Toyota Camry XV40 (2007-2011) Torque Spec Settings

Below you'll find the tightening torques for the Toyota Camry XV40 in both Nm and ft/lbs. The first table contains the most-used torque settings. The tables after it contain all torque spec values I could find.

Most-used torque specs for Toyota Camry XV40

Part	Description	Torque (Nm)	Torque (ft/lbs)	Remarks	Applies to
Wheel hub assembly	Front axle hub nut	294	217
Transmission fluid pan	Drain plug	39	29		Automatic Transaxle
Transmission fluid pan	Drain plug	39	29		Manual Transaxle
Transmission fluid pan	Drain plug	49	36		U250E Automatic Transaxle

To make sure these are the correct tightening torque values, you can use the data below to verify this is the right model.

---

All Torque Settings in Tables

Part	Description	Torque (Nm)	Torque (ft/lbs)	Remarks	Applies to
Oil pump	Oil pump assembly bolt	19	14		2.4L Engine 2AZ-FXE Engine
Radiator	Radiator and cylinder block drain cock plugs	13	10		2AZ-FXE Engine

Part	Description	Torque (Nm)	Torque (ft/lbs)	Remarks	Applies to

Part	Description	Torque (Nm)	Torque (ft/lbs)	Remarks	Applies to

Part	Description	Torque (Nm)	Torque (ft/lbs)	Remarks	Applies to

Part	Description	Torque (Nm)	Torque (ft/lbs)	Remarks	Applies to

Part	Description	Torque (Nm)	Torque (ft/lbs)	Remarks	Applies to

Part	Description	Torque (Nm)	Torque (ft/lbs)	Remarks	Applies to
