Engine
 unverified source
Flywheel/Flex plate Flexplate bolts 35 26 Stage 5, Fasteners 5 through 8
  • 6.2L Engine
 unverified source
Flywheel/Flex plate Flexplate bolts 5 4 Stage 1
  • 6.7L Engine
 unverified source
Flywheel/Flex plate Flexplate bolts 100 74 Stage 2
  • 6.7L Engine
 unverified source
Flywheel/Flex plate Flexplate bolts 80 59
  • 6.8L Engine
 unverified source
Flywheel/Flex plate Flexplate inspection cover bolts 34 25
  • 6.2L Engine
 unverified source
Flywheel/Flex plate Flexplate inspection cover bolts 34 25
  • 6.8L Engine
 unverified source
Flywheel/Flex plate Flexplate inspection cover bolts 34 25
  • TorqShift Automatic Transmission
 unverified source
Transmission fluid pan Transmission fluid filler tube nut 10 7
  • TorqShift Automatic Transmission
 unverified source
Transmission fluid pan Transmission filler tube bolt 25 18
  • TorqShift 6 Automatic Transmission
 unverified source
Transmission fluid pan Transmission fluid filter bolts 11 8
  • TorqShift 6 Automatic Transmission
 unverified source
Transmission fluid pan Transmission fluid cooler tube bracket to Engine nut 40 30
  • 6.2L Engine
 unverified source
Transmission fluid pan Transmission fluid cooler tube bracket to Engine nut 40 30
  • 6.8L Engine
 unverified source
Transmission fluid pan Transmission fluid cooler tube bracket to Engine nut 12 9
  • 6.7L Engine
 unverified source
Transmission fluid pan Transmission fluid cooler tube fitting 60 44
unverified source
Transmission fluid pan Transmission fluid cooler tube to Transmission case nuts 40 30
  • TorqShift Automatic Transmission
 unverified source
Transmission fluid pan Transmission fluid cooler tube bracket assembly to Case bolt 25 18
  • TorqShift 6 Automatic Transmission
 unverified source
Transmission fluid pan Transmission auxiliary fluid cooler bolts 11 8
  • Gasoline Engines
 unverified source
Transmission fluid pan Transmission fluid indicator tube bolt at engine 11 8
  • 6.7L Engine
 unverified source
Transmission fluid pan Transmission fluid indicator tube nut at transmission 25 18
  • 6.7L Engine
 unverified source
Transmission fluid pan Transmission fluid filler/level indicator tube bolt 10 7
  • 6.8L Engine
 unverified source
Transmission fluid pan Transmission fluid pan drain plug 18 13
  • TorqShift Automatic Transmission
 unverified source
Transmission fluid pan Transmission fluid pan drain plug 18 13
  • TorqShift 6 Automatic Transmission
 unverified source
Transmission fluid pan Transmission fluid pan bolts 20 15
  • TorqShift Automatic Transmission
 unverified source
Transmission fluid pan Transmission fluid pan bolts 9 7
  • TorqShift 6 Automatic Transmission
 unverified source
Transmission fluid pan Pump body to Case bolts 27 20
  • TorqShift Automatic Transmission
 unverified source
Transmission fluid pan Pump to Transmission case bolts 25 18
  • TorqShift 6 Automatic Transmission
 unverified source
Transmission fluid pan Pump body bolts 31 23
  • TorqShift Automatic Transmission
 unverified source
Transmission mount/case Transmission to Engine bolts 48 35
  • 6.2L Engine
 unverified source
Transmission mount/case Transmission to Engine bolts 48 35
  • 6.7L Engine
 unverified source
Transmission mount/case Transmission to Engine bolts 48 35
  • 6.8L Engine
 unverified source
Transmission mount/case Transmission to Engine bolts 47 35
  • TorqShift Automatic Transmission
 unverified source
Transmission mount/case Transmission to Engine bolts 48 35
  • TorqShift 6 Automatic Transmission
 unverified source
Transmission mount/case Transmission to Engine bolts 63 46
  • Tremec 5-Speed Manual Transmission
 unverified source
Transmission mount/case Engine to Transmission spacer plate bolts 28 21
  • Tremec 5-Speed Manual Transmission
 unverified source
Transmission mount/case Transmission crossmember nuts 90 66
unverified source
