Toyota 4Runner 5 (2010-on) Torque Spec Settings

Researched by Wan Wei Tay
Updated: November 05, 2023

By Kevauto - Own work, CC BY-SA 4.0

Below you'll find the tightening torques for the Toyota 4Runner 5 in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.

Most-used torque specs for Toyota 4Runner 5

Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

To make sure these are the correct tightening torque values, you can use the data below to verify this is the right model.

Are these torque settings right for you?

  • Production years: 2010 - present
  • Generation: 5
  • Type of van: car
  • Model variant: Base

All Torque Settings in Tables

engine torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Drain plug to No.2 oil pan 40 30
  • 1GR-FE
verified source
Oil pan Oil pan drain plug to No.2 oil pan 38 28
  • 2TR-FE
verified source
Oil pan Oil pan to Cylinder block bolts and nut 21 15 For bolts A, B, C, E and nut
  • 1GR-FE
verified source
Oil pan Oil pan to Cylinder block bolt 10 7 For bolt D
  • 1GR-FE
verified source
Oil pan Oil pan to Cylinder block and Timing chain cover 26 19
  • 2TR-FE
verified source
Oil pan Oil pan stud bolt 10 7 For stud bolt A
  • 1GR-FE
verified source
Oil pan Oil pan stud bolts 4 3 For stud bolts B
  • 1GR-FE
verified source
Oil pan Oil pan stud bolt 8 6 Stud bolt A
  • 2TR-FE
verified source
Oil pan Oil pan stud bolt 3 2 Stud bolt B
  • 2TR-FE
verified source
Oil pan No.1 oil pan baffle plate to Oil pan 10 7
  • 1GR-FE
verified source
Oil pan No.2 oil pan to Oil pan 10 7
  • 1GR-FE
verified source
Oil pan No.2 oil pan to Oil pan 9 7
  • 2TR-FE
verified source
Oil filter Oil filter to Oil filter bracket 25 18
  • 1GR-FE
verified source
Oil filter Oil filter to Oil filter bracket 17 13
  • 2TR-FE
verified source
Oil filter Oil filter drain plug to Oil filter 13 10
  • 1GR-FE
verified source
Oil filter Oil filter bracket to Timing chain cover 21 15
  • 1GR-FE
verified source
Oil filter Oil filter bracket union to Cylinder block 25 18
  • 2TR-FE
verified source
Oil filter Oil filter bracket to Screw plug 49 36
  • 2TR-FE
verified source
Oil filter Oil filter bracket to Cylinder block 25 18
  • 2TR-FE
verified source
Oil filter Oil filter union to Oil filter bracket 43 32
  • 2TR-FE
verified source
Oil filter Oil strainer to Oil pan 9 7
  • 1GR-FE
verified source
Oil filter Oil strainer to Oil pan 26 19
  • 2TR-FE
verified source
Oil pressure switch Engine oil pressure switch to Timing chain cover 15 11
  • 1GR-FE
verified source
Oil pressure switch Oil pressure switch to Cylinder block 15 11
  • 2TR-FE
verified source
Oil dipstick Engine oil level dipstick guide to Timing chain cover 10 7
  • 1GR-FE
verified source
Oil dipstick Engine oil level dipstick guide to Front No.1 engine mounting bracket 20 15
  • 2TR-FE
verified source
Oil feeder Oil filler cap housing to Cylinder head cover LH 10 7
  • 1GR-FE
verified source
Oil pump Oil pump to Transmission case 21 15
  • A343E Automatic Transmission
verified source
Oil pump Oil pump to Transmission case 21 15
  • A750E Automatic Transmission
verified source
Oil pump Oil pump to Transmission case 21 15
  • A750F Automatic Transmission
verified source
Oil pump Oil pump body to Stator shaft 10 7
  • A343E Automatic Transmission
verified source
Oil pump Oil pump body to Stator shaft 11 8
  • A750E Automatic Transmission
verified source
Oil pump Oil pump body to Stator shaft 11 8
  • A750F Automatic Transmission
verified source
Oil pump Oil pump relief valve plug to Oil pump cover 49 36
  • 1GR-FE
verified source
Oil pump Oil pump relief valve plug to Timing chain cover 49 36
  • 2TR-FE
verified source
Oil pump Oil pump cover to Timing chain cover screw 10 7
  • 1GR-FE
verified source
Oil pump Oil pump cover to Timing chain cover bolt 9 7
  • 1GR-FE
verified source
Oil pump Oil pump cover to Timing chain cover 9 7
  • 2TR-FE
verified source
Piston rods Connecting rod cap to Connecting rod 25 18 Step 1
  • 1GR-FE
verified source
Piston rods Connecting rod cap to Connecting rod 25 18 Step 1
  • 2TR-FE
verified source
Cylinder head Cylinder head to Cylinder block 38 28 Step 1
  • 1GR-FE
verified source
Cylinder head Cylinder head to Cylinder block 39 29
  • 2TR-FE
verified source
Cylinder head Cylinder head LH to Cylinder block 36 27 For cylinder head set bolt, Step 1
  • 1GR-FE
verified source
Cylinder head Cylinder head LH to Cylinder block 30 22 Except cylinder head set bolt
  • 1GR-FE
verified source
Cylinder head Cylinder head stud bolt 10 7 For bolt A
  • 1GR-FE
verified source
Cylinder head Cylinder head stud bolt 4 3 For bolt B
  • 1GR-FE
verified source
Cylinder head Cylinder head stud bolt 3 2 Stud bolt A
  • 2TR-FE
verified source
Cylinder head Cylinder head stud bolt 8 6 Stud bolt B
  • 2TR-FE
verified source
Cylinder head Cylinder head stud bolt 8 6 Stud bolt C
  • 2TR-FE
verified source
Cylinder head No.1 straight screw plug to Cylinder head 44 32
  • 1GR-FE
verified source
Cylinder head No.1 head straight screw plug to Cylinder head 44 32
  • 2TR-FE
verified source
Cylinder head No.2 straight screw plug to Cylinder head 80 59
  • 1GR-FE
verified source
Cylinder head No.2 head straight screw plug to Cylinder head 140 103
  • 2TR-FE
verified source
Cylinder head Engine hanger to Cylinder head 33 24
  • 1GR-FE
verified source
Cylinder head No.1 engine hanger to Cylinder head 42 31
  • 2TR-FE
verified source
Cylinder head Fuel pipe to Cylinder head cover LH 9 7
  • 1GR-FE
verified source
Cylinder head No.1 oil pipe to Cylinder head and cylinder head cover 65 48
  • 1GR-FE
verified source
Cylinder head No.2 oil pipe to Cylinder head and cylinder head cover 65 48
  • 1GR-FE
verified source
Cylinder head No.1 chain tensioner to Cylinder head RH 10 7
  • 1GR-FE
verified source
Cylinder head Cylinder head cover stud bolt 4 3
  • 1GR-FE
verified source
Cylinder head Rear cylinder head cover to Cylinder head cover and cylinder block 9 7
  • 1GR-FE
verified source
Cylinder head Cylinder head cover to Cylinder head and Timing chain cover 9 7
  • 2TR-FE
verified source
Cylinder head No.1 surge tank stay to Cylinder head sub-assembly LH 21 15
  • 1GR-FE
verified source
Cylinder head No.2 surge tank stay to Cylinder head sub-assembly LH 21 15
  • 1GR-FE
verified source
Spark plugs Spark plug to Cylinder head 18 13
  • 1GR-FE
verified source
Spark plugs Spark plug to Cylinder head 18 13
  • 2TR-FE
verified source
Intake manifold Intake air surge tank to Intake manifold 28 21
  • 1GR-FE
verified source
Intake manifold Intake manifold to Cylinder head sub-assembly LH, RH 21 15
  • 1GR-FE
verified source
Intake manifold Intake manifold to Cylinder head 25 18
  • 2TR-FE
verified source
Intake manifold Purge VSV to Intake air surge tank 9 7
  • 1GR-FE
verified source
Intake manifold Purge VSV to Intake manifold 9 7
  • 2TR-FE
verified source
Intake manifold Wiring harness clamp bracket to Intake manifold 8 6
  • 2TR-FE
verified source
Intake manifold No.1 air cleaner hose clamp 5 4
  • 1GR-FE
verified source
Intake manifold Air cleaner cap hose clamp 5 4
  • 2TR-FE
verified source
Intake manifold No.1 air cleaner hose bolt 5 4
  • 1GR-FE
verified source
Intake manifold Air cleaner case to Body 12 9
  • 2TR-FE
verified source
Throttle body Throttle body to Intake air surge tank 10 7
  • 1GR-FE
verified source
Throttle body Throttle body bracket to Intake air surge tank 21 15
  • 1GR-FE
verified source
Throttle body Throttle body with motor assembly to Intake manifold 9 7
  • 2TR-FE
verified source
Engine block Cylinder block water drain cock to Cylinder block 30 22
  • 1GR-FE
verified source
Engine block Cylinder block water drain cock to Cylinder block 25 18
  • 2TR-FE
verified source
Engine block Cylinder block water drain cock plug to Cylinder block water drain cock 13 10
  • 1GR-FE
verified source
Engine block Cylinder block drain cock plug to Cylinder block drain cock 13 10
  • 2TR-FE
verified source
Engine block Cylinder block stud bolts 10 7 For stud bolts A
  • 1GR-FE
verified source
Engine block Cylinder block stud bolts 4 3 For stud bolts B
  • 1GR-FE
verified source
Engine block PCV valve sub-assembly to Cylinder head cover sub-assembly LH 27 20
  • 1GR-FE
verified source
Engine block PCV valve to Cylinder head cover 5 4
  • 2TR-FE
verified source
Engine block Oil seal retainer to Cylinder block 10 7
  • 1GR-FE
verified source
Engine block Oil seal retainer to Cylinder block 13 10
  • 2TR-FE
verified source
Engine block No.1 chain vibration damper to Cylinder head LH and cylinder block 23 17
  • 1GR-FE
verified source
Engine block No.1 chain vibration damper to Cylinder block and cylinder head bolt 21 15
  • 2TR-FE
verified source
Engine block No.1 chain vibration damper to Cylinder block and cylinder head nut 18 13
  • 2TR-FE
verified source
Engine block No.1 idler gear shaft to Cylinder block 60 44
  • 1GR-FE
verified source
Engine block No.1 oil nozzle to Cylinder block 9 7
  • 1GR-FE
verified source
Engine block No.1 oil nozzle to Cylinder block 7 5
  • 2TR-FE
verified source
Engine block No.1 chain tensioner to Cylinder block 10 7
  • 2TR-FE
verified source
Engine mounts Front No.1 engine mounting bracket RH to Cylinder block 43 32
  • 1GR-FE
verified source
Engine mounts Front No.1 engine mounting bracket RH to Cylinder block 51 38
  • 2TR-FE
verified source
Engine mounts Front No.1 engine mounting bracket LH to Cylinder block 43 32
  • 1GR-FE
verified source
Engine mounts Front No.1 engine mounting bracket LH to Cylinder block 51 38
  • 2TR-FE
verified source
Engine mounts Front engine mounting insulator to Front No.1 engine mounting bracket 46 34
