Toyota Camry XV30 (2002-2006) Torque Spec Settings
By OSX - Own work, Public Domain
Below you'll find the tightening torques for the Toyota Camry XV30 in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.
Most-used torque settings for Toyota Camry XV30
| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Spark plugs | Spark plugs | 18 | 13 |
|
|
To make sure these are the correct tightening torque values, you can use the data below to verify this is the right model.
Are these torque settings right for you?
- Production years: 2002 - 2006
- Generation: 5
- Type of van: car
- Model variant: Base
- Also known as:
All Torque Settings in Tables
engine torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Oil pan | Oil Pan bolt | 9 | 7 |
|
|
|
| Oil pan | Oil Drain Plug | 25 | 18 |
|
|
|
| Oil pressure switch | Oil Pressure Switch | 15 | 11 |
|
|
|
| Oil pump | Oil Pump bolts | 19 | 14 |
|
|
|
| Oil pump | Oil Pump Body Cover bolts | 9 | 7 |
|
|
|
| Oil pump | Oil Pump Strainer nuts | 9 | 7 |
|
|
|
| Oil pump | Oil Pump Cover bolts | 10 | 7 |
|
|
|
| Oil pump | Oil Pump Relief Valve plug | 24 | 18 |
|
|
|
| Piston rods | Connecting Rod Cap bolts | 25 | 18 |
|
|
|
| Cylinder head | Cylinder Head Cover bolt and nut | 11 | 8 |
|
|
|
| Cylinder head | Cylinder Head bolt | 79 | 58 |
|
|
|
| Cylinder head | Cylinder Head Stud bolt (A&B) | 5 | 4 |
|
|
|
| Cylinder head | Cylinder Head Stud bolt (C&D) | 10 | 7 |
|
|
|
| Cylinder head | Cylinder Block Stud bolt (A&C) | 5 | 4 |
|
|
|
| Cylinder head | Cylinder Block Stud bolt (B) | 10 | 7 |
|
|
|
| Spark plugs | Spark plugs | 18 | 13 |
|
|
|
| Intake manifold | Intake Manifold bolt and nut | 30 | 22 |
|
|
|
| Intake manifold | Intake Manifold bolt and nutIntake Air control Valve Assy. mounting nut | 15 | 11 |
|
|
|
| Throttle body | Throttle body Assy. mounting bolt | 30 | 22 |
|
|
|
| Throttle body | Throttle body Assy. mounting bolt | 20 | 15 |
|
|
|
| Throttle body | Throttle body Assy. mounting nut | 20 | 15 |
|
|
|
| Throttle body | E.F.I. Throttle Position Sensor bolt | 2 | 1 |
|
|
|
| Engine mounts | Engine Mounting Bracket No.2 RH bolt | 52 | 38 |
|
|
|
| Engine mounts | Engine Mounting Stay No.2 RH bolt | 64 | 47 |
|
|
|
| Engine mounts | Engine Moving Control Rod bolt (w/ bracket) | 64 | 47 |
|
|
|
| Engine mounts | Transverse Engine Engine Mounting Bracket bolt | 54 | 40 |
|
|
|
| Engine mounts | Transverse Engine Engine Mounting Bracket nut | 96 | 71 |
|
|
|
| Engine mounts | Transverse Engine Engine Mounting Insulator RH nut (A) | 95 | 70 |
|
|
|
| Engine mounts | Transverse Engine Engine Mounting Insulator RH nut (B) | 87 | 64 |
|
|
|
| Engine mounts | Transverse Engine Engine Mounting Insulator FR bolt | 87 | 64 |
|
|
|
| Sensors | Speed Sensor Front LH mounting bolt | 8 | 6 |
|
|
|
| Sensors | Knock Control Sensor bolt | 39 | 29 |
|
|
|
| Sensors | Water Temperature Sensor | 20 | 15 |
|
|
|
| Sensors | Yawrate sensor to Body mounting bolt | 13 | 10 |
|
|
|
| Sensors | Skid control ECU to Body mounting nut | 6 | 4 |
|
|
|
| Sensors | Transmission revolution sensor mounting bolt | 11 | 8 |
|
|
|
| Sensors | Transmission revolution sensor mounting bolt | 11 | 8 |
|
|
|
| Sensors | Oxygen Sensor | 44 | 32 |
|
|
|
| Sensors | Oxygen Sensor | 44 | 32 |
|
|
|
| Alternator | Alternator Assy. bolts (M8) | 21 | 15 |
|
|
|
| Alternator | Alternator Assy. bolts (M10) | 52 | 38 |
|
|
|
| Alternator | Wiring Harnesss Clamp | 8 | 6 |
|
|
|
| Alternator | Generator Pulley bolt | 39 | 29 |
|
|
|
| Starter | Starter Yoke Assy. through bolts | 5 | 4 |
|
|
|