Transmission mount/case Transmission mount nuts 115 85
unverified source
Transmission mount/case Extension housing to Case bolt 47 35
  • TorqShift Automatic Transmission
 unverified source
Transmission mount/case Extension housing bolts 40 30
  • TorqShift 6 Automatic Transmission
 unverified source
Transmission mount/case Extension housing to Transmission main case bolts 62 46
  • Tremec 5-Speed Manual Transmission
 unverified source
Transmission mount/case O/D planet to Coast clutch hub bolts 25 18 Stage 1
  • TorqShift Automatic Transmission
 unverified source
Transmission mount/case Main control to Transmission case bolts 11 8
  • TorqShift 6 Automatic Transmission
 unverified source
Transmission mount/case Transmission Control Module (TCM) 19 14
  • TorqShift 6 Automatic Transmission
 unverified source
Transmission mount/case Transmission feed tube to Transmission case bolts 11 8
  • TorqShift 6 Automatic Transmission
 unverified source
Torque converter Torque converter to Flexplate nut 36 27
  • 6.2L Engine
 unverified source
Torque converter Torque converter to Flexplate nuts 35 26
  • 6.8L Engine
 unverified source
Torque converter Torque converter to Flexplate nut 48 35
  • TorqShift Automatic Transmission
 unverified source
Torque converter Torque converter nuts 55 41
  • 6.7L Engine
 unverified source
Torque converter Torque converter nuts 48 35
  • TorqShift 6 Automatic Transmission
 unverified source
Transfer Transfer case to Transmission bolts 55 41
  • TorqShift Automatic Transmission
 unverified source
Transfer Transfer case to Transmission bolts 55 41
  • TorqShift 6 Automatic Transmission
 unverified source
Transfer Transfer case linkage bolts 115 85
  • TorqShift 6 Automatic Transmission
 unverified source
Transfer Transfer case shift linkage bolts 115 85
  • 4WD
 unverified source
Transfer Transfer Case Control Module (TCCM) nuts 4 3
  • 4WD
 unverified source
Transfer Transfer case control bracket bolt 115 85
unverified source
Transfer Transfer case control pivot bolt 40 30
unverified source
Transfer Transfer case skid plate bolts 24 18
unverified source
Transfer Lower gear shift lever bolts 11 8
  • Tremec 5-Speed Manual Transmission
 unverified source
Transfer Upper gear shift lever bolts 28 21
  • Tremec 5-Speed Manual Transmission
 unverified source
Transfer Shift lever bolt 27 20
unverified source
Transfer Shift lever nut 20 15
unverified source
Transfer Shift control housing bolts 27 20
  • Tremec 5-Speed Manual Transmission
 unverified source
Transfer Selector lever bolt 18 13
  • Automatic Transmission
 unverified source
Transfer Selector lever cable bracket bolts 48 35
  • TorqShift Automatic Transmission
 unverified source
Transfer Selector lever cable bracket bolts 48 35
  • TorqShift 6 Automatic Transmission
 unverified source
Transfer Selector lever mechanism bolts 10 7
  • Automatic Transmission
 unverified source
Transfer Manual control lever nut 24 18
  • TorqShift 6 Automatic Transmission
 unverified source
Transfer Park pawl abutment Torx screw 25 18
  • TorqShift Automatic Transmission
 unverified source
Transfer Park pawl abutment plate 11 8
  • TorqShift 6 Automatic Transmission
 unverified source
Transfer Park pawl pin plug 35 26
  • TorqShift 6 Automatic Transmission
 unverified source
Transfer Park rod guide plate to Case bolts 25 18
  • TorqShift Automatic Transmission
 unverified source
Transfer Transmission Range (TR) sensor bolts 10 7
  • TorqShift Automatic Transmission
 unverified source
Transfer Transmission Range (TR) sensor detent spring bolt 12 9
  • TorqShift 6 Automatic Transmission
 unverified source
Transfer Transmission shift cable bracket bolt 48 35
  • 6.7L Engine
 unverified source
Transfer Drain and fill plugs 27 20
unverified source
Drive/Axle shaft Axle shaft bolts 133 98
  • Full Floating Axle - Dana
 unverified source
Drive/Axle shaft Axle shaft bolts 50 37