  • 2TR-FE
verified source
Engine mounts Front engine mounting insulator LH to Harness bracket 13 10
  • 2TR-FE
verified source
Engine mounts Engine mount insulator to Engine mount bracket 72 53
  • 1GR-FE
verified source
Engine mounts Engine mount insulator to Body 40 30
  • 1GR-FE
verified source
Engine mounts Engine mounting insulator to Body 40 30
  • 2TR-FE
verified source
Engine mounts Rear engine mounting heat insulator to Rear no.1 engine mounting insulator 12 9
  • 2TR-FE
verified source
Engine mounts Rear No.1 engine mounting insulator to Transmission 65 48
  • 2TR-FE
verified source
Engine mounts No.3 frame crossmember to Rear no.1 engine mounting insulator 30 22
  • 2TR-FE
verified source
Engine mounts Rear engine under cover to Body 29 21
  • 1GR-FE
verified source
Engine mounts Rear engine under cover to Body 29 21
  • 2TR-FE
verified source
Engine mounts No.1 engine under cover to Body 29 21
  • 1GR-FE
verified source
Engine mounts No.1 engine under cover to Body 29 21
  • 2TR-FE
verified source
Engine mounts Engine under cover seal to No.1 engine under cover 29 21
  • 1GR-FE
verified source
Engine mounts Engine under cover seal to Rear engine under cover 29 21
  • 2TR-FE
verified source
Sensor Accelerator pedal sensor to Body 5 4
  • 1GR-FE
verified source
Sensor Accelerator pedal position sensor assembly to Body 5 4
  • 2TR-FE
verified source
Sensor VVT sensor to Cylinder head 10 7
  • 1GR-FE
verified source
Sensor Camshaft position sensor to Timing chain cover 9 7
  • 2TR-FE
verified source
Sensor Crankshaft position sensor to Cylinder block 10 7
  • 1GR-FE
verified source
Sensor Crankshaft position sensor to Timing chain cover 9 7
  • 2TR-FE
verified source
Sensor Engine coolant temperature sensor to Rear water by-pass joint 20 15
  • 1GR-FE
verified source
Sensor Engine coolant temperature sensor to Cylinder block 20 15
  • 2TR-FE
verified source
Sensor Knock sensor to Cylinder block 20 15
  • 1GR-FE
verified source
Sensor Knock sensor to Cylinder block 20 15
  • 2TR-FE
verified source
Sensor Air fuel ratio sensor to Front exhaust pipe assembly (for Bank 1) 44 32
  • 1GR-FE
verified source
Sensor Air fuel ratio sensor to Front exhaust pipe assembly (for Bank 1) 40 30 For use with SST
  • 1GR-FE
verified source
Sensor Air fuel ratio sensor to Front exhaust pipe assembly 44 32
  • 2TR-FE
verified source
Sensor Air fuel ratio sensor to Front exhaust pipe assembly 40 30 For use with SST
  • 2TR-FE
verified source
Sensor Air fuel ratio sensor to Front No.2 exhaust pipe assembly (for Bank 2) 44 32
  • 1GR-FE
verified source
Sensor Air fuel ratio sensor to Front No.2 exhaust pipe assembly (for Bank 2) 40 30 For use with SST
  • 1GR-FE
verified source
Sensor Heated oxygen sensor to Front exhaust pipe assembly (for Bank 1) 44 32
  • 1GR-FE
verified source
Sensor Heated oxygen sensor to Front exhaust pipe assembly (for Bank 1) 40 30 For use with SST
  • 1GR-FE
verified source
Sensor Heated oxygen sensor to Front exhaust pipe assembly 44 32
  • 2TR-FE
verified source
Sensor Heated oxygen sensor to Front exhaust pipe assembly 40 30 For use with SST
  • 2TR-FE
verified source
Sensor Heated oxygen sensor to Front No.2 exhaust pipe assembly (for Bank 2) 44 32
  • 1GR-FE
verified source
Sensor Heated oxygen sensor to Front No.2 exhaust pipe assembly (for Bank 2) 40 30 For use with SST
  • 1GR-FE
verified source
Sensor Manifold absolute pressure sensor to Intake air connector 5 4
  • 2TR-FE
verified source
Sensor Speed sensor NCO, SP2 to Automatic Transmission 5 4
  • A343E Automatic Transmission
verified source
Sensor Speed sensor NT, SP2 to Automatic Transmission 5 4
  • A750E Automatic Transmission
verified source
Sensor Speed sensor NT, SP2 to Automatic Transmission 5 4
  • A750F Automatic Transmission
verified source
Sensor Front speed sensor bolt 9 7
verified source
Sensor Rear speed sensor nut 8 6
verified source
Sensor Front speed sensor bracket to Steering knuckle 13 10
verified source
Sensor ATF temperature sensor to Automatic transmission 29 21
  • A343E Automatic Transmission
verified source
Sensor Yaw rate and acceleration sensor bolt 15 11
verified source
Alternator Retainer plate to Generator drive end frame 2 1
  • 1GR-FE
verified source
Alternator Retainer plate to Generator drive end frame assembly 2 1
  • 2TR-FE
verified source
Alternator Generator coil assembly to Generator drive end frame 6 4
  • 1GR-FE
verified source
Alternator Generator coil to Generator drive end frame assembly 6 4
  • 2TR-FE
verified source
Alternator Generator brush holder assembly to Generator coil assembly 2 1
  • 1GR-FE
verified source
Alternator Generator brush holder assembly to Generator coil 2 1
  • 2TR-FE
verified source
Alternator Generator rear end cover to Generator coil assembly 5 4
  • 1GR-FE
verified source
Alternator Generator rear end cover to Generator coil 5 4
  • 2TR-FE
verified source
Alternator Cord clip to Generator rear end cover 6 4
  • 1GR-FE
verified source
Alternator Generator with clutch pulley to Generator rotor assembly 80 59
  • 1GR-FE
verified source
Alternator Generator with clutch pulley to Generator rotor assembly 64 47 For use with SST
  • 1GR-FE
verified source
Alternator Generator with clutch pulley to Generator rotor assembly 111 82
  • 2TR-FE
verified source
Alternator Generator with clutch pulley to Generator rotor assembly 88 65 For use with SST
  • 2TR-FE
verified source
Alternator Generator bracket to Generator assembly 20 15
  • 1GR-FE
verified source
Alternator Generator assembly to Timing chain cover 43 32
  • 1GR-FE
verified source
Alternator Generator assembly to Timing chain cover 43 32
  • 2TR-FE
verified source
Alternator Generator bracket to Cylinder block 20 15
  • 1GR-FE
verified source
Alternator Wire harness to Generator assembly 8 6
  • 1GR-FE
verified source
Alternator Generator wire to Generator assembly 10 7
  • 1GR-FE
verified source
Alternator Generator assembly to Generator wire 10 7
  • 2TR-FE
verified source
Starter Starter assembly to Transmission housing 37 27
  • 1GR-FE
verified source
Starter Starter assembly to Transmission housing 37 27
  • 2TR-FE
verified source
Starter Starter drive housing to Magnet starter switch assembly 6 4
  • 1GR-FE
verified source
Starter Starter drive housing assembly to Magnet starter switch assembly 6 4
  • 2TR-FE
verified source
Starter Commutator end frame to Starter brush holder assembly 2 1
  • 1GR-FE
verified source
Starter Commutator end frame to Brush holder assembly 2 1
  • 2TR-FE
verified source
Starter Commutator end frame to Starter drive housing 6 4
  • 1GR-FE
verified source
Starter Commutator end frame to Starter drive housing assembly 6 4
  • 2TR-FE
verified source
Starter Starter wire to Starter assembly 10 7
  • 1GR-FE
verified source
Starter Starter wire to Cylinder block 8 6
  • 1GR-FE
verified source
Starter Starter wire 10 7
  • 2TR-FE
verified source
Starter Starter cover to Starter assembly 12 9
  • 1GR-FE
verified source
Starter Lead wire to Terminal C 6 4
  • 1GR-FE
verified source
Starter Lead wire to Terminal C 6 4
  • 2TR-FE
verified source
Battery Battery clamp to Body 6 4
  • 1GR-FE
verified source
Battery Ignition coil to Cylinder head cover 10 7
  • 1GR-FE
verified source
Battery Ignition coil to Cylinder head cover 9 7
  • 2TR-FE
verified source
Camshaft Camshaft timing gear to Camshaft 100 74
  • 1GR-FE
verified source
Camshaft Camshaft timing gear to Camshaft 78 58
  • 2TR-FE
verified source
Camshaft Camshaft timing exhaust gear to Camshaft 100 74
  • 1GR-FE
verified source
Camshaft Camshaft timing sprocket to No.2 camshaft 78 58
  • 2TR-FE
verified source
Camshaft No.2 chain tensioner to Camshaft housing RH 21 15
  • 1GR-FE
verified source
Camshaft No.3 chain tensioner to Camshaft housing LH 21 15
  • 1GR-FE
verified source
Camshaft Timing chain guide to No.1 camshaft bearing cap 10 7
  • 2TR-FE
verified source
Camshaft Camshaft bearing cap (for Bank 1) to Cylinder head LH bolt 28 21 For bolt A
  • 1GR-FE
verified source
Camshaft Camshaft bearing cap (for Bank 1) to Cylinder head LH bolt 16 12 For bolt B
  • 1GR-FE
verified source
Camshaft Camshaft bearing cap (for Bank 2) to Cylinder head RH bolt 28 21 For bolt A
  • 1GR-FE
verified source
Camshaft Camshaft bearing cap (for Bank 2) to Cylinder head RH bolt 16 12 For bolt B
  • 1GR-FE
verified source
Camshaft Camshaft bearing cap to Cylinder head bolt 12 9 Bolt A
  • 2TR-FE
verified source
Camshaft Camshaft bearing cap to Cylinder head bolt 16 12 Bolt B
  • 2TR-FE
verified source
Camshaft Cylinder head to Camshaft housing bolts 10 7 For bolt A and D
  • 1GR-FE
verified source
Camshaft Cylinder head to Camshaft housing bolts 21 15 For bolt B and C
  • 1GR-FE
verified source
Camshaft Camshaft timing oil control valve assembly to Cylinder head 10 7
  • 1GR-FE
verified source
Camshaft Camshaft timing oil control valve to Cylinder head 8 6
  • 2TR-FE
verified source
Crankshaft Crankshaft pulley to Crankshaft 260 192
  • 1GR-FE
verified source
Crankshaft Crankshaft pulley to Crankshaft 260 192
  • 2TR-FE
verified source
Crankshaft Crankshaft bearing cap to Cylinder block 61 45 Step 1, Quantity: 16
  • 1GR-FE
verified source
Crankshaft Crankshaft bearing cap to Cylinder block 26 19 Quantity: 8
  • 1GR-FE
verified source
Crankshaft Drive plate and ring gear to Crankshaft 83 61
  • 1GR-FE
verified source
Crankshaft Drive plate and ring gear to Crankshaft 74 55
  • 2TR-FE
verified source
Crankshaft Balance shaft drive gear to No.1 balance shaft 25 18
  • 2TR-FE
verified source
Crankshaft No.1 balance shaft drive gear to No.1 balance shaft 36 27
