Toyota RAV4 XA50 (2018-2022) Torque Spec Settings

Researched by Yien Yien Chan
Updated: December 24, 2023

By Kevauto - Own work, CC BY-SA 4.0

Below you'll find the tightening torques for the Toyota RAV4 XA50 in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.

Most-used torque specs for Toyota RAV4 XA50

Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Drain plug 40 30
verified source
Steering wheel Steering wheel 62 46
verified source

To make sure these are the correct tightening torque values, you can use the data below to verify this is the right model.

Are these torque settings right for you?

  • Production years: 2018 - 2022
  • Generation: 5
  • Type of van: car
  • Model variant: Base

All Torque Settings in Tables

engine torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Oil pan Oil pan 10 7
verified source
Oil pan Drain plug 40 30
verified source
Oil filter Oil strainer 10 7
verified source
Oil filter Oil strainer union 30 22
verified source
Oil pressure switch Oil pressure switching valve 10 7
verified source
Oil dipstick Engine oil level dipstick guide 10 7
verified source
Oil pump Oil pump cover 9 7
verified source
Oil pump Oil pump relief valve plug 53 39
verified source
Oil pump Oil pump 24 18
verified source
Oil pump Oil pump bracket 24 18
verified source
Piston rods Connecting rod bearing cap 38 28
verified source
Piston rods Cylinder block 44 32
verified source
Cylinder head Cylinder head 90 66
verified source
Cylinder head Screw plug to cylinder head 25 18
verified source
Intake manifold Water by pass pipe to Intake manifold 21 15 Bolt A
verified source
Intake manifold Water by pass pipe to Intake manifold 10 7 Bolt B
verified source
Intake manifold Intake manifold to cylinder head 24 18
verified source
Intake manifold Engine wire to intake manifold 10 7
verified source
Engine block Water hose clamp bracket 13 10
verified source
Engine block Oil nozzle to cylinder block 10 7
verified source
Engine mounts Engine hanger 43 32
verified source
Engine mounts Engine mount bracket 43 32
verified source
Engine mounts Engine mount spacer 72 53
verified source
Engine mounts Engine mounting insulator RH 72 53
verified source
Engine mounts Ground wire to engine mounting insulator RH 72 53
verified source
Engine mounts Engine mounting insulator LH 42 31
verified source
Sensor Oil pressure and temperature sensor 15 11
verified source
Sensor Oil level sensor 10 7
verified source
Sensor Fuel pressure sensor 10 7
verified source
Starter Starter commutator end frame 2 1
verified source
Starter Starter driver housing 6 4
verified source
Starter Magnet starter switch 8 6
verified source
Battery HV battery to vehicle body 19 14
verified source
Battery No. 1 HV battery cover panel RH 8 6 Nut
verified source
Battery No. 1 HV battery cover panel RH 8 6 Bolt
verified source
Battery No. 2 hybrid battery shield to HV battery 19 14
verified source
Camshaft Camshaft bearing cap to cylinder head 29 21
verified source
Camshaft Camshaft bearing cap to camshaft housing 16 12
verified source
Camshaft Camshaft timing gear to camshaft 86 63
verified source
Camshaft Camshaft timing exhaust gear to camshaft 19 14
verified source
Crankshaft Drive plate to crankshaft 150 111
verified source
Crankshaft Vibration damper to cylinder head 24 18
verified source
Crankshaft Crankshaft pulley 260 192
verified source
Crankshaft Drive shaft bearing bracket to crankcase 64 47
verified source
Water pump Engine water pump to cylinder block 43 32
verified source
Water pump Sensor wire to engine water pump 10 7
verified source
Fuel/Oil cooler Oil cooler 16 12
verified source
Radiator Thermostat 10 7
verified source
Radiator Upper radiator 13 10
verified source
Radiator Radiator reserve tank 5 4
verified source
Belt tensioner/Timing chains Timing chain cover 27 20
verified source
Belt tensioner/Timing chains Chain Tensioner slipper to cylinder head 24 18
verified source
Belt tensioner/Timing chains Chain tensioner to timing chain cover 10 7
verified source
Belt tensioner/Timing chains V-ribbed belt tensioner 21 15
verified source
Fuel system Fuel pump lifter guide 10 7
verified source
Fuel system Fuel pipe 35 26 Without union nut wrench
verified source
Fuel system Fuel pipe 30 22 With union nut wrench
verified source
Fuel system Fuel delivery pipe to port fuel injector 29 21 For port Injection
verified source
Fuel system Fuel delivery pipe to cylinder head 29 21 For direct Injection
verified source
Fuel system Fuel pump control ECU bracket 5 4
verified source
Fuel system Fuel pump control ECU to body 10 7
verified source
Fuel system Fuel tank band to body 45 33 Without SST
verified source
Fuel system Fuel tank band to body 25 18 With SST
verified source
Fuel system No.1 fuel tank protector to fuel tank band 11 8
verified source
Fuel system No.1 floor under cover to body 8 6
verified source
Fuel system No.2 floor under cover to body 8 6
verified source
Fuel system Front floor cover LH to body 8 6
verified source
Fuel system Front floor cover RH to body 8 6
verified source