  • Full Floating Axle - Ford
 unverified source
Drive/Axle shaft Driveshaft center bearing support bolts 70 52
unverified source
Drive/Axle shaft Driveshaft center bearing support bracket nuts 23 17
unverified source
Drive/Axle shaft Driveshaft flange bolts (front or rear) 103 76
  • TorqShift 6 Automatic Transmission
 unverified source
Drive/Axle shaft Front driveshaft flange bolts 35 26
unverified source
Drive/Axle shaft Rear driveshaft flange bolt 103 76
  • Ford 10.50 Inch Rear Axle
 unverified source
Drive/Axle shaft Driveshaft to Transmission flange bolts 103 76
  • Tremec 5-Speed Manual Transmission
 unverified source
Drive/Axle shaft Front driveshaft U-joint bearing strap bolts 35 26
unverified source
Drive/Axle shaft Rear driveshaft U-joint bearing strap bolts 62 46
unverified source
Drive/Axle shaft Reverse slip driveshaft flange to Driveshaft nut 576 425
unverified source
Drive/Axle shaft Output shaft flange bolt 130 96
  • TorqShift Automatic Transmission
 unverified source
Drive/Axle shaft Output shaft flange bolt 133 98
  • TorqShift 6 Automatic Transmission
 unverified source
Drive/Axle shaft Output shaft retaining nut 200 148
  • TorqShift Automatic Transmission
 unverified source
Drive/Axle shaft Output shaft nut 200 148
  • TorqShift 6 Automatic Transmission
 unverified source
Drive/Axle shaft Rear driveshaft bolts 100 74 Vehicles with circular flange
  • Dana S110 Rear Axle
 unverified source
Drive/Axle shaft Rear driveshaft bolts 100 74 Vehicles with circular flange
  • Dana S130 Rear Axle
 unverified source
Drive/Axle shaft Rear driveshaft bolts 62 46 Vehicles with split pin yoke
  • Dana S110 Rear Axle
 unverified source
Drive/Axle shaft Rear driveshaft bolts 62 46 Vehicles with split pin yoke
  • Dana S130 Rear Axle
 unverified source

steering torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Tie rod end Inner tie rod to Center link nut 88 65
  • F-250
  • RWD
 unverified source
Tie rod end Inner tie rod to Center link nut 88 65
  • F-350
  • RWD
 unverified source
Tie rod end Outer tie rod end nut 115 85
unverified source
Tie rod end Tie rod clamp nuts 55 41
  • F-250
 unverified source
Tie rod end Tie rod clamp nuts 55 41
  • F-350
 unverified source
Tie rod end Tie rod clamp nuts 80 59
  • F-450
 unverified source
Tie rod end Tie rod clamp nuts 80 59
  • F-550
 unverified source
Tie rod end Tie rod adjuster sleeve nuts 55 41
unverified source
Pitman arm Front drag link nut 115 85
unverified source
Pitman arm Outer drag link nut 115 85
unverified source
Pitman arm Drag link clamp nut 55 41
unverified source
Pitman arm Drag link adjuster sleeve nuts 55 41
unverified source
Pitman arm Drag link to Sector shaft arm nut 175 129
unverified source
Idler arm Steering idler arm to Frame bolts 115 85
unverified source
Idler arm Steering idler arm to Centerlink nut 175 129
unverified source
Steering rack Steering damper to Frame bolt 103 76
  • TorqShift Automatic Transmission
 unverified source
Steering rack Steering linkage damper bolt 80 59
  • 4WD
 unverified source
Steering rack Steering linkage damper bolt and nut 90 66
  • RWD
 unverified source
Steering rack Steering linkage damper frame bracket nuts 70 52
unverified source
Steering rack Steering linkage damper to Frame bracket nut 80 59
unverified source
Steering rack Steering linkage damper to Drag link bracket U-bolt nuts 25 18
  • F-250
  • RWD
 unverified source
Steering rack Steering linkage damper to Drag link bracket U-bolt nuts 25 18
  • F-350
  • RWD
 unverified source
Steering rack Pressure line to Steering gear fitting 35 26
unverified source
Steering rack Return hose to Steering gear fitting 35 26
unverified source
Steering rack Sector shaft arm to Sector shaft nut 475 350
unverified source
Steering rack Steering gear bolts 200 148
  • F-250
 unverified source
Steering rack Steering gear bolts 200 148