  • 2TR-FE
verified source
Crankshaft No.2 balance shaft drive gear to No.2 balance shaft 36 27
  • 2TR-FE
verified source
Crankshaft No.1 balance shaft to Cylinder block 18 13
  • 2TR-FE
verified source
Crankshaft No.2 balance shaft to Cylinder block 18 13
  • 2TR-FE
verified source
Crankshaft Crankshaft cylinder block 39 29 Step 1
  • 2TR-FE
verified source
Water pump Water pump to Timing chain cover bolt 47 35 For bolt A
  • 1GR-FE
verified source
Water pump Water pump to Timing chain cover bolt 11 8 For bolt B
  • 1GR-FE
verified source
Water pump Water pump to Timing chain cover bolt 23 17 For bolt C
  • 1GR-FE
verified source
Water pump Water pump assembly to Timing chain cover bolt 26 19 For bolt A
  • 2TR-FE
verified source
Water pump Water pump assembly to Timing chain cover bolt 9 7 For bolt B
  • 2TR-FE
verified source
Fuel/Oil cooler Engine oil cooler to Oil filter bracket bolt 68 50
  • 1GR-FE
verified source
Fuel/Oil cooler Engine oil cooler to Oil filter bracket nut 10 7
  • 1GR-FE
verified source
Fuel/Oil cooler Fan shroud to Oil cooler tube 6 4
  • 1GR-FE
verified source
Fuel/Oil cooler Drain plug to No.2 oil pan 14 10
  • 1GR-FE
verified source
Fuel/Oil cooler No.1 oil cooler tube to Transmission housing 14 10
  • A343E Automatic Transmission
verified source
Fuel/Oil cooler No.1 oil cooler tube to Engine 6 4
  • A343E Automatic Transmission
verified source
Fuel/Oil cooler No.2 oil cooler tube to Radiator support 14 10
  • A343E Automatic Transmission
verified source
Fuel/Oil cooler No.2 oil cooler tube sub-assembly to Radiator 6 4
  • A750E Automatic Transmission
verified source
Fuel/Oil cooler No.2 oil cooler tube sub-assembly to Radiator 6 4
  • A750F Automatic Transmission
verified source
Fuel/Oil cooler Oil cooler tube union nut to Oil cooler tube union 34 25
  • A343E Automatic Transmission
verified source
Fuel/Oil cooler No.1 oil cooler tube union nut to Oil cooler tube union 34 25
  • A750E Automatic Transmission
verified source
Fuel/Oil cooler No.1 oil cooler tube union nut to Oil cooler tube union 34 25
  • A750F Automatic Transmission
verified source
Fuel/Oil cooler Oil cooler tube union to Transmission case 29 21
  • A343E Automatic Transmission
verified source
Fuel/Oil cooler Oil cooler tube union to Transmission case 29 21
  • A750E Automatic Transmission
verified source
Fuel/Oil cooler Oil cooler tube union to Transmission case 29 21
  • A750F Automatic Transmission
verified source
Radiator Radiator to Radiator support 18 13
  • 1GR-FE
verified source
Radiator Radiator assembly to Vehicle body 18 13
  • 2TR-FE
verified source
Radiator Fan shroud to Radiator 5 4
  • 1GR-FE
verified source
Radiator Fan shroud to Radiator assembly 5 4
  • 2TR-FE
verified source
Radiator Radiator reservoir to Fan shroud 5 4
  • 1GR-FE
verified source
Radiator Radiator reservoir to Fan shroud 5 4
  • 2TR-FE
verified source
Radiator Fluid coupling to Fan pulley 21 15
  • 1GR-FE
verified source
Radiator Fluid coupling and fan pulley to Water pump assembly 25 18
  • 2TR-FE
verified source
Radiator Fluid coupling to Fan 10 7
  • 1GR-FE
verified source
Radiator Fluid coupling to Fan 5 4
  • 2TR-FE
verified source
Radiator Water inlet housing to Timing chain cover 10 7
  • 1GR-FE
verified source
Radiator Water inlet to Timing chain cover 28 21
  • 2TR-FE
verified source
Radiator Water inlet with thermostat to Water inlet housing 9 7
  • 1GR-FE
verified source
Radiator No.1 water outlet pipe to Cylinder block 10 7
  • 1GR-FE
verified source
Radiator Water by-pass pipe to Timing chain cover and oil filter bracket 10 7
  • 1GR-FE
verified source
Radiator No.1 water by-pass pipe to Timing chain cover 18 13
  • 2TR-FE
verified source
Air conditioning Air conditioning unit to Blower unit 3 2
verified source
Air conditioning Air conditioning tube assembly to Cooler condenser assembly 5 4
verified source
Air conditioning Air conditioning hose and accessory to Body 10 7
verified source
Air conditioning Air conditioner tube and accessory assembly to No.1 cooler evaporator sub-assembly 4 3
verified source
Air conditioning Discharge hose sub-assembly to Cooler condenser assembly 5 4
verified source
Air conditioning Discharge hose sub-assembly to Cooler compressor assembly 10 7
  • 1GR-FE
verified source
Air conditioning Discharge hose sub-assembly to Cooler compressor assembly 10 7
  • 2TR-FE
verified source
Air conditioning Suction hose sub-assembly to Cooler compressor assembly 10 7
  • 1GR-FE
verified source
Air conditioning Suction hose sub-assembly to Cooler compressor assembly 10 7
  • 2TR-FE
verified source
Air conditioning Suction hose sub-assembly to Engine 8 6
  • 1GR-FE
verified source
Air conditioning Suction hose sub-assembly to Engine 8 6
  • 2TR-FE
verified source
Air conditioning Discharge hose assembly to Cooler compressor assembly 5 4
verified source
Air conditioning Cooler compressor assembly to Engine stud bolt 10 7
  • 1GR-FE
verified source
Air conditioning Cooler compressor assembly to Engine bolt 25 18
  • 1GR-FE
verified source
Air conditioning Cooler compressor assembly to Engine nut 25 18
  • 1GR-FE
verified source
Air conditioning Cooler compressor assembly to Engine 25 18
  • 2TR-FE
verified source
Air conditioning No.1 compressor mounting bracket to Timing chain cover and cylinder block bolt 45 33 Bolt A
  • 2TR-FE
verified source
Air conditioning No.1 compressor mounting bracket to Timing chain cover and cylinder block bolt 45 33 Bolt B
  • 2TR-FE
verified source
Air conditioning No.1 compressor mounting bracket to Timing chain cover and cylinder block bolt 25 18 Bolt C
  • 2TR-FE
verified source
Air conditioning Cooler compressor to No.1 compressor mounting bracket 25 18
  • 2TR-FE
verified source
Air conditioning Cooler condenser assembly to Body 5 4
verified source
Air conditioning Cooler refrigerant liquid pipe A to Cooler condenser assembly 5 4
verified source
Air conditioning No.1 pressure switch to Cooler refrigerant liquid pipe A 11 8
verified source
Air conditioning No.1 cooler refrigerant discharge hose to Cooler condenser assembly 5 4
verified source
Air conditioning Cap to Cooler condenser assembly 3 2
verified source
Belt tensioner/Timing chains V-ribbed belt tensioner to Timing chain cover 36 27
  • 1GR-FE
verified source
Belt tensioner/Timing chains V-ribbed belt tensioner to Timing chain cover and Cylinder block bolt 40 30 Bolt 1
  • 2TR-FE
verified source
Belt tensioner/Timing chains V-ribbed belt tensioner to Timing chain cover and Cylinder block bolt 21 15 Bolt 2
  • 2TR-FE
verified source
Belt tensioner/Timing chains No.1 idler pulley to Timing chain cover 54 40
  • 1GR-FE
verified source
Belt tensioner/Timing chains No.1 idler pulley to Timing chain cover 43 32
  • 2TR-FE
verified source
Belt tensioner/Timing chains No.2 idler pulley to Timing chain cover 54 40
  • 1GR-FE
verified source
Belt tensioner/Timing chains Timing chain cover to Cylinder head and cylinder block 47 35 For area 1
  • 1GR-FE
verified source
Belt tensioner/Timing chains Timing chain cover to Cylinder head and cylinder block 23 17 Except area 1
  • 1GR-FE
verified source
Belt tensioner/Timing chains Timing chain cover to Cylinder head and cylinder block bolt 60 44 Bolt A
  • 2TR-FE
verified source
Belt tensioner/Timing chains Timing chain cover to Cylinder head and cylinder block bolts and nut 21 15 Bolts B, D and nut
  • 2TR-FE
verified source
Belt tensioner/Timing chains Timing chain cover to Cylinder head and cylinder block bolt 26 19 Bolt C
  • 2TR-FE
verified source
Belt tensioner/Timing chains Timing chain cover to Cylinder head and cylinder block bolt 21 15 Bolt E
  • 2TR-FE
verified source
Belt tensioner/Timing chains Timing chain cover to Cylinder head and cylinder block bolt 46 34 Bolt F
  • 2TR-FE
verified source
Belt tensioner/Timing chains Suction hose to Timing chain cover 8 6
  • 1GR-FE
verified source
Belt tensioner/Timing chains Suction hose to Timing chain cover 8 6
  • 2TR-FE
verified source
Belt tensioner/Timing chains Straight screw plug to Timing chain cover 17 13
  • 2TR-FE
verified source
Belt tensioner/Timing chains Timing chain cover plate to Timing chain cover 9 7
  • 1GR-FE
verified source
PCM ECM to Body 8 6
  • 1GR-FE
verified source
PCM ECM to Reinforcement 8 6
  • 2TR-FE
verified source
PCM ECM bracket to ECM 3 2
  • 1GR-FE
verified source
PCM ECM to ECM bracket 3 2
  • 2TR-FE
verified source
PCM No.2 ECM bracket to ECM 3 2
  • 1GR-FE
verified source
PCM ECM to No.2 ECM bracket 3 2
  • 2TR-FE
verified source
Fuel system Fuel delivery pipe sub-assembly to Intake manifold 21 15
  • 1GR-FE
verified source
Fuel system Fuel delivery pipe to Cylinder block 12 9
  • 2TR-FE
verified source
Fuel system Fuel pressure regulator to Fuel delivery pipe 9 7
  • 1GR-FE
verified source
Fuel system Fuel pressure regulator assembly to Fuel delivery pipe 9 7
  • 2TR-FE
verified source
Fuel system Fuel pump ECU to Frame 31 23
  • 1GR-FE
verified source
Fuel system Fuel pump ECU to Frame 31 23
  • 2TR-FE
verified source
Fuel system Fuel tank band to body 40 30
  • 1GR-FE
verified source
Fuel system Fuel tank band to body 40 30
  • 2TR-FE
verified source
Fuel system No.1 fuel tank protector sub-assembly to Body 20 15
  • 1GR-FE
verified source
Fuel system No.1 fuel tank protector sub-assembly to Body 20 15
  • 2TR-FE
verified source
Fuel system No.3 fuel tank protector to Fuel tank 5 4
  • 1GR-FE
verified source
Fuel system No.3 fuel tank protector to Fuel tank 5 4
  • 2TR-FE
verified source
Fuel system Fuel pressure pulsation damper assembly to Fuel delivery pipe 9 7
  • 2TR-FE
verified source