| Starter | Starter Yoke Assy. through bolts | 6 | 4 |
|
|
|
| Starter | Lead wire to terminal nut | 7 | 5 |
|
|
|
| Starter | Lead wire to terminal nut | 7 | 5 |
|
|
|
| Starter | Starter Assy mounting bolt | 42 | 31 |
|
|
|
| Starter | Starter Assy mounting nut | 10 | 7 |
|
|
|
| Battery | Ignition coil | 9 | 7 |
|
|
|
| Battery | Ignition coil | 8 | 6 |
|
|
|
| Camshaft | Camshaft Bearing cap bolt (No.1&No.2) | 30 | 22 |
|
|
|
| Camshaft | Camshaft Bearing cap bolt (No.3) | 9 | 7 |
|
|
|
| Camshaft | Camshaft Timing Gear Set bolt | 54 | 40 |
|
|
|
| Camshaft | Camshaft Timing Oil Control Valve | 9 | 7 |
|
|
|
| Crankshaft | Crankshaft Pulley bolt | 170 | 125 |
|
|
|
| Crankshaft | Crankshaft Main Bearing Cap bolt | 20 | 15 | Min. 20Nm, Max. 40Nm. |
|
|
| Crankshaft | Crankshaft Position sensor bolt | 9 | 7 |
|
|
|
| Water pump | Water Pump bolts | 9 | 7 |
|
|
|
| Water pump | Water Pump bolts | 9 | 7 |
|
|
|
| Water pump | Water Pump Pulley bolts | 26 | 19 |
|
|
|
| Radiator | Blower assy to Body | 2 | 1 |
|
|
|
| Radiator | Blower assy to Body | 2 | 1 |
|
|
|
| Radiator | Junction block to Instrument panel reinforcement mounting nut | 8 | 6 |
|
|
|
| Radiator | Junction block to Instrument panel reinforcement mounting nut | 8 | 6 |
|
|
|
| Radiator | Instrument panel brace sub–assy No. 1 to Instrument panel reinforcement mounting bolt and nut | 10 | 7 |
|
|
|
| Radiator | Instrument panel brace sub–assy No. 1 to Instrument panel reinforcement mounting bolt and nut | 10 | 7 |
|
|
|
| Radiator | Water Inlet Housing | 9 | 7 |
|
|
|
| Radiator | Water Inlet Housing | 8 | 6 |
|
|
|
| Radiator | Fan Assy. bolts (with motor) | 5 | 4 |
|
|
|
| Radiator | Fan Assy. bolts (with motor) | 5 | 4 |
|
|
|
| Radiator | Radiator Support bolts (Upper) | 14 | 10 |
|
|
|
| Radiator | Radiator Support bolts (Upper) | 14 | 10 |
|
|
|
| Air conditioning | Magnet clutch hub to Cooler compressor assy | 18 | 13 |
|
|
|
| Air conditioning | Magnet clutch hub to Cooler compressor assy | 18 | 13 |
|
|
|
| Air conditioning | Cooler refrigerant suction hose No.1 to Compressor and magnet clutch | 10 | 7 |
|
|
|
| Air conditioning | Cooler refrigerant suction hose No.1 to Compressor and magnet clutch | 10 | 7 |
|
|
|
| Air conditioning | Cooler refrigerant discharge hose No.1 to Compressor and magnet clutch | 10 | 7 |
|
|
|
| Air conditioning | Cooler refrigerant discharge hose No.1 to Compressor and magnet clutch | 10 | 7 |
|
|
|
| Air conditioning | Compressor and Magnetic Clutch to Engine mounting bolt and nut (Bolt A, B, C, F and Nut D) | 25 | 18 |
|
|
|
| Air conditioning | Compressor and Magnetic Clutch to Engine mounting bolt and nut (Bolt E) | 18 | 13 |
|
|
|
| Air conditioning | Compressor and Magnetic Clutch to Engine mounting bolt and nut | 25 | 18 |
|
|
|
| Air conditioning | Cap to Cooler condenser assy | 12 | 9 |
|
|
|
| Air conditioning | Cap to Cooler condenser assy | 12 | 9 |
|
|
|
| Air conditioning | Cooler condenser assy to Body mounting nut | 10 | 7 |
|
|
|
| Air conditioning | Cooler condenser assy to Body mounting nut | 10 | 7 |
|
|
|
| Air conditioning | Cooler refrigerant liquid pipe A and discharge hose No. 1 to Cooler condenser assy mounting bolt | 5 | 4 |
|
|
|
| Air conditioning | Cooler refrigerant liquid pipe A and discharge hose No. 1 to Cooler condenser assy mounting bolt | 5 | 4 |
|
|
|
| Air conditioning | Air conditioning tube assy to Cooler evaporator sub–assy No. 1 | 4 | 3 |
|
|
|
| Air conditioning | Air conditioning tube assy to Cooler evaporator sub–assy No. 1 | 4 | 3 |
|
|
|