  • F-350
 unverified source
Steering rack Steering gear bolts 300 221
  • F-450
 unverified source
Steering rack Steering gear bolts 300 221
  • F-550
 unverified source
Steering column Steering column shroud screws 2 1
unverified source
Steering column Steering column to Instrument panel nuts 30 22
unverified source
Steering column Steering column to Instrument panel bolts 28 21
unverified source
Steering column Upper steering column housing position screw 25 18
unverified source
Steering column Steering Column Control Module (SCCM) screws 2 1
unverified source
Steering column Shifter assembly bolt and screws 6 4
unverified source
Steering shaft Steering shaft bolt 28 21
  • 6.2L Engine
 unverified source
Steering shaft Steering column shaft dash seal bolts 11 8
unverified source
Steering shaft Upper steering column shaft to Steering column bolt 28 21
unverified source
Steering shaft Upper steering column shaft to Lower steering column shaft bolt 55 41
unverified source
Steering shaft Lower steering column shaft to Steering gear bolt 35 26
unverified source
Steering wheel Steering wheel bolt 48 35
unverified source
Steering wheel Steering wheel rotation sensor bolts 3 2
unverified source
Steering wheel Ignition switch screw 5 4
unverified source
Power steering Power steering pump bolts 25 18
  • 6.2L Engine
 unverified source
Power steering Power steering pump bolts 25 18
  • 6.7L Engine
 unverified source
Power steering Power steering pump bolts 30 22
  • 6.8L Engine
 unverified source
Power steering Power steering pump bracket bolts 24 18
  • 6.7L Engine
 unverified source
Power steering Power steering fluid cooler bolts 35 26
  • Diesel Engine
 unverified source
Power steering Power steering fluid cooler bolts 11 8
  • Gasoline Engines
 unverified source
Power steering Power steering fluid reservoir bolt 7 5
  • Diesel Engine
 unverified source
Power steering Power steering fluid reservoir bolt 7 5
  • Gasoline Engines
 unverified source
Power steering Power steering pressure hose bracket screw 5 4
  • Diesel Engine
 unverified source
Power steering Power Steering Pressure (PSP) hose support bracket nut 10 7
  • 6.2L Engine
 unverified source
Power steering Power steering pressure tube bolt 12 9
  • 6.7L Engine
 unverified source
Power steering Power steering fluid return tube bolt 23 17
  • 6.2L Engine
 unverified source

exhaust torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Exhaust manifold Exhaust manifold heat shield bolts 12 9
  • 6.2L Engine
 unverified source
Exhaust manifold Exhaust manifold heat shield bolts 10 7
  • 6.7L Engine
 unverified source
Exhaust manifold Exhaust manifold heat shield bolts 14 10
  • 6.8L Engine
 unverified source
Exhaust manifold Exhaust manifold nuts 25 18 Stage 1
  • 6.2L Engine
 unverified source
Exhaust manifold Exhaust manifold nuts 32 24 Stage 2
  • 6.2L Engine
 unverified source
Exhaust manifold Exhaust manifold nuts 20 15 Stage 1
  • 6.7L Engine
 unverified source
Exhaust manifold Exhaust manifold nuts 30 22 Stage 2
  • 6.7L Engine
 unverified source
Exhaust manifold Exhaust manifold nuts 30 22 Stage 3
  • 6.7L Engine
 unverified source
Exhaust manifold Exhaust manifold nuts 25 18
  • 6.8L Engine
 unverified source
Exhaust manifold Exhaust manifold studs 25 18
  • 6.2L Engine
 unverified source
Exhaust manifold Exhaust manifold studs 13 10
  • 6.7L Engine
 unverified source
Exhaust manifold Exhaust manifold to Cylinder head studs 12 9
  • 6.8L Engine
 unverified source
Exhaust manifold Exhaust manifold flange nuts 25 18
  • 6.7L Engine
 unverified source
Exhaust manifold Exhaust manifold flange nuts 40 30
  • 6.8L Engine
 unverified source
Exhaust manifold Exhaust manifold flange studs 13 10
  • 6.7L Engine
 unverified source
Exhaust manifold Exhaust Y-pipe flange nuts 40 30
  • 6.2L Engine
 unverified source
Exhaust manifold Exhaust Y-pipe flange nuts 40 30