drivetrain torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Differential Differential carrier assembly to Front differential breather tube 13 10
verified source
Differential Rear differential carrier assembly to Propeller shaft assembly 88 65
verified source
Differential Rear differential carrier assembly to Rear axle carrier 52 38
verified source
Differential Front No.1 differential mount nut to Frame 87 64
verified source
Differential Front No.1 differential front support to Differential carrier assembly 186 137
verified source
Differential Front No.1 differential support to Frame 137 101
verified source
Differential Front No.2 differential support to Frame 137 101
verified source
Differential Front No.2 differential support to Differential carrier 160 118
verified source
Differential Front No.3 differential support to Differential carrier 108 80
verified source
Differential Ring gear to Front differential case 115 85
verified source
Differential Rear differential case to Ring gear 97 72
verified source
Differential Rear differential case RH to Rear differential case LH 47 35
verified source
Differential Front differential tube assembly to Differential side bearing retainer 110 81
verified source
Differential Differential vacuum actuator assembly to Front differential tube assembly 21 15
verified source
Differential Companion flange sub assembly to Front differential drive pinion 370 273
verified source
Differential Companion flange sub assembly to Rear differential drive pinion 457 337
verified source
Differential Differential side bearing retainer to Front differential case 50 37
verified source
Differential Bearing cap to Rear differential carrier 103 76
verified source
Differential Front drain plug 65 48
verified source
Differential Rear drain plug 49 36
verified source
Differential Front filler plug 39 29
verified source
Differential Rear filler plug 49 36
verified source
Wheel hub assembly Front wheel adjusting nut LH to Front axle with ABS rotor bearing assembly 275 203
  • 2WD
verified source
Wheel hub assembly Front hub nut 112 83
verified source
Wheel hub assembly Rear hub nut 112 83
verified source
Transmission fluid pan Drain plug to Oil pan 20 15
  • A343E Automatic Transmission
verified source
Transmission fluid pan Drain plug to Oil pan 20 15
  • A750E Automatic Transmission
verified source
Transmission fluid pan Drain plug to Oil pan 20 15
  • A750F Automatic Transmission
verified source
Transmission fluid pan Overflow plug to Oil pan 20 15
  • A750E Automatic Transmission
verified source
Transmission fluid pan Overflow plug to Oil pan 20 15
  • A750F Automatic Transmission
verified source
Transmission fluid pan Refill plug to Transmission case 37 27
  • A750E Automatic Transmission
verified source
Transmission fluid pan Refill plug to Transmission case 37 27
  • A750F Automatic Transmission
verified source
Transmission mount/case Oil pan to Transmission case 7 5
  • A343E Automatic Transmission
verified source
Transmission mount/case Oil pan to Transmission case 7 5
  • A750E Automatic Transmission
verified source
Transmission mount/case Oil pan to Transmission case 7 5
  • A750F Automatic Transmission
verified source
Transmission mount/case Automatic transmission assembly to Engine bolt 37 27 14mm head bolt
  • A343E Automatic Transmission
verified source
Transmission mount/case Automatic transmission assembly to Engine bolt 71 52 17mm head bolt
  • A343E Automatic Transmission
verified source
Transmission mount/case Automatic transmission assembly to Engine bolt 37 27 14mm head bolt
  • A750E Automatic Transmission
verified source
Transmission mount/case Automatic transmission assembly to Engine bolt 71 52 17mm head bolt
  • A750E Automatic Transmission
verified source
Transmission mount/case Automatic transmission assembly to Engine bolt 37 27 14mm head bolt
  • A750F Automatic Transmission
verified source
Transmission mount/case Automatic transmission assembly to Engine bolt 71 52 17mm head bolt
  • A750F Automatic Transmission
verified source
Transmission mount/case Transmission housing to Transmission case bolt 34 25 14mm head bolt
  • A343E Automatic Transmission
verified source
Transmission mount/case Transmission housing to Transmission case bolt 57 42 17mm head bolt
  • A343E Automatic Transmission
verified source
Transmission mount/case Transmission housing to Transmission case bolt 34 25 14mm head bolt
  • A750E Automatic Transmission
verified source
Transmission mount/case Transmission housing to Transmission case bolt 57 42 17mm head bolt
  • A750E Automatic Transmission
verified source
Transmission mount/case Transmission housing to Transmission case bolt 34 25 14mm head bolt
  • A750F Automatic Transmission
verified source
Transmission mount/case Transmission housing to Transmission case bolt 57 42 17mm head bolt
  • A750F Automatic Transmission
verified source
Transmission mount/case Valve body to Transmission case 11 8
  • A343E Automatic Transmission
verified source
Transmission mount/case Valve body to Transmission case 11 8
  • A750E Automatic Transmission
verified source
Transmission mount/case Valve body to Transmission case 11 8
  • A750F Automatic Transmission
verified source
Transmission mount/case Overdrive support to Transmission case 25 18
  • A343E Automatic Transmission
verified source
Transmission mount/case Transmission under cover to Body 29 21
  • 1GR-FE
verified source
Transmission mount/case Transmission wire connector set bolt to Automatic transmission 5 4
  • A343E Automatic Transmission
verified source
Transmission mount/case Transmission wire connector set bolt to Automatic transmission 5 4
  • A750E Automatic Transmission
verified source
Transmission mount/case Transmission wire connector set bolt to Automatic transmission 5 4
  • A750F Automatic Transmission
verified source
Transmission mount/case Transmission oil filler tube to Intake manifold 14 10
  • A343E Automatic Transmission
verified source
Transmission mount/case Transmission control cable to Transmission control shaft lever LH 14 10
  • A343E Automatic Transmission
verified source
Transmission mount/case Transmission control cable to Transmission control shaft lever LH 14 10
  • A750E Automatic Transmission
verified source
Transmission mount/case Transmission control cable to Transmission control shaft lever LH 14 10
  • A750F Automatic Transmission
verified source
Transmission mount/case Transmission control cable bracket to Automatic transmission assembly 25 18
  • A343E Automatic Transmission
verified source
Transmission mount/case No.1 transmission control cable bracket to Automatic transmission assembly 14 10
  • A750E Automatic Transmission
verified source
Transmission mount/case No.1 transmission control cable bracket to Automatic transmission assembly 14 10
  • A750F Automatic Transmission
verified source
Transmission mount/case Transmission control shaft lever LH to Transmission control shaft 16 12
  • A343E Automatic Transmission
verified source
Transmission mount/case Transmission control shaft lever LH to Transmission control shaft 16 12
  • A750E Automatic Transmission
verified source
Transmission mount/case Transmission control shaft lever LH to Transmission control shaft 16 12
  • A750F Automatic Transmission
verified source
Transmission mount/case Extension housing to Transmission case 34 25
  • A343E Automatic Transmission
verified source
Transmission mount/case Extension housing to Transmission case 34 25
  • A750E Automatic Transmission
verified source
Transmission mount/case Automatic transaxle breather tube to Transmission case 5 4
  • A750E Automatic Transmission
verified source
Transmission mount/case Automatic transaxle breather tube to Transmission case 5 4
  • A750F Automatic Transmission
verified source
Transmission mount/case Park/Neutral position switch bolt 13 10
  • A343E Automatic Transmission
verified source
Transmission mount/case Park/Neutral position switch bolt 13 10
  • A750E Automatic Transmission
verified source
Transmission mount/case Park/Neutral position switch bolt 13 10
  • A750F Automatic Transmission
verified source
Transmission mount/case Park/Neutral position switch nut 7 5
  • A343E Automatic Transmission
verified source
Transmission mount/case Park/Neutral position switch nut 7 5
  • A750E Automatic Transmission
verified source
Transmission mount/case Park/Neutral position switch nut 7 5
  • A750F Automatic Transmission
verified source
Transmission adapter Rear adaptor transfer to Transmission case 34 25
  • A750F Automatic Transmission
verified source
Torque converter Torque converter clutch to Drive plate 48 35
  • A343E Automatic Transmission
verified source
Torque converter Torque converter clutch to Drive plate 48 35
  • A750E Automatic Transmission
verified source
Torque converter Torque converter clutch to Drive plate 48 35
  • A750F Automatic Transmission
verified source
Transfer Drain plug to Transfer assembly 37 27
  • 4WD
  • VF2A Transfer
verified source
Transfer Drain plug to Transfer assembly 37 27
  • 4WD
  • VF4BM Transfer
verified source
Transfer Filler plug to Transfer assembly 37 27
  • 4WD
  • VF2A Transfer
verified source
Transfer Filler plug to Transfer assembly 37 27
  • 4WD
  • VF4BM Transfer
verified source
Transfer Transfer case plug to Front transfer case 19 14
  • 4WD
  • VF2A Transfer
verified source
Transfer Transfer case plug to Front transfer case 19 14
  • 4WD
  • VF4BM Transfer
verified source
Transfer Transfer oil pump body sub-assembly to Front transfer case 8 6
  • 4WD
  • VF2A Transfer
verified source
Transfer Transfer oil separator sub-assembly to Front transfer case 8 6
  • 4WD
  • VF2A Transfer
verified source
Transfer Oil separator sub-assembly to Rear transfer case 8 6
  • 4WD
  • VF4BM Transfer
verified source
Transfer Rear transfer case to Front transfer case 28 21
  • 4WD
  • VF2A Transfer
verified source
Transfer Front transfer case to Rear transfer case 28 21
  • 4WD
  • VF4BM Transfer
verified source
Transfer Transfer extension housing sub-assembly to Rear transfer case 12 9
  • 4WD
  • VF2A Transfer
verified source
Transfer Transfer extension housing sub-assembly to Case rear 12 9
  • 4WD
  • VF4BM Transfer
verified source
Transfer Transfer case cover sub-assembly to Front case 18 13
  • 4WD
  • VF4BM Transfer
verified source
Transfer Transfer to Transfer adaptor 24 18
  • 4WD
  • VF4BM Transfer
verified source
Transfer Transfer output shaft companion flange 118 87
  • 4WD
  • VF2A Transfer
verified source
Transfer Companion flange sub-assembly lock nut 118 87
  • 4WD
  • VF4BM Transfer
verified source
Transfer Transfer control shift lever retainer sub-assembly to Front transfer case 18 13
  • 4WD
  • VF2A Transfer
verified source
Transfer Transfer bearing retainer sub-assembly to Front transfer case 12 9
  • 4WD
  • VF2A Transfer
verified source
Transfer Transfer RH bearing retainer sub-assembly to Front case 12 9
  • 4WD
  • VF4BM Transfer
verified source
Transfer Transfer indicator switch to Front transfer case 37 27
  • 4WD
  • VF2A Transfer
verified source
Transfer Transfer assembly to Transmission assembly 24 18
  • 4WD
  • VF2A Transfer
verified source
Transfer No.2 transfer gear shift fork to Transfer shift actuator assembly 24 18
  • 4WD
  • VF4BM Transfer
verified source
Transfer Center differential lock fork sub-assembly to Transfer shift actuator assembly 24 18
  • 4WD
  • VF4BM Transfer
verified source
Transfer Transfer shift actuator assembly to Rear transfer case 20 15
  • 4WD
  • VF4BM Transfer
verified source
Transfer Transmission floor shift assembly to Body 14 10
  • A343E Automatic Transmission
verified source
Transfer Transmission floor shift assembly to Body 14 10
  • A750E Automatic Transmission
verified source
Transfer Transmission floor shift assembly to Body 14 10
  • A750F Automatic Transmission
verified source
Transfer Shift control cable support to Body 6 4
  • A343E Automatic Transmission
verified source
Transfer Transmission control cable support to Body 6 4
  • A750E Automatic Transmission
verified source
Transfer Transmission control cable support to Body 6 4
  • A750F Automatic Transmission
verified source
Transfer Shift control cable retainer to Body 6 4
  • A343E Automatic Transmission
verified source
Transfer Transmission control cable retainer to Body 6 4
  • A750E Automatic Transmission
verified source
Transfer Transmission control cable retainer to Body 6 4
  • A750F Automatic Transmission
verified source
Transfer Shift control cable clamp to Body nut 5 4
  • A750E Automatic Transmission
verified source
Transfer Shift control cable clamp to Body nut 5 4
  • A750F Automatic Transmission
verified source
Transfer Parking lock pawl bracket to Transmission case 7 5
  • A343E Automatic Transmission
verified source
Transfer Parking lock pawl bracket to Transmission case 7 5
  • A750E Automatic Transmission
verified source
Transfer Parking lock pawl bracket to Transmission case 7 5
  • A750F Automatic Transmission
verified source
Drive/Axle shaft Front axle shaft to Front axle shaft nut 235 173
  • 2WD
verified source
Drive/Axle shaft Front axle shaft to Front axle shaft nut 235 173
  • 4WD
verified source
Drive/Axle shaft Rear axle shaft to Housing 60 44
verified source
Drive/Axle shaft Front propeller shaft to Front differential carrier assembly 88 65
verified source
Drive/Axle shaft Rear propeller shaft to Rear differential carrier assembly 88 65
verified source
Drive/Axle shaft Front propeller shaft to Transfer assembly 88 65
verified source
Drive/Axle shaft Rear propeller shaft to Transfer assembly 88 65
verified source