| Air conditioning | Air conditioning radiator assy to Body | 2 | 1 |
|
|
|
| Air conditioning | Air conditioning radiator assy to Body | 2 | 1 |
|
|
|
| Belt tensioner/Timing chains | Chain Tensioner nut | 9 | 7 |
|
|
|
| Belt tensioner/Timing chains | V-ribbed Belt Tensioner Assy. mounting bolt and nut | 59 | 44 |
|
|
|
| Belt tensioner/Timing chains | Chain Tensioner plate mounting nut | 12 | 9 |
|
|
|
| Belt tensioner/Timing chains | Chain Vibration Damper No.1 mounting nut | 9 | 7 |
|
|
|
| Belt tensioner/Timing chains | Chain Tensioner Slipper mounting bolt | 19 | 14 |
|
|
|
| Belt tensioner/Timing chains | Timing Chain Cover mounting bolt (A) | 9 | 7 |
|
|
|
| Belt tensioner/Timing chains | Timing Chain Cover mounting bolt (B) | 21 | 15 |
|
|
|
| Belt tensioner/Timing chains | Timing Chain Cover mounting bolt (C) | 43 | 32 |
|
|
|
| Belt tensioner/Timing chains | Timing Chain Cover mounting nut | 9 | 7 |
|
|
|
| Belt tensioner/Timing chains | Drive Belt Tensioner Stud bolt | 10 | 7 |
|
|
|
| Belt tensioner/Timing chains | Idler Pulley pivot bolt | 34 | 25 |
|
|
|
| Fuel system | Fuel Delivery Pipe bolt (w/ injector) | 20 | 15 |
|
|
|
| Fuel system | Fuel Tank Vent Tube Set Plate bolt | 4 | 3 |
|
|
|
| Fuel system | Fuel Tank Vent Tube Set Plate bolt | 4 | 3 |
|
|
|
| Fuel system | Fuel Tank Band Sub–assy No.1 RH bolt | 39 | 29 |
|
|
|
| Fuel system | Fuel Tank Band Sub–assy No.1 RH bolt | 39 | 29 |
|
|
|
| Fuel system | Fuel Tank Band Sub–assy No.1 LH bolt | 39 | 29 |
|
|
|
| Fuel system | Fuel Tank Band Sub–assy No.1 LH bolt | 39 | 29 |
|
|
|
| Fuel system | Fuel Tank Protector Lower Center bolt | 5 | 4 |
|
|
|
| Fuel system | Fuel Tank Protector Lower Center bolt | 5 | 4 |
|
|
|
| Fuel system | Fuel Main Tube Support mounting bolt | 5 | 4 |
|
|
|
| Fuel system | Fuel Main Tube Support mounting bolt | 5 | 4 |
|
|
|
| Fuel system | Fuel Pressure Pulsation Damper Assy mounting bolt | 33 | 24 |
|
|
|
| Fuel system | Fuel Pressure Pulsation Damper Assy union bolt | 33 | 24 |
|
|
|
| Fuel system | Fuel Pressure Pulsation Damper Assy union bolt | 33 | 24 |
|
|
|
| Fuel system | Fuel Delivery Pipe No. 1 mounting bolt | 20 | 15 |
|
|
|
| Fuel system | Intake Air Surge Tank mounting bolt and nut | 43 | 32 |
|
|
|
| Fuel system | Fuel Delivery Pipe mounting bolt (w/ injector) | 10 | 7 |
|
|
|
| Fuel system | Engine Hanger No.1 bolt | 39 | 29 |
|
|
|
| Fuel system | Surge Tank Stay No.1 bolt | 20 | 15 |
|
|
|
| Fuel system | Charcoal canister bracket set bolt | 43 | 32 |
|
|
drivetrain torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Differential | Gear shift fork No. 1 set bolt | 24 | 18 |
|
|
|
| Differential | Gear shift fork No. 1 set bolt | 24 | 18 |
|
|
|
| Differential | Reverse shift arm bracket assy to Manual transaxle case mounting bolt | 17 | 13 |
|
|
|
| Differential | Reverse shift arm bracket assy to Manual transaxle case mounting bolt | 17 | 13 |
|
|
|
| Differential | Reverse restrict pin plug | 13 | 10 |
|
|
|
| Differential | Reverse restrict pin plug | 13 | 10 |
|
|
|
| Differential | Reverse idler gear shaft bolt | 30 | 22 |
|
|
|
| Differential | Reverse idler gear shaft bolt | 30 | 22 |
|
|
|
| Differential | Manual transmission output shaft rear set nut | 123 | 91 |
|
|
|
| Differential | Manual transmission output shaft rear set nut | 123 | 91 |
|
|
|
| Differential | Manual transmission filler plug | 49 | 36 |
|
|
|
| Differential | Manual transmission filler plug | 49 | 36 |
|
|
|
| Differential | Front differential ring gear bolts | 106 | 78 |
|
|
|
| Differential | Front differential ring gear bolts | 106 | 78 |