  • 6.8L Engine
 unverified source
Exhaust manifold Exhaust intermediate pipe to Tail pipe assembly nuts 55 41
  • 6.7L Engine
 unverified source
Turbo Turbocharger actuator bolt 24 18
  • Diesel Engine
 unverified source
Turbo Turbocharger downpipe bracket bolt 25 18
  • 6.7L Engine
 unverified source
Turbo Turbocharger downpipe clamp nut at turbocharger 15 11
  • 6.7L Engine
 unverified source
Turbo Turbocharger downpipe clamp nut at pipe 55 41
  • 6.7L Engine
 unverified source
Turbo Turbocharger downpipe flange bolt 40 30
  • 6.7L Engine
 unverified source
Turbo Turbocharger heat shield bolts 10 7
  • 6.7L Engine
 unverified source
Turbo Turbocharger inlet pipe clamps 15 11
unverified source
Turbo Turbocharger inlet pipe nuts 25 18
unverified source
Turbo Turbocharger inlet pipe studs 13 10
unverified source
Turbo Pedestal to Turbocharger bolts 10 7 Turbocharger, Stage 1
unverified source
Turbo Turbocharger to Pedestal bracket bolts 11 8 Turbocharger
unverified source
Turbo Turbocharger bolts 55 41 Turbocharger
unverified source
Turbo Turbocharger coolant tube fittings (small) 22 16 Turbocharger
unverified source
Turbo Turbocharger oil feed fitting banjo bolts 38 28
unverified source
EGR EGR cooler assembly bolts 10 7
  • 6.7L Engine
 unverified source
EGR EGR valve inlet tube bolts at exhaust manifold 10 7
  • 6.7L Engine
 unverified source
EGR EGR valve inlet tube bolts at EGR cooler 10 7
  • 6.7L Engine
 unverified source
EGR EGR valve inlet tube bracket bolt at EGR cooler 10 7 Stage 1
  • 6.7L Engine
 unverified source
EGR EGR valve inlet tube bracket bolt 10 7 Stage 3
  • 6.7L Engine
 unverified source
EGR EGR valve bolts 12 9 Stage 1, Bolts 1 thru 12
  • 6.7L Engine
 unverified source
EGR EGR valve bolts 16 12 Stage 2, Bolts 1 thru 12
  • 6.7L Engine
 unverified source
EGR EGR valve bolts 16 12 Stage 3, Bolts 1 thru 4
  • 6.7L Engine
 unverified source
EGR EGR valve bolts 12 9 Stage 4, Bolt 13
  • 6.7L Engine
 unverified source
EGR EGR valve vacuum regulator bolt 5 4
  • 6.7L Engine
 unverified source
Diesel particulate filter Catalyst and particulate filter assembly isolator bracket nuts 30 22
unverified source
Diesel particulate filter Catalyst and particulate filter assembly to Exhaust intermediate pipe nuts 55 41
unverified source
Diesel particulate filter Exhaust lower downpipe to Catalyst and particulate filter assembly bolts 40 30
unverified source
Catalytic converter Catalyst Monitor Sensor (CMS) 46 34
  • Gasoline Engines
 unverified source
Catalytic converter Exhaust manifold to Catalytic converter nuts 40 30
  • 6.8L Engine
 unverified source
Catalytic converter Exhaust Y-pipe with dual catalytic converter to Resonator bolts 40 30
unverified source

brakes torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Disc brake Front brake caliper anchor plate bolts 225 166
  • F-250
 unverified source
Disc brake Front brake caliper anchor plate bolts 225 166
  • F-350
 unverified source
Disc brake Front brake caliper anchor plate bolts 400 295
  • F-450
 unverified source
Disc brake Front brake caliper anchor plate bolts 400 295
  • F-550
 unverified source
Disc brake Rear brake caliper anchor plate bolts 275 203
  • F-250
 unverified source
Disc brake Rear brake caliper anchor plate bolts 275 203
  • F-350
 unverified source
Disc brake Rear brake caliper anchor plate bolts 400 295
  • F-450
 unverified source
Disc brake Rear brake caliper anchor plate bolts 400 295
  • F-550
 unverified source
Disc brake Rear brake caliper support bracket nuts 137 101
unverified source
Disc brake Front brake caliper bolts 76 56
  • F-250
 unverified source
Disc brake Front brake caliper bolts 76 56
  • F-350
 unverified source
Disc brake Front brake caliper bolts 63 46
  • F-450
 unverified source
Disc brake Front brake caliper bolts 63 46
  • F-550
 unverified source