steering torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Tie rod end Steering knuckle to Tie rod end 91 67
verified source
Tie rod end Tie rod end lock nut 88 65
verified source
Steering knuckle Front axle with ABS rotor bearing assembly to Steering knuckle 80 59
  • 2WD
verified source
Steering knuckle Front axle with ABS rotor bearing assembly to Steering knuckle 80 59
  • 4WD
verified source
Steering knuckle Steering knuckle to Upper arm 110 81
verified source
Steering rack Pressure feed tube clamp to Steering gear assembly 28 21
verified source
Steering rack Steering gear assembly set bolt and nut 120 89
verified source
Steering rack Steering gear outlet return tube to Steering gear assembly 25 18
verified source
Steering rack Rack to Rack end 105 77
verified source
Steering rack Rack to Rack end 77 57 For use without SST
verified source
Steering column Steering column assembly set nut 15 11
verified source
Steering column Column hole cover set bolt 5 4
verified source
Steering column Steering column assembly to Steering intermediate shaft assembly 36 27
verified source
Steering shaft Steering intermediate shaft assembly to No.2 intermediate shaft assembly 36 27
verified source
Steering shaft No.2 intermediate shaft assembly to Steering gear assembly 36 27
verified source
Steering wheel Steering wheel set nut 50 37
verified source
Steering wheel Steering pad to Steering wheel 9 7
verified source
Power steering Power steering oil pressure switch to Pressure feed tube 21 15
  • 1GR-FE
verified source
Power steering Power steering oil pressure switch to Pressure feed tube 21 15
  • 2TR-FE
verified source
Power steering Pressure feed tube union bolt 50 37
  • 1GR-FE
verified source
Power steering Pressure feed tube union bolt 50 37
  • 2TR-FE
verified source
Power steering Wire harness bracket to Vane pump assembly 40 30
  • 1GR-FE
verified source
Power steering Vane pump assembly set bolt 43 32
  • 1GR-FE
verified source
Power steering Vane pump assembly set bolt 21 15
  • 2TR-FE
verified source
Power steering Vane pump front housing to Vane pump rear housing 22 16
  • 1GR-FE
verified source
Power steering Vane pump front housing to Vane pump rear housing 22 16
  • 2TR-FE
verified source
Power steering Vane pump oil reservoir sub-assembly to Vane pump front housing 9 7
  • 2TR-FE
verified source