|
|
|
| Clutch assembly | Clutch pedal sub–assy to Clutch pedal support mounting bolt and nut | 37 | 27 |
|
|
|
| Clutch assembly | Clutch pedal sub–assy to Clutch pedal support mounting bolt and nut | 37 | 27 |
|
|
|
| Clutch assembly | Clutch start switch assy set nut | 16 | 12 |
|
|
|
| Clutch assembly | Clutch start switch assy set nut | 16 | 12 |
|
|
|
| Clutch assembly | Clutch cover assy to Flywheel mounting bolt | 19 | 14 |
|
|
|
| Clutch assembly | Clutch cover assy to Flywheel mounting bolt | 19 | 14 |
|
|
|
| Clutch assembly | Cylinder push rod clevis lock nut | 26 | 19 |
|
|
|
| Clutch assembly | Cylinder push rod clevis lock nut | 26 | 19 |
|
|
|
| Clutch assembly | Clutch master cylinder assy to Clutch pedal support mouting nut | 12 | 9 |
|
|
|
| Clutch assembly | Clutch master cylinder assy to Clutch pedal support mouting nut | 12 | 9 |
|
|
|
| Clutch assembly | Clutch master cylinder assy to Flexible hose tube | 15 | 11 |
|
|
|
| Clutch assembly | Clutch master cylinder assy to Flexible hose tube | 15 | 11 |
|
|
|
| Clutch assembly | Clutch tube bracket set bolt | 17 | 13 |
|
|
|
| Clutch assembly | Clutch tube bracket set bolt | 17 | 13 |
|
|
|
| Flywheel | Flywheel Sub-assy. bolts | 130 | 96 |
|
|
|
| Flywheel | Drive Plate and Ring gear sub-assy. bolt | 98 | 72 |
|
|
|
| Transmission fluid pan | Transmission drain plug | 49 | 36 |
|
|
|
| Transmission fluid pan | Transmission drain plug | 49 | 36 |
|
|
|
| Transmission mount/case | Transaxle housing to Engine block mounting bolts (Bolt A) | 64 | 47 |
|
|
|
| Transmission mount/case | Transaxle housing to Engine block mounting bolts (Bolt B) | 44 | 32 |
|
|
|
| Transmission mount/case | Transaxle housing to Engine block mounting bolts (Bolt A) | 64 | 47 |
|
|
|
| Transmission mount/case | Transaxle housing to Engine block mounting bolts (Bolt B) | 46 | 34 |
|
|
|
| Transmission mount/case | Transaxle housing to Engine block mounting bolts (Bolt C) | 44 | 32 |
|
|
|
| Transmission mount/case | Transmission wire to Transaxle mounting bolt | 5 | 4 |
|
|
|
| Transmission mount/case | Transmission wire to Transaxle mounting bolt | 5 | 4 |
|
|
|
| Transmission mount/case | ATF temperature sensor to Valve body mounting bolt | 7 | 5 |
|
|
|
| Transmission mount/case | ATF temperature sensor to Valve body mounting bolt | 7 | 5 |
|
|
|
| Transmission mount/case | Oil pan to Transaxle mounting bolt | 8 | 6 |
|
|
|
| Transmission mount/case | Oil pan to Transaxle mounting bolt | 8 | 6 |
|
|
|
| Transmission mount/case | Solenoid valve to Valve body mounting bolt (Bolt A) | 7 | 5 |
|
|
|
| Transmission mount/case | Solenoid valve to Valve body mounting bolt (Bolt A) | 7 | 5 |
|
|
|
| Transmission mount/case | Solenoid valve to Valve body mounting bolt (Bolt B) | 11 | 8 |
|
|
|
| Transmission mount/case | Solenoid valve to Valve body mounting bolt (Bolt B) | 11 | 8 |
|
|
|
| Transmission mount/case | Valve body to transaxle mounting bolt | 11 | 8 |
|
|
|
| Transmission mount/case | Valve body to transaxle mounting bolt | 11 | 8 |
|
|
|
| Transmission mount/case | Oil strainer to Valve body mounting bolt | 11 | 8 |
|
|
|
| Transmission mount/case | Oil strainer to Valve body mounting bolt | 11 | 8 |
|
|
|
| Transmission mount/case | Manual Transmission case protector mounting bolt | 18 | 13 |
|
|
|
| Transmission mount/case | Manual Transmission case protector mounting bolt | 18 | 13 |
|
|
|
| Transmission mount/case | Transmission case to Manual transaxle case mounting bolt | 29 | 21 |
|
|
|