Disc brake Rear brake caliper bolts 35 26
  • F-250
  • SRW
 unverified source
Disc brake Rear brake caliper bolts 35 26
  • F-350
  • SRW
 unverified source
Disc brake Rear brake caliper bolts 76 56
  • F-350
  • DRW
 unverified source
Disc brake Rear brake caliper bolts 62 46
  • F-450
 unverified source
Disc brake Rear brake caliper bolts 62 46
  • F-550
 unverified source
Disc brake Front brake caliper flow bolt 48 35
unverified source
Disc brake Rear brake caliper flow bolt 35 26
unverified source
Disc brake Front brake disc shield screws 11 8
unverified source
Disc brake Caliper bleeder screw 15 11
unverified source
Disc brake Hydraulic brake tube fittings (brake caliper tubes) 23 17
unverified source
Brake line Front brake hose bracket bolts 18 13
unverified source
Brake line Rear brake hose bracket bolts 7 5
  • Dana 80 Rear Axle
 unverified source
Brake line Rear brake hose bracket bolts 7 5
  • Ford 10.50 Inch Rear Axle
 unverified source
Brake line Front brake flexible hose lower bracket bolt 15 11
unverified source
Brake line Front brake flexible hose upper bracket bolt 30 22
unverified source
Brake line Rear brake flexible hose bracket bolt 25 18
unverified source
Brake line Rear brake flexible hose bolt 30 22
unverified source
Brake line Rear brake tube to Flexible hose fitting 18 13
  • Dana S110 Rear Axle
 unverified source
Brake line Rear brake tube to Flexible hose fitting 18 13
  • Dana S130 Rear Axle
 unverified source
Brake line Front brake tube fitting to Brake hose 20 15
unverified source
Brake line Rear brake tube fitting 18 13
unverified source
Brake line Rear brake tube shield nuts 35 26
unverified source
Brake line Rear brake hose junction block bolt 17 13
  • Dana 80 Rear Axle
 unverified source
Brake line Rear brake hose junction block bolt 20 15
  • Ford 10.50 Inch Rear Axle
 unverified source
Brake booster Brake booster nuts 25 18
unverified source
Brake booster Brake booster power steering jumper line fittings 28 21
unverified source
Brake pedal Brake pedal bracket to Column brace nuts 25 18
unverified source
Brake pedal Brake pedal control switch 3 2
unverified source
Brake pedal Clutch pedal support bracket nut 25 18
unverified source
Brake pedal Accelerator pedal and position sensor assembly bolts 25 18 Fixed pedal
unverified source
Brake pedal Accelerator pedal and position sensor assembly nuts 9 7 Adjustable pedal
unverified source
Brake pedal Adjustable pedal motor and bracket assembly bolts 25 18
unverified source
Master cylinder Master cylinder brake tube fittings 25 18
unverified source
Master cylinder Brake master cylinder nuts 30 22 Hydro-Boost
unverified source
Master cylinder Brake master cylinder nuts 23 17 Vacuum booster
unverified source
Parking brake Parking brake cable wire form bracket bolts 40 30
unverified source
Parking brake LH parking brake to Spring U-bolt plate bolt 28 21
unverified source
Parking brake Parking brake cable to Differential bracket bolt 25 18
unverified source
Parking brake Parking brake cable to Shock mount bracket bolt 20 15
unverified source
Parking brake Parking brake control nuts 25 18
unverified source
Parking brake Parking brake release handle screw 3 2
unverified source
ABS ABS module screws 3 2
unverified source
ABS Hydraulic Control Unit (HCU) to HCU bracket bolt 15 11
unverified source
ABS HCU bracket to Body bolt 25 18
unverified source
ABS HCU bracket to Body nuts 25 18
unverified source
ABS Brake pressure transducer 18 13
unverified source

suspension torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Wheels Wheel nuts 224 165
  • SRW
  • DRW
 unverified source
Spring Front spring lower nuts 200 148
  • 4WD
 unverified source
Spring Front spring lower nuts 200 148
  • F-250
  • F-350
  • RWD
 unverified source
Spring Rear auxiliary spring nut 100 74
  • F-450
  • F-550
 unverified source
Spring Front spring bracket bolts 35 26