exhaust torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Exhaust manifold Exhaust manifold sub-assembly RH to Cylinder head RH 21 15
  • 1GR-FE
verified source
Exhaust manifold Exhaust manifold to Cylinder head 36 27
  • 2TR-FE
verified source
Exhaust manifold Exhaust manifold RH to Front exhaust pipe 54 40
  • 1GR-FE
verified source
Exhaust manifold Exhaust manifold LH to Front No.2 exhaust pipe 54 40
  • 1GR-FE
verified source
Exhaust manifold Exhaust manifold to Front exhaust pipe assembly 43 32
  • 2TR-FE
verified source
Exhaust manifold Exhaust manifold RH to No.1 exhaust manifold heat insulator 13 10
  • 1GR-FE
verified source
Exhaust manifold Exhaust manifold LH to No.2 exhaust manifold heat insulator 13 10
  • 1GR-FE
verified source
Exhaust manifold No.1 exhaust manifold heat insulator to Exhaust manifold 12 9
  • 2TR-FE
verified source
Exhaust manifold Manifold stay to Exhaust manifold LH to Front transmission case 40 30
  • 1GR-FE
verified source
Exhaust manifold Manifold stay to Exhaust manifold 30 22
  • 2TR-FE
verified source
Exhaust manifold No.2 manifold stay to Exhaust manifold RH to Front transmission case 40 30
  • 1GR-FE
verified source
Exhaust manifold Manifold stay to Transmission bolt 71 52 Bolt A
  • 2TR-FE
verified source
Exhaust manifold Manifold stay to Transmission bolt 44 32 Bolt B
  • 2TR-FE
verified source
Exhaust manifold Exhaust manifold stay to Automatic transmission bolt 44 32 14mm head bolt
  • A343E Automatic Transmission
verified source
Exhaust manifold Exhaust manifold stay to Automatic transmission bolt 71 52 17mm head bolt
  • A343E Automatic Transmission
verified source
Exhaust manifold Exhaust manifold stay to Exhaust manifold 30 22
  • A343E Automatic Transmission
verified source
Exhaust manifold Front exhaust pipe assembly to Center exhaust pipe assembly 43 32
  • 1GR-FE
verified source
Exhaust manifold Front exhaust pipe to Center exhaust pipe 43 32
  • 2TR-FE
verified source
Exhaust manifold Front exhaust pipe to Front No.2 exhaust pipe 48 35
  • 1GR-FE
verified source
Exhaust manifold Center exhaust pipe to Tailpipe assembly 48 35
  • 1GR-FE
verified source
Exhaust manifold Center exhaust pipe to Tailpipe assembly 48 35
  • 2TR-FE
verified source
Exhaust manifold Exhaust pipe stopper bracket to Crossmember 19 14
  • 1GR-FE
verified source
Exhaust manifold No.4 intake pipe to Exhaust manifold 20 15
  • 2TR-FE
verified source