| Transmission mount/case | Transmission case to Manual transaxle case mounting bolt | 29 | 21 |
|
|
|
| Transmission mount/case | Manual transaxle case receiver to Manual transaxle case mounting bolt | 7 | 5 |
|
|
|
| Transmission mount/case | Manual transaxle case receiver to Manual transaxle case mounting bolt | 7 | 5 |
|
|
|
| Transmission mount/case | Back up lamp switch assy to Manual transmission case mounting bolt | 40 | 30 |
|
|
|
| Transmission mount/case | Back up lamp switch assy to Manual transmission case mounting bolt | 40 | 30 |
|
|
|
| Transmission mount/case | Manual transmission breather plug to Manual transmission case mounting bolt | 49 | 36 |
|
|
|
| Transmission mount/case | Manual transmission breather plug to Manual transmission case mounting bolt | 49 | 36 |
|
|
|
| Transmission mount/case | Lock ball assy No. 1 to Manual transmission case mounting bolt | 29 | 21 |
|
|
|
| Transmission mount/case | Lock ball assy No. 1 to Manual transmission case mounting bolt | 29 | 21 |
|
|
|
| Transmission mount/case | Selecting ballcrank assy to Manual transmission case mounting bolt | 20 | 15 |
|
|
|
| Transmission mount/case | Selecting ballcrank assy to Manual transmission case mounting bolt | 20 | 15 |
|
|
|
| Transmission mount/case | Release fork support to Manual transmission case mounting bolt | 47 | 35 |
|
|
|
| Transmission mount/case | Release fork support to Manual transmission case mounting bolt | 47 | 35 |
|
|
|
| Torque converter | Torque converter clutch mounting bolts | 41 | 30 |
|
|
|
| Torque converter | Torque converter clutch mounting bolts | 41 | 30 |
|
|
|
| Transfer | "Floor Shift Cable Transmission Control Shift nut" | 15 | 11 |
|
|
|
| Transfer | Park/neutral position switch bolt | 7 | 5 |
|
|
|
| Transfer | Park/neutral position switch nut | 5 | 4 |
|
|
|
| Transfer | Control shaft lever to Control shaft nut | 13 | 10 |
|
|
|
| Transfer | Control shaft cover set bolt | 20 | 15 |
|
|
|
| Transfer | Control shaft cover set bolt | 20 | 15 |
|
|
|
| Transfer | Control shift lever to Shift & select lever shaft mounting bolt | 6 | 4 |
|
|
|
| Transfer | Control shift lever to Shift & select lever shaft mounting bolt | 6 | 4 |
|
|
|
| Drive/Axle shaft | Drive Shaft Bearing Bracket bolt | 64 | 47 |
|
|
|
| Drive/Axle shaft | Axle hub LH nut | 294 | 217 |
|
|
|
| Drive/Axle shaft | Axle hub LH nut | 294 | 217 |
|
|
steering torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Tie rod end | Tie Rod Assy LH nut | 49 | 36 |
|
|
|
| Tie rod end | Tie Rod End Lock nuts | 74 | 55 |
|
|
|
| Pinion | Control valve housing set bolt | 21 | 15 |
|
|
|
| Pinion | Control valve housing set bolt | 21 | 15 |
|
|
|
| Pinion | Control valve shaft lock nut | 25 | 18 |
|
|
|
| Pinion | Control valve shaft lock nut | 25 | 18 |
|
|
|
| Pinion | Rack housing cap | 59 | 44 |
|
|
|
| Pinion | Rack housing cap | 59 | 44 |
|
|
|
| Pinion | Rack guide spring cap nut | 48 | 35 | Min. 48Nm, Max. 68.5Nm. |
|
|
| Pinion | Rack guide spring cap nut | 48 | 35 | Min. 48Nm, Max. 68.5Nm. |
|
|
| Pinion | Pressure feed and return tubes to Control valve housing | 22.5 | 17 | Min. 22.5Nm. Max. 24.5Nm. |
|
|
| Pinion | Pressure feed and return tubes to Control valve housing | 22.5 | 17 | Min. 22.5Nm. Max. 24.5Nm. |
|
|
| Steering rack | Power steering rack to Steering rack end sub–assy | 58.5 | 43 | Min. 58.5Nm. Max. 83.5Nm. |
|
|
| Steering rack | Power steering rack to Steering rack end sub–assy | 58.5 | 43 | Min. 58.5Nm. Max. 83.5Nm. |
|
|
| Steering rack | Control valve shaft lock nut | 25 | 18 |
|
|
|
| Steering rack | Control valve shaft lock nut | 25 | 18 |
|
|
|
| Steering rack | Turn pressure tube union nut | 11.5 | 8 | Min. 11.5Nm. Max. 12.5Nm. |
|
|
| Steering rack | Turn pressure tube union nut | 11.5 | 8 | Min. 11.5Nm. Max. 12.5Nm. |
|
|
| Steering rack | Rack & pinion power steering gear assy set bolt and nut | 70 | 52 |
|
|
|
| Steering rack | Rack & pinion power steering gear assy set bolt and nut | 70 | 52 |
|
|
|
| Steering rack | Pressure feed tube clamp set bolt | 10 | 7 |
|
|
|
| Steering rack | Pressure feed tube clamp set bolt | 10 | 7 |
|
|
|
| Steering rack | Return tube assy clamp set nut | 10 | 7 |
|
|
|
| Steering rack | Return tube assy clamp set nut | 10 | 7 |
|
|
|
| Steering column | Steering column assembly set bolt and nut | 21 | 15 |
|
|
|
| Steering column | Steering column assembly set bolt and nut | 21 | 15 |
|
|
|
| Steering shaft | Steering Intermediate Shaft Sub-assy. bolt" | 35 | 26 |
|
|
|
| Steering wheel | Steering wheel set nut | 50 | 37 |
|
|
|
| Steering wheel | Steering wheel set nut | 50 | 37 |
|
|
|
| Power steering pump | Vane pump housing rear to Vane pump ousing front mounting bolt | 22 | 16 |
|
|
|
| Power steering pump | Vane pump housing rear to Vane pump ousing front mounting bolt | 24 | 18 |
|
|
|
| Power steering pump | Pressure port union | 69 | 51 |
|
|
|
| Power steering pump | Pressure port union | 83 | 61 |
|
|
|
| Power steering pump | Power steering suction port union set bolt | 12 | 9 |
|
|
|
| Power steering pump | Power steering suction port union set bolt | 13 | 10 |
|
|
|
| Power steering pump | Power steering oil pressure switch | 21 | 15 |
|
|
|
| Power steering pump | Power steering oil pressure switch | 21 | 15 |
|
|
|
| Power steering pump | Pressure feed tube assy to Vane pump assy union bolt | 52 | 38 |
|
|
|
| Power steering pump | Pressure feed tube assy to Vane pump assy union bolt | 52 | 38 |
|
|
|
| Power steering pump | Vane pump assy set bolt (A) | 30 | 22 |
|
|
|
| Power steering pump | Vane pump assy set bolt (B) | 43 | 32 |
|
|
|
| Power steering pump | Vane pump assy set bolt | 43 | 32 |
|
|
|
| Power steering pump | Pump bracket front and Vane pump bracket rear bolt (Type A) | 43 | 32 |
|
|
|
| Power steering pump | Pump bracket front and Vane pump bracket rear bolt (Type B) | 44 | 32 |
|
|
|
| Power steering pump | Vane pump pulley set nut (Type A) | 44 | 32 |
|
|
exhaust torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Exhaust manifold | Manifold Converter Insulator No.1 mounting bolt | 12 | 9 |
|
|
|
| Exhaust manifold | Exhaust Manifold Converter Sub–assy mounting nut | 37 | 27 |
|
|
|
| Exhaust manifold | Manifold Stay mounting bolt and nut | 44 | 32 |
|
|
|
| Exhaust manifold | Exhaust Manifold Heat bolt (No.1) | 12 | 9 |
|
|
|
| Exhaust manifold | Front Pipe to Exhaust Manifold Converter nut | 62 | 46 |
|
|
|
| Exhaust manifold | Front Pipe to Exhaust Manifold Converter nut (No.2) | 62 | 46 |
|
|
|
| Exhaust manifold | Front Pipe to Exhaust Manifold Converter RH bolt | 62 | 46 |
|
|
|
| Exhaust manifold | Exhaust Pipe No. 1 Support Bracket mounting nut | 33 | 24 |
|
|
|
| Exhaust manifold | Exhaust Pipe No. 1 Support Bracket mounting nut | 33 | 24 |
|
|
|
| Exhaust manifold | Exhaust Pipe No. 1 Support Bracket mounting bolt | 33 | 24 |
|
|
|
| Exhaust manifold | Exhaust Pipe No. 1 Support Bracket mounting bolt | 33 | 24 |
|
|
|
| EGR | E.G.R Gas Temparature Sensor | 20 | 15 |
|
|
|
| EGR | E.G.R Gas Temparature Sensor | 20 | 15 |
|
|
|
| EGR | E.G.R Valve assy. mounting nut | 12 | 9 |
|
|
|
| EGR | E.G.R Valve assy. mounting nut | 12 | 9 |