drivetrain torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Differential Differential support to suspension member 130 96
  • Rear
verified source
Differential Differential support to torque vectoring 120 89
  • Rear
verified source
Differential Differential filter plug 39 29
  • Rear
verified source
Clutch assembly Clutch control solenoid wire 5 4
verified source
Drive/Axle shaft Front axle to shock absorber 290 214
verified source
Drive/Axle shaft Front axle to tie rod 49 36
verified source
Drive/Axle shaft Front drive shaft 294 217
  • Front
verified source
Drive/Axle shaft Drive shaft to axle shaft nut 216 159
  • Rear
verified source

steering torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Steering knuckle Steering knuckle to disc brake caliper 107 79 Steel steering knuckle
  • Front
verified source
Steering knuckle Steering knuckle to disc brake caliper 150 111 Aluminium steering knuckle
  • Front
verified source
Steering knuckle Steering knuckle 120 89
  • Front
verified source
Steering column Steering column 36 27
verified source
Steering wheel Steering wheel 62 46
verified source

exhaust torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Exhaust manifold No.2 exhaust manifold heat insulator to exhaust manifold 11 8
verified source
Exhaust manifold Exhaust manifold to cylinder head 26 19
verified source
Exhaust manifold Manifold stay to exhaust manifold and cylinder block 34 25
verified source
Exhaust manifold No. 1 exhaust manifold heat insulator to exhaust manifold 10 7
verified source
Exhaust manifold No. 1 upper floor heat insulator to vehicle body 5 4
verified source
Exhaust manifold Wire harness clamp bracket to water hose clamp bracket 13 10
verified source
Exhaust manifold No.7 exhaust pipe support bracket to vehicle body 29 21
verified source
Exhaust manifold No.6 exhaust pipe support bracket to vehicle body 29 21
verified source
Exhaust manifold Front exhaust pipe assembly to exhaust manifold 43 32
verified source
Exhaust manifold Front exhaust pipe assembly to tail exhaust pipe 43 32
verified source
EGR EGR valve bracket 10 7
verified source
EGR EGR valve assembly to cylinder head 10 7
verified source
EGR EGR pipe subassembly 10 7
verified source
EGR EGR cooler bracket 21 15
verified source
EGR EGR cooler to cylinder head 24 18
verified source
Muffler Muffler heat insulator to vehicle 5 4
verified source

brakes torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Disc brake Axle carrier to disc brake caliper 107 79
  • Rear
verified source
Disc brake Disc brake cylinder mounting 107 79 Minimum
  • Front
verified source
Disc brake Disc brake cylinder mounting 150 111 Maximum
  • Front
verified source
Disc brake Disc brake bleeder plug 8 6
  • Front
verified source
Brake line Brake line 13 10 Minimum
  • Front
verified source
Brake line Brake line 15 11 Maximum
  • Front
verified source
Brake pedal Accelerator pedal to vehicle body 8 6
verified source

suspension torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Shock absorbers/shocks Shock absorber with coil spring 50 37 Vehicle body
  • Front
verified source
Shock absorbers/shocks Shock absorber with coil spring 290 214 Steering knuckle
  • Front
verified source
Shock absorbers/shocks Shock absorber to vehicle 55 41
  • Rear
verified source
Shock absorbers/shocks Shock absorber to axle carrier 125 92 Specified tightening
  • Rear
verified source
Shock absorbers/shocks Shock absorber to axle carrier 91 67 Ball joint lock nut
  • Rear
verified source
Stabilizer bar Stabilizer bracket 44 32
  • Front
verified source
Stabilizer bar Stabilizer bar to stabilizer link 74 55
  • Front
verified source
Stabilizer bar Stabilizer bar 78 58
  • Rear
verified source
Sway bar links/Stabilizer links Stabilizer link 81 60
  • Rear
verified source
Control arm Suspension arm to front frame 200 148 Bolt 1 & Bolt 2
  • Front
verified source
Control arm Suspension arm to front frame 135 100 Bolt 3
  • Front
verified source
Trailing arm Trailing arm to vehicle 90 66
  • Rear
verified source
Ball joint Ball joint to front axle 133 98
  • Front
verified source

general torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