brakes torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Disc brake Front disc brake cylinder bolt 123 91
verified source
Disc brake Rear disc brake cylinder mounting bolt 105 77
verified source
Disc brake Rear disc brake cylinder to Rear disc brake cylinder mounting 88 65
verified source
Disc brake Front bleeder plug 11 8
verified source
Disc brake Rear bleeder plug 11 8
verified source
Disc brake No.1 brake actuator tube flare nut 15 11
verified source
Disc brake No.1 brake actuator bracket bolt 8 6
verified source
Disc brake No.3 brake actuator bracket bolt 8 6
verified source
Brake line Front brake tube to Disc brake cylinder 15 11
verified source
Brake line Front brake tube to Flexible hose 15 11
verified source
Brake line Rear brake tube to Flexible hose 15 11
verified source
Brake line Rear brake flexible hose to Housing 15 11
verified source
Brake line Rear flexible hose to Disc brake cylinder 31 23
verified source
Brake booster Front brake tube to Disc brake cylinder 14 10
verified source
Brake booster Hydraulic brake booster assembly to Brake tube flare nut 15 11
verified source
Brake booster Brake booster accumulator assembly 57 42
verified source
Brake booster No.1 brake booster pump bracket to Master cylinder body 8 6
verified source
Brake pedal Brake pedal support reinforcement set bolt 20 15
verified source
Master cylinder Brake master cylinder side lock nut to Rod operating adapter 26 19
verified source
Master cylinder Master cylinder body to Master cylinder solenoid 32 24
verified source
Master cylinder Pin to Master cylinder body 8 6
verified source
Master cylinder Brake master cylinder reservoir sub-assembly to Master cylinder body 2 1
verified source
Parking brake Parking brake switch to Parking brake control pedal assembly 3 2
verified source
Parking brake Parking brake control pedal assembly to Body 13 10
verified source
Parking brake No.1 parking brake cable assembly (pedal side) lock nut 5 4
verified source
Parking brake No.1 parking brake cable assembly (parking brake equalizer side) lock nut 5 4
verified source
Parking brake No.1 parking brake cable bolt 13 10
verified source
Parking brake No.1 parking brake cable nut 6 4
verified source
Parking brake No.1 parking brake cable assembly to Body 6 4
verified source
Parking brake No.2 parking brake cable to Body 13 10
verified source
Parking brake No.3 parking brake cable to Body 13 10
verified source
Parking brake No.1 parking brake cable No.3 clamp to Body 13 10
verified source
Parking brake No.2 parking brake cable clamp to Body 13 10
verified source
Parking brake No.3 parking brake cable clamp to Body 13 10
verified source
Parking brake No.2 parking brake cable assembly to Backing plate 8 6
verified source
Parking brake No.3 parking brake cable assembly to Backing plate 8 6
verified source
Parking brake No.1 parking brake cable heat insulator to Body 13 10
verified source