|
|
|
| EGR | E.G.R Pipe Sub-assy. No.2 mounting nut | 12 | 9 |
|
|
|
| EGR | E.G.R Pipe Sub-assy. No.2 mounting nut | 12 | 9 |
|
|
|
| Muffler | Center Pipe to Tail Pipe nut | 56 | 41 |
|
|
|
| Muffler | Center Pipe to Tail Pipe nut | 56 | 41 |
|
|
|
| Muffler | Exhaust Pipe Damper bolt | 19 | 14 |
|
|
|
| Catalytic converter | Front pipe to Center Pipe bolt | 56 | 41 |
|
|
|
| Catalytic converter | Front pipe to Center Pipe bolt | 56 | 41 |
|
|
|
| Catalytic converter | Floor Panel Brace Rear mounting bolt | 20 | 15 |
|
|
brakes torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Disc brake | Rear Disc Brake Caliper bolts | 62 | 46 |
|
|
|
| Disc brake | Rear Disc Brake Caliper bolts | 62 | 46 |
|
|
|
| Disc brake | Bleeder plug | 8 | 6 |
|
|
|
| Disc brake | Bleeder plug | 8 | 6 |
|
|
|
| Disc brake | Brake cylinder mounting to Steering knuckle bolts | 107 | 79 |
|
|
|
| Disc brake | Brake cylinder mounting to Steering knuckle bolts | 107 | 79 |
|
|
|
| Disc brake | Disc brake cylinder bolts | 34 | 25 |
|
|
|
| Disc brake | Disc brake cylinder bolts | 34 | 25 |
|
|
|
| Disc brake | Brake cylinder and Flexible hose union bolt | 29 | 21 |
|
|
|
| Disc brake | Brake cylinder and Flexible hose union bolt | 29 | 21 |
|
|
|
| Disc brake | Rear disc brake cylinder mounting set bolt (TMC made) | 62 | 46 |
|
|
|
| Disc brake | Rear disc brake cylinder mounting set bolt (TMC made) | 62 | 46 |
|
|
|
| Disc brake | Rear disc brake cylinder mounting set bolt (TMMK made) | 47 | 35 |
|
|
|
| Disc brake | Rear disc brake cylinder mounting set bolt (TMMK made) | 47 | 35 |
|
|
|
| Disc brake | Rear Disc Brake Cylinder Slide Pin(Upper) (TMC made) | 34 | 25 |
|
|
|
| Disc brake | Rear Disc Brake Cylinder Slide Pin(Upper) (TMC made) | 34 | 25 |
|
|
|
| Disc brake | Rear Disc Brake Cylinder Slide Pin(Lower) (TMC made) | 39 | 29 |
|
|
|
| Disc brake | Rear Disc Brake Cylinder Slide Pin(Lower) (TMC made) | 39 | 29 |
|
|
|
| Disc brake | Rear Disc Brake Cylinder Slide Pin (TMMK made) | 43 | 32 |
|
|
|
| Disc brake | Rear Disc Brake Cylinder Slide Pin (TMMK made) | 43 | 32 |
|
|
|
| Brake booster | Brake tube to master cylinder nut | 15 | 11 |
|
|
|
| Brake booster | Brake tube to master cylinder nut | 15 | 11 |
|
|
|
| Brake booster | Brake booster clevis lock nut | 26 | 19 |
|
|
|
| Brake booster | Brake booster clevis lock nut | 26 | 19 |
|
|
|
| Brake booster | Vacuum hose bracket set bolt | 5 | 4 |
|
|
|
| Brake booster | Vacuum hose bracket set bolt | 5 | 4 |
|
|
|
| Brake booster | Charcoal canister bracket set bolt | 43 | 32 |
|
|
|
| Brake pedal | Brake pedal sub–assy set bolt | 37 | 27 |
|
|
|
| Brake pedal | Brake pedal sub–assy set bolt | 37 | 27 |
|
|
|
| Brake pedal | Stop lamp lock nut | 26 | 19 |
|
|
|
| Brake pedal | Stop lamp lock nut | 26 | 19 |
|
|
|
| Brake pedal | Brake pedal support assy and Reinforcement mounting bolt | 20 | 15 |
|
|
|
| Brake pedal | Brake pedal support assy and Reinforcement mounting bolt | 20 | 15 |
|
|
|
| Brake pedal | Brake pedal support assy and Body mounting nuts | 13 | 10 |
|
|
|
| Brake pedal | Brake pedal support assy and Body mounting nuts | 13 | 10 |
|
|
|
| Master cylinder | Master cylinder piston stopper bolt | 10 | 7 |
|
|
|
| Master cylinder | Master cylinder piston stopper bolt | 10 | 7 |
|
|
|
| Master cylinder | Brake master cylinder to Brake booster | 13 | 10 |
|
|
|
| Master cylinder | Brake master cylinder to Brake booster | 13 | 10 |
|
|
|
| Parking brake | Parking brake cable lock nut (Pedal type) | 5 | 4 |
|
|
|