  • F-250
  • F-350
  • RWD
 unverified source
Spring Front jounce bumper nuts 35 26
  • 4WD
 unverified source
Spring Rear shackle to Bracket bolt 225 166
unverified source
Spring Rear spring to Front bracket bolt 515 380
unverified source
Spring Rear spring to Shackle nut 225 166
unverified source
Spring Rear U-bolt nuts 100 74 Stage 1
unverified source
Spring Rear U-bolt nuts 200 148 Stage 2
unverified source
Spring Rear U-bolt nuts 300 221 Stage 3
unverified source
Spring Rear U-bolt nuts 400 295 Stage 4
unverified source
Shock absorbers/shocks Front shock absorber lower bolts 150 111
  • 4WD
 unverified source
Shock absorbers/shocks Front shock absorber lower nuts 70 52
  • F-250
  • F-350
  • RWD
 unverified source
Shock absorbers/shocks Front shock absorber lower bolt 150 111
  • F-450
  • F-550
  • RWD
 unverified source
Shock absorbers/shocks Rear lower shock absorber nuts 90 66
  • Ford 10.50 Inch Rear Axle
 unverified source
Shock absorbers/shocks Rear shock absorber lower nut 90 66
unverified source
Shock absorbers/shocks Front shock absorber upper nuts 63 46
  • 4WD
 unverified source
Shock absorbers/shocks Front shock absorber upper nut 63 46
  • F-250
  • F-350
  • RWD
 unverified source
Shock absorbers/shocks Rear shock absorber upper nut and washer 70 52
unverified source
Shock absorbers/shocks Rear shock absorber nuts and bolts 90 66
  • Dana S110 Rear Axle
  • Dana S130 Rear Axle
 unverified source
Shock absorbers/shocks Rear shock absorber bracket nuts 40 30
unverified source
Stabilizer bar Front stabilizer bar bracket nuts 48 35
  • 4WD
 unverified source
Stabilizer bar Front stabilizer bar bracket bolts and nuts 48 35
  • F-250
  • F-350
  • RWD
 unverified source
Stabilizer bar Front stabilizer bar bracket nuts 48 35
  • F-450
  • F-550
  • RWD
 unverified source
Stabilizer bar Rear stabilizer bar bracket bolts 48 35
  • F-250
  • F-350
 unverified source
Stabilizer bar Rear stabilizer bar bracket bolts 80 59
  • F-450
  • F-550
 unverified source
Stabilizer bar Rear stabilizer bar bracket nuts 40 30
unverified source
Sway bar links/Stabilizer links Front stabilizer bar link bolts 80 59
  • 4WD
 unverified source
Sway bar links/Stabilizer links Front stabilizer bar link nuts 115 85
  • F-250
  • F-350
  • RWD
 unverified source
Sway bar links/Stabilizer links Front stabilizer bar link nuts 80 59
  • F-450
  • F-550
  • RWD
 unverified source
Sway bar links/Stabilizer links Rear stabilizer bar link nuts 103 76
unverified source
Radius arm Radius arm front and rear nuts 300 221
  • F-250
  • F-350
  • 4WD
 unverified source
Radius arm Radius arm front and rear nuts 300 221
  • F-450
  • F-550
  • 4WD
 unverified source
Radius arm Radius arm front nuts 400 295
  • F-250
  • F-350
  • RWD
 unverified source
Radius arm Radius arm rear nuts 300 221
  • F-250
  • F-350
  • RWD
 unverified source
Radius arm Radius arm front and rear nuts 300 221
  • F-450
  • F-550
  • RWD
 unverified source
Trailing arm Front trailing arm bolts 300 221
unverified source
Ball joint Front track bar ball joint nut 250 184
  • 4WD
 unverified source
Ball joint Front track bar ball joint nut 250 184
  • F-250
  • F-350
  • F-450
  • F-550
  • RWD
 unverified source
Ball joint Front lower ball joint nut 204 150
  • 4WD
 unverified source
Ball joint Front lower ball joint nut 133 98
  • F-250
  • F-350
  • RWD
 unverified source
Ball joint Front lower ball joint nut 204 150
  • F-450
  • F-550
  • RWD
 unverified source
Ball joint Front upper ball joint nut 94 69
  • 4WD
 unverified source
Ball joint Front upper ball joint nut 80 59
  • F-250
  • F-350
  • RWD
 unverified source
Ball joint Front upper ball joint nut 94 69
  • F-450
  • F-550
  • RWD
 unverified source

general torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

Did you find the answer to your specific question?
👍 15 👎 22

Related Vans:
