Ford F150 12 (2009-2014) Torque Spec Settings

IFCAR, Public domain, via Wikimedia Commons

Below you'll find the tightening torques for the Ford F150 12 in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.

Most-used torque settings for Ford F150 12

Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Drain plug 23 17
  • 6.2L Engine
 unverified source
Oil filter Oil filter 5 4
  • 6.2L Engine
 unverified source
Spark plugs Spark plugs 18 13
  • 6.2L Engine
 unverified source
Transmission fluid pan Transmission fluid fill plug 35 26
  • 6R80 Automatic Transmission
 unverified source
Wheels Wheel nuts 204 150
unverified source

Are these torque settings right for you?

  • Production years: 2009 - 2014
  • Generation: 12
  • Type of van: pickup
  • Model variant: Base
  • Also known as: Ford Lobo Ford Lobo Raptor Ford F-150 Lincoln Mark LT

All Torque Settings in Tables

engine torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil pan bolts 2 1 Stage 1
  • 6.2L Engine
 unverified source
Oil pan Oil pan bolts 10 7 Stage 2
  • 6.2L Engine
 unverified source
Oil pan Drain plug 23 17
  • 6.2L Engine
 unverified source
Oil filter Oil filter 5 4
  • 6.2L Engine
 unverified source
Oil filter Oil filter adapter bolts 20 15
  • 6.2L Engine
 unverified source
Oil pressure switch EOP switch 14 10
  • 6.2L Engine
 unverified source
Oil dipstick Oil level indicator and tube bolt 10 7
  • 6.2L Engine
 unverified source
Oil pump Oil pump fasteners 2 1 Stage 1
  • 6.2L Engine
 unverified source
Oil pump Oil pump upper bolts 10 7 Stage 2
  • 6.2L Engine
 unverified source
Oil pump Oil pump lower stud bolts 20 15 Stage 3
  • 6.2L Engine
 unverified source
Oil pump Oil pump screen and pickup tube to Oil pump bolts 10 7
  • 6.2L Engine
 unverified source
Spark plugs Spark plugs 18 13
  • 6.2L Engine
 unverified source
Intake manifold Intake manifold bolts 10 7 Stage 1
  • 6.2L Engine
 unverified source
Throttle body TB bolts 12 9 Stage 1
  • 6.2L Engine
 unverified source
Throttle body TB adapter to TB clamp 5 4
  • 6.2L Engine
 unverified source
Engine block Block heater 40 30
  • 6.2L Engine
 unverified source
Engine mounts Engine front cover bolts 10 7 Stage 1
  • 6.2L Engine
 unverified source
Engine mounts Engine front cover bolts 20 15 Stage 2
  • 6.2L Engine
 unverified source
Sensor CKP sensor bolt 10 7
  • 6.2L Engine
 unverified source
Alternator Generator support bracket bolts 20 15 Stage 1
  • 6.2L Engine
 unverified source
Starter Starter motor mounting bolts 25 18
  • 6.2L Engine
 unverified source
Starter Starter motor mounting stud bolts 25 18
  • 6.2L Engine
 unverified source
Starter Starter motor ground cable nut 25 18
  • 6.2L Engine
 unverified source
Battery Positive battery cable nut 9 7
  • 6.2L Engine
 unverified source
Battery Ignition coil-on-plug bolts 10 7
  • 6.2L Engine
 unverified source
Camshaft Camshaft bearing caps bolts 6 4 Stage 1
  • 6.2L Engine
 unverified source
Camshaft Camshaft phaser and sprocket bolts 9 7 Stage 1
  • 6.2L Engine
 unverified source
Crankshaft Crankshaft rear seal retainer plate bolts 10 7 Stage 1
  • 6.2L Engine
 unverified source
Crankshaft Crankshaft pulley bolt 175 129 Stage 1
  • 6.2L Engine
 unverified source
Common rail Fuel rail bolts 10 7 Stage 3
  • 6.2L Engine
 unverified source
Water pump Coolant pump pulley bolts 25 18
  • 6.2L Engine
 unverified source
Radiator Coolant outlet connection bolts 10 7
  • 6.2L Engine
 unverified source
Radiator Thermostat housing 10 7
  • 6.2L Engine
 unverified source
Air conditioning A/C compressor bolts 25 18
  • 6.2L Engine
 unverified source
Belt tensioner/Timing chains Accessory drive belt tensioner bolts 25 18
  • 6.2L Engine
 unverified source
Belt tensioner/Timing chains Accessory drive belt idler pulley bolt 25 18
  • 6.2L Engine
 unverified source
Belt tensioner/Timing chains Timing chain tensioner bolts 10 7 Stage 1
  • 6.2L Engine
 unverified source
Belt tensioner/Timing chains Timing chain guide bolt 10 7 Stage 1
  • 6.2L Engine
 unverified source
Valve cover Valve cover bolts 10 7
  • 6.2L Engine
 unverified source
Rocker arm Intake rocker arm shaft assembly bolts 10 7 Stage 1
  • 6.2L Engine
 unverified source
Rocker arm Intake rocker arm shaft assembly bolts 20 15 Stage 2
  • 6.2L Engine
 unverified source
Rocker arm Exhaust rocker arm shaft assembly bolts 10 7 Stage 1
  • 6.2L Engine
 unverified source
Rocker arm Exhaust rocker arm shaft assembly bolts 20 15 Stage 2
  • 6.2L Engine
 unverified source
Fuel system Fuel Pump (FP) control module bolts 9 7
  • 6.2L Engine
 unverified source

drivetrain torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Flywheel/Flex plate Flexplate bolts 20 15 Fasteners 1 through 4, Stage 1
  • 6.2L Engine
 unverified source
Flywheel/Flex plate Flexplate bolts 35 26 Fasteners 1 through 4, Stage 2
  • 6.2L Engine
 unverified source
Flywheel/Flex plate Flexplate bolts 20 15 Fasteners 5 through 8, Stage 4
  • 6.2L Engine
 unverified source
Flywheel/Flex plate Flexplate bolts 35 26 Fasteners 5 through 8, Stage 5
  • 6.2L Engine
 unverified source
Transmission mount/case Transmission to Engine bolts 48 35
  • 6.2L Engine
 unverified source
Transmission mount/case Transmission fluid cooling tubes rear support bracket bolt 48 35
  • 6.2L Engine
 unverified source
Transmission mount/case Transmission fluid cooler tube bracket to Front of the engine nut 40 30
  • 6.2L Engine
 unverified source
Transmission mount/case Transmission mount to Crossmember nuts 103 76
  • 6.2L Engine
 unverified source
Drive/Axle shaft Axle shaft housing carrier bushing bolt 115 85
  • 6.2L Engine
 unverified source
Drive/Axle shaft Lower front axle carrier mounting bushing bolt 115 85
  • 6.2L Engine
 unverified source
Drive/Axle shaft Upper front axle carrier mounting bushing bolt 115 85
  • 6.2L Engine
 unverified source

steering torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

exhaust torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Exhaust manifold Exhaust manifold nuts 25 18 Stage 1
  • 6.2L Engine
 unverified source
Exhaust manifold Exhaust manifold nuts 32 24 Stage 2
  • 6.2L Engine
 unverified source
Exhaust manifold Exhaust manifold studs 25 18
  • 6.2L Engine
 unverified source
Exhaust manifold Exhaust manifold heat shield bolts 12 9
  • 6.2L Engine
 unverified source
Exhaust manifold Exhaust manifold to Cylinder head stud 25 18
  • 6.2L Engine
 unverified source
Exhaust manifold Exhaust Y-pipe flange nuts 40 30
  • 6.2L Engine
 unverified source

brakes torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

suspension torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Stabilizer bar Stabilizer bar bracket nuts 55 41
  • 6.2L Engine
 unverified source

general torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