| Parking brake | Parking brake cable lock nut (Pedal type) | 5 | 4 |
|
|
|
| Parking brake | Parking brake cable lock nut (Lever type) | 5 | 4 |
|
|
|
| Parking brake | Parking brake cable lock nut (Lever type) | 5 | 4 |
|
|
|
| Parking brake | Parking brake lever set bolt | 13 | 10 |
|
|
|
| Parking brake | Parking brake lever set bolt | 13 | 10 |
|
|
|
| Parking brake | Parking brake control pedal set bolt | 39 | 29 |
|
|
|
| Parking brake | Parking brake control pedal set bolt | 39 | 29 |
|
|
|
| Parking brake | Console box mounting set bolt | 13 | 10 |
|
|
|
| Parking brake | Console box mounting set bolt | 13 | 10 |
|
|
|
| Parking brake | Parking brake cable No. 1 to Turn buckle mounting bolt and nut | 5 | 4 |
|
|
|
| Parking brake | Parking brake cable No. 1 to Turn buckle mounting bolt and nut | 5 | 4 |
|
|
|
| Parking brake | Parking brake cable heart insulator set nut | 5 | 4 |
|
|
|
| Parking brake | Parking brake cable heart insulator set nut | 5 | 4 |
|
|
|
| Parking brake | Parking brake cable No. 3 to Backing plate bolt | 8 | 6 |
|
|
|
| Parking brake | Parking brake cable No. 3 to Backing plate bolt | 8 | 6 |
|
|
|
| Parking brake | Parking brake cable No. 4 to Body bolt | 13 | 10 |
|
|
|
| Parking brake | Parking brake cable No. 4 to Body bolt | 13 | 10 |
|
|
|
| ABS | ABS Speed sensor wire harness bolts | 6 | 4 |
|
|
|
| ABS | ABS Speed sensor wire harness bolts | 6 | 4 |
|
|
|
| Brake actuator | Brake actuator assy to Actuator bracket mounting nut | 5 | 4 |
|
|
|
| Brake actuator | Brake actuator assy to Actuator bracket mounting nut | 5 | 4 |
|
|
|
| Brake actuator | Brake actuator bracket to Body mounting nuts | 19 | 14 |
|
|
|
| Brake actuator | Brake actuator bracket to Body mounting nuts | 19 | 14 |
|
|
|
| Proportioning valve | Proportioning valve assy to Body mounting bolt | 5 | 4 |
|
|
|
| Proportioning valve | Proportioning valve assy to Body mounting bolt | 5 | 4 |
|
|
|
| Proportioning valve | Proportioning valve assy to Brake line | 15 | 11 |
|
|
|
| Proportioning valve | Proportioning valve assy to Brake line | 15 | 11 |
|
|
suspension torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to | |
|---|---|---|---|---|---|---|
| Wheels | Wheel Lug nuts | 103 | 76 |
|
|
|
| Shock absorbers/shocks | Front Shock Absorber upper nuts | 80 | 59 |
|
|
|
| Shock absorbers/shocks | Front Shock Absorber lower bolts and nuts | 210 | 155 |
|
|
|
| Shock absorbers/shocks | Front/Rear Shock Absorber lock nut | 49 | 36 |
|
|
|
| Shock absorbers/shocks | Dynamic damper bolts | 29 | 21 |
|
|
|
| Shock absorbers/shocks | Rear Shock Absorber upper nuts | 39 | 29 |
|
|
|
| Shock absorbers/shocks | Rear Shock Absorber lower bolts and nuts | 255 | 188 |
|
|
|
| Shock absorbers/shocks | Front Shock Absorber lock nut | 49 | 36 |
|
|
|
| Stabilizer bar | Front/Rear Stabilizer bar bracket bolts | 19 | 14 |
|
|
|
| Sway bar links/Stabilizer links | Front Stabilzer link nut | 74 | 55 |
|
|
|
| Sway bar links/Stabilizer links | Rear Stabilzer link nut | 39 | 29 |
|
|
|
| Control arm | Front Suspension Arm lower bolts (front) | 200 | 148 |
|
|
|
| Control arm | Front Suspension Arm lower bolts (rear) | 206 | 152 |
|
|
|
| Control arm | Rear Suspension Arm lower bolts | 100 | 74 |
|
|
|
| Control arm | Strut Rod bolt | 113 | 83 |
|
|
|
| Ball joint | Lower Ball Joint Assy bolt and nut | 127 | 94 |
|
|
general torque settings
Save to email ✉️| Part | Description | Torque (Nm) | Torque (ft/lbs) | Remarks | Applies to |
|---|
By OSX - Own work, Public Domain
Did you find the answer to your specific question?
👍 0 👎 3
