Toyota Mirai JPD10 (2016-2020) Torque Spec Settings

By M 93, CC BY-SA 3.0 de

Below you'll find the tightening torques for the Toyota Mirai JPD10 in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.

Most-used torque specs for Toyota Mirai JPD10

Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Wheels Wheel lug nuts 103 76
unverified source

To make sure these are the correct tightening torque values, you can use the data below to verify this is the right model.

Are these torque settings right for you?

  • Production years: 2016 - 2020
  • Generation: 1
  • Type of van: car
  • Model variant: Base

All Torque Settings in Tables

engine torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Air conditioning Coolant reservoir fastener 75 55 Use a drive socket #14. Use a ratchet wrench.
unverified source

drivetrain torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Axle/Drive shaft Drive shaft nut 216 159 Use a drive socket #30. Use a torque wrench.
unverified source
Wheel hub assembly Wheel hub bearing fasteners 50 37 Use a drive socket #14. Use a torque wrench.
unverified source

steering torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

exhaust torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to

brakes torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Brake caliper Brake caliper 30 22 Use a drive socket #13. Use a torque wrench.
unverified source
Brake caliper Brake caliper fasteners 44 32 Use a drive socket #14. Use a torque wrench.
unverified source

suspension torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Wheels Wheel lug nuts 103 76
unverified source
Control arm Control arm front fastener to subframe 233 172 Use a drive socket #22. Use a torque wrench.
unverified source
Control arm Control arm rear fastener to subframe 233 172 Use a combination spanner #22. Use a drive socket #22. Use a torque wrench.
unverified source
Ball joint Ball joint fastener 89 66 Use a drive socket #17. Use a torque wrench.
unverified source
Sway bar links/Stabilizer links Stabilizer link to stabilizer bar 74 55 Use a drive sokcet #17. Use a torque wrench.
unverified source
Sway bar links/Stabilizer links Stabilizer link to shock strut nut 74 55 Use a drive sokcet #17. Use a torque wrench.
unverified source

general torque settings

Save to email ✉️
Part Description Torque (Nm) Torque (ft/lbs) Remarks Applies to
Example of a Mirai JPD10

By M 93, CC BY-SA 3.0 de