suspension torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Wheels Front wheel to Front axle hub 112 83
  • 2WD
verified source
Wheels Front wheel to Front axle hub 112 83
  • 4WD
verified source
Wheels Rear wheel to Rear axle hub 112 83
verified source
Shock absorbers/shocks Front shock absorber to Front support to front shock absorber nut 25 18
verified source
Shock absorbers/shocks Front shock absorber with coil spring to Chassis frame 64 47
verified source
Shock absorbers/shocks Rear shock absorber to Chassis frame 25 18
verified source
Shock absorbers/shocks Rear shock absorber to Axle housing 98 72
verified source
Shock absorbers/shocks Front shock absorber with coil spring to Tube 25 18
verified source
Shock absorbers/shocks Rear shock absorber to Tube 25 18
verified source
Shock absorbers/shocks Front shock absorber control tube bracket to Chassis frame 29 21
verified source
Shock absorbers/shocks Rear shock absorber bracket to Chassis frame 29 21
verified source
Stabilizer bar Front stabilizer bar to Stabilizer bracket 87 64
verified source
Stabilizer bar Rear stabilizer bar to Axle housing 110 81
verified source
Stabilizer bar Rear stabilizer bracket to Chassis frame 45 33
verified source
Stabilizer bar Front stabilizer bar to Stabilizer bar link 70 52
verified source
Stabilizer bar Rear stabilizer link to Stabilizer bar 70 52
verified source
Stabilizer bar Front stabilizer bar link to Stabilizer lower bracket 40 30
verified source
Stabilizer bar Rear stabilizer link to Stabilizer lower bracket 45 33
verified source
Stabilizer bar Front stabilizer cylinder to Stabilizer lower bracket 40 30
verified source
Stabilizer bar Rear stabilizer control cylinder to Stabilizer lower bracket 45 33
verified source
Stabilizer bar Front No.1 stabilizer bracket to Chassis frame 49 36
verified source
Stabilizer bar Front stabilizer cylinder to Chassis frame 130 96
verified source
Stabilizer bar Rear stabilizer control cylinder to Chassis frame 100 74
verified source
Stabilizer bar Front stabilizer cylinder to No.1 front stabilizer control tube 44 32
verified source
Stabilizer bar Rear stabilizer control cylinder to Stabilizer control tube 69 51
verified source
Sway bar links/Stabilizer links Front stabilizer bar link to Chassis frame 140 103
verified source
Sway bar links/Stabilizer links Rear stabilizer link to Chassis frame 100 74
verified source
Sway bar links/Stabilizer links Front steering knuckle to Stabilizer bar link 70 52
verified source
Control arm Front upper arm to Chassis frame 115 85
verified source
Control arm Rear upper control arm to Chassis frame 80 59
verified source
Control arm Front upper arm to Steering knuckle 110 81
verified source
Control arm Rear upper control arm to Axle housing 80 59
verified source
Control arm Front lower suspension arm to Shock absorber 95 70
verified source
Control arm Front lower suspension arm to Chassis frame 175 129
verified source
Control arm Rear lower control arm to Chassis frame 130 96
verified source
Control arm Rear lower control arm to Axle housing 130 96
verified source
Control arm Rear lower control arm to No.3 parking brake cable 13 10
verified source
Control arm Front lower suspension arm to Stabilizer end bracket 75 55
verified source
Control arm Rear lateral control arm to Chassis frame 130 96
verified source
Control arm Rear lateral control arm to Axle housing 130 96
verified source
Ball joint Lower suspension arm to Front lower ball joint attachment 140 103
verified source
Ball joint Steering knuckle to Front lower ball joint attachment 160 118
verified source

general torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Example of a 4Runner 5

By Mr.choppers - Own work, CC BY-SA 3.0


Did you find the answer to your specific question?
👍 0 👎 0
